  • Page 1 Padlock AX Manual 12.10.2022...

  • Page 2: Table Of Contents

    Contents Padlock AX (Manual) 2 / 26 Contents General safety instructions ........................ 3 Product-specific safety instructions .................... 6 Intended use.............................. 7 Programming ..............................  8 Operation .............................. 10 Battery replacement.......................... 12 Signalling.............................. 17 Technical specifications......................... 18 Scale drawings ............................... 20 EU/UK Declaration of conformity ......................  23...

  • Page 3: General Safety Instructions

    Blocked access Access through a door may stay blocked due to incorrectly fitted and/or in- correctly programmed components. SimonsVoss Technologies GmbH is not liable for the consequences of blocked access such as access to in- jured or endangered persons, material damage or other damage!
  • Page 4 1. General safety instructions Padlock AX (Manual) 4 / 26 PRUDENCE Fire hazard posed by batteries The batteries used may pose a fire or burn hazard if handled incorrectly. 1. Do not try to charge, open, heat or burn the batteries.
  • Page 5 Only trained personnel may install and commission the product.  Incorrect installation SimonsVoss Technologies GmbH accepts no liability for damage caused to doors or compon- ents due to incorrect fitting or installation. Modifications or further technical developments cannot be excluded and may be implemented without notice.

  • Page 6: Product-Specific Safety Instructions

    Damage to the Digital Cylinder AX due to unsuitable tools Special tools are required to open the cover and dismantle the Digital Cylinder AX. If you use un- suitable tools, you may damage the Digital Cylinder AX. Only use the separately available SimonsVoss special tool (Accessories). ...

  • Page 7: Intended Use

    3. Intended use Padlock AX (Manual) 7 / 26 3 Intended use The digital padlock is used to lock doors or other entrances or access points. The padlock may only be used for this specific purpose.

  • Page 8: Programming

    4. Programming Padlock AX (Manual) 8 / 26 4 Programming NOTE Freely rotating active/hybrid Digital Cylinder AX only with shortened range With freely rotating cylinders, the reader knobs may not have sufficient clearance at low cylinder lengths. Due to the range of the active techno- logy, the radio signal can also be unintentionally received by the second reader knob.
  • Page 9 4. Programming Padlock AX (Manual) 9 / 26 NOTE Duration of initial programming A large amount of data is transferred during initial programming. The data transfer speed is significantly higher with a SmartStick AX or a SmartCD.MP (and the programming time is therefore shorter).

  • Page 10: Operation

    5. Operation Padlock AX (Manual) 10 / 26 5 Operation Open 1. Activate your identification medium on the knob. 2. Turn the knob fully clockwise. Shackle unlocked. 3. Open the shackle. Padlock open. Closing 1. Close the shackle. SL version: Shackle locks into place automatically.
  • Page 11 5. Operation Padlock AX (Manual) 11 / 26 3. ML version only: Turn the knob fully counter-clockwise. Shackle locked. 4. Check for correct closure. Padlock locked.

  • Page 12: Battery Replacement

    6. Battery replacement Padlock AX (Manual) 12 / 26 6 Battery replacement NOTE Battery contact malfunction due to grease film When touching batteries, leave a thin film of skin grease on the batteries. This film deteriorates the contact between the electronics and the batter- ies.
  • Page 13 6. Battery replacement Padlock AX (Manual) 13 / 26 3. Align the special tool so that the logo is parallel to the recess. 4. Hold the special tool and thumb turn cap firmly at the same time and turn them together 1-2° clockwise first and then counter-clockwise.
  • Page 14 6. Battery replacement Padlock AX (Manual) 14 / 26 6. Push the latch inward and open the battery cover. 7. Remove the batteries with the special magnetic tool.
  • Page 15 6. Battery replacement Padlock AX (Manual) 15 / 26 8. Insert the new batteries (positive poles touching in the middle). 9. Close the battery cover. Cylinder signals the successful change with triple red flashing and beeping. 10. Put on the cover.
  • Page 16 6. Battery replacement Padlock AX (Manual) 16 / 26 11. Turn the cover clockwise. The cover snaps into place with one click. 12. Carry out a function test. Batteries are replaced.

  • Page 17: Signalling

    7. Signalling Padlock AX (Manual) 17 / 26 7 Signalling Signalling Meaning Identification medium assumed, 2× shortly before engaging (green) normal activation Identification medium not author- 1 x briefly (red) ised 1× briefly, 1× long (green) Flip-flop mode: Engaged 1× long, 1× briefly (green) Flip-flop mode: Disengaged 3×...

  • Page 18: Technical Specifications

    8. Technical specifications Padlock AX (Manual) 18 / 26 8 Technical specifications Basic body without knob/shackle: Dimensions (WxHxD) 70×51×25 mm (8 mm shackle) or 72.5×60×25 mm (11 mm shackle) Dimensions knob (Øxlength) Ø 32 mm × 39.5 mm (electronic) Shackle diameter...
  • Page 19 8. Technical specifications Padlock AX (Manual) 19 / 26 Online, virtual network and offline Networking modes (can be combined - not approved by VdS) Opening modes Pulse flip-flop Storable accesses (3060) 3,000 Time zone groups 100+1 (G2) Number of identification media that...

  • Page 20: Scale Drawings

    8. Technical specifications Padlock AX (Manual) 20 / 26 8.1 Scale drawings 8 mm shackle, 25 mm shackle interior height...
  • Page 21 8. Technical specifications Padlock AX (Manual) 21 / 26 8 mm shackle, 60 mm shackle interior height...
  • Page 22 8. Technical specifications Padlock AX (Manual) 22 / 26 8 mm shackle, 50 mm shackle interior height...

  • Page 23: Eu/Uk Declaration Of Conformity

    Padlock AX (Manual) 23 / 26 9 EU/UK Declaration of conformity The company SimonsVoss Technologies GmbH hereby declares that article (SV-Z5.PL.*) complies with the following guidelines: 2014/53/EU "Radio equipment"  as well as the corresponding UK statutory 2017 No. 1206 "Radio equipment"...

  • Page 24: Help And Other Information

    10. Help and other information Padlock AX (Manual) 24 / 26 10 Help and other information Information material/documents You will find detailed information on operation and configuration and other documents on the website: https://www.simons-voss.com/en/documents.html Declarations of conformity You will find declarations of conformity and other certificates on the website: https://www.simons-voss.com/en/certificates.html...
  • Page 25 10. Help and other information Padlock AX (Manual) 25 / 26 Address SimonsVoss Technologies GmbH Feringastr. 4 D-85774 Unterfoehring Germany...
  • Page 26 Our commercial success lies in the courage to innovate, sustainable thinking and action, and heartfelt appreciation of employees and partners. SimonsVoss is a company in the ALLEGION Group, a globally active network in the security sector. Allegion is represented in around 130 countries worldwide (www.allegion.com).
