- Page 1 EnCor Enspire ™ Breast Biopsy System Quick Reference Guide Ultrasound/Stereotactic...
-
Page 3: Table Of Contents
Contents 1. Easy setup System power up ............................................... 1.1 Vacuum setup ..............................................1.2 Probe setup ................................................1.3 Touch screen setup ............................................1.4 2. Routine procedures Sampling ................................................2.1 Marker placement .............................................2.2 Clean up ................................................2.2 3. Advanced options Sample pattern selection ..........................................3.1 Sample size and tissue density ........................................3.2 Anesthetic mode ...............................................3.3 Biopsy site fluid management........................................3.4... -
Page 4: Easy Setup
Easy setup System power up Vacuum setup Probe setup... - Page 5 2. Connect appropriate EnCor Driver/s to rectangular connector 4. Connect the Foot Pedal at rear of console (if desired). ® on rear of console. The Active Driver is indicated by a green LED light above connector. EnCor Enspire™ quick reference...
-
Page 6: Vacuum Setup
Easy setup System power up Vacuum setup Probe setup... - Page 7 Secure large cap and Place canister into console. tandem cap to lid of canister. Connect tubing cassette Connect elbow to Load tubing cassette to patient port on canister. center of canister lid. (ensure it “clicks” into place). EnCor Enspire™ quick reference...
-
Page 8: Probe Setup
Easy setup System power up Vacuum setup Probe setup... - Page 9 Spike saline bag prior to inserting Align probe. Slide front of probe into designated slot. under front latches. Snap rear of probe Connect probe tubing to large port into rear latches. (purple). Connect optional rinse tubing to small port (blue). EnCor Enspire™ quick reference...
-
Page 11: Routine Procedures
Routine procedures Sampling Marker placement Clean ups... - Page 12 Press and hold “Sample” footswitch for continuous continuous sampling during an ultrasound biopsy. sampling during a stereotactic biopsy. Remove sample tray to access samples. Probe will automatically index to take samples from each of the designated sample sections. EnCor Enspire™ quick reference...
- Page 13 Routine procedures Sampling Marker placement Clean ups...
- Page 14 Align the yellow indicator on the marker with the red indicator on the probe (open aperture position). Depress plunger to deploy marker. Touch “Rotate 180˚” icon on screen. Remove the EnCor ® probe/marker applicator together as one unit. EnCor Enspire™ quick reference...
- Page 15 Routine procedures Sampling Marker placement Clean ups...
- Page 16 Remove probe from driver and dispose Remove and dispose of canister, tubing in sharps biohazard container. cassette and optional saline bag. EnCor Enspire™ quick reference...
-
Page 17: Advanced Options
Advanced options Sample pattern selection Sample size and tissue density Anesthetic mode Biopsy site fluid management Sample rinse option Probe specifications... - Page 18 Sample Pattern Selector. Ultrasound To rotate aperture orientation to even and odd clock positions, push the arrow indicating desired starting position. Stereotactic “Advanced Mode” non-contiguous sample selection is possible. EnCor Enspire™ quick reference...
-
Page 19: Anesthetic Mode
Advanced options Sample pattern selection Sample size and tissue density Anesthetic mode Biopsy site fluid management Sample rinse option Probe specifications... - Page 20 To change sample mode from normal To change sampling from Full to Half, tissue to dense tissue, touch “Dense” touch “Half” sample icon. Touch “Full” icon. Touch“Normal” icon to return sample icon to return to full sampling. to normal tissue sampling. EnCor Enspire™ quick reference...
- Page 21 Advanced options Sample pattern selection Sample size and tissue density Anesthetic mode Biopsy site fluid management Sample rinse option Probe specifications...
- Page 22 “Pattern” icon. touch “360˚” icon to index Vacuum option is accessed the aperture orientation by pressing “VAC” handswitch and distribute anesthetic or footswitch. throughout the biopsy site. Exit anesthetic mode by pressing “Sample” handswitch or footswitch. EnCor Enspire™ quick reference...
- Page 23 Advanced options Sample pattern selection Sample size and tissue density Anesthetic mode Biopsy site fluid management Sample rinse option Probe specifications...
- Page 24 To exit vacuum and return option available. to selected mode, press “VAC” handswitch or footswitch. Touch VAC “Rotate” icon to Touch VAC “Hold” icon to automatically vacuum in engage vacuum continuously. each quadrant. EnCor Enspire™ quick reference...
- Page 25 Advanced options Sample pattern selection Sample size and tissue density Anesthetic mode Biopsy site fluid management Sample rinse option Probe specifications...
- Page 26 Initiate rinse by touching “Rinse” icon on the touch screen. Press “VAC” handswitch or footswitch to make rinse Note: Only available when option available. vacuum and rinse tubing cassette is installed and connected to saline bag. EnCor Enspire™ quick reference...
- Page 27 Advanced options Sample pattern selection Sample size and tissue density Anesthetic mode Biopsy site fluid management Sample rinse option Probe specifications...
- Page 28 Probe specifications Overall Probe Length Dead Space Sample Notch Needle Circumference Probe size Description Overall probe length 34.3 cm 34.2 cm 34.1 cm Needle length 11.4 cm 11.3 cm 11.2 cm Needle circumference 5.0 mm 4.0 mm 3.4 mm Dead space 10.8 mm 9.9 mm 8.7 mm...
-
Page 29: Procedure Screen
Procedure screen Descriptions... - Page 30 Procedure screen descriptions Key description System Status/User Instructions Indicator. Anesthetic Mode Activation Tab/Indicator. Note: Tab highlighted in blue when active mode. Double-press to activate the Stereotactic Table Configuration Window. Marker Mode Activation Tab/Indicator. Note: Must be in Stereotactic Mode and done Note: Tab highlighted in pink when active mode.
- Page 31 ™ ® is not compatible with earlier driver scripts. The script version is identified on the touch screen display during system initialization. 5. The Encor Enspire ™ Breast Biopsy System console may not be placed in an MRI suite. Place the console outside of the MRI suite and use the appropriate Encor ®...
