It is a machine though and needs to be looked after, please read through this user manual which will help you get the most out of your new Ashdown and keep it running as long as some of our happiest and very famous customers.
This can be used to ensure clean headroom or to dial in something a little more aggressive..8. PRE-SET Select from 6 available on board official Ashdown Two notes DynIR impulse response 1. INSTRUMENT INPUT cabinets designed by us for you. See table *T.1 for list.
Page 4
LITTLE BASTARD 2.N LITTLE BASTARD 2.N USER GUIDE USER GUIDE 12. HEADPHONES There is a 32Ohm headphone out for use in silent practice. The headphone output is derived from the amplifier output transformer and does not include the cabinet simulation. This is intended for silent practice and monitoring in real-time.
Page 5
LITTLE BASTARD 2.N LITTLE BASTARD 2.N USER GUIDE USER GUIDE 19. USB - PROGRAM/CHARGE Set a MIDI channel for the unit to receive. You can choose to receive all channels, To either program the on board Two notes Torpedo embededd firmware or with the which is useful when you don’t know exactly on which channel the commands are...
Page 6
LITTLE BASTARD 2.N LITTLE BASTARD 2.N USER GUIDE USER GUIDE THE TORPEDO TECHNOLOGY NOTES: To bring you realism and playing comfort, Two notes has developed a unique technology based on an adaptation of convolution techniques. Starting with the measurement of an actual cabinet and microphone setup, the embedded Two notes Torpedo can accurately reproduce the system as it was measured, as well as the microphone’s position in space.
Page 7
LITTLE BASTARD 2.N LITTLE BASTARD 2.N USER GUIDE USER GUIDE SILENT LIVE INPUT 1 INPUT 1 INPUT 2 INPUT 2 4 OHM or 2 x 8 OHM CABs MIXING DESK MIXING DESK AUDIO INTERFACE AUDIO INTERFACE 8 OHM CAB NO LOAD REQUIRED...
Page 8
LITTLE BASTARD 2.N LITTLE BASTARD 2.N USER GUIDE USER GUIDE THE BASS SELECTION RE-AMP We made a point of capturing a diverse offering of cabinets spanning the entire range from the infamous ABM range to our unique CL-310 cab designed for Guy Pratt.
Page 9
LITTLE BASTARD 2.N LITTLE BASTARD 2.N USER GUIDE USER GUIDE TWO NOTES: GET STARTED All your licenses will the be easily accessible through the software interface which connects you to your online account. 1. To get the best out of your LB 30 2.N, you will need to install the TORPEDO REMOTE 8.
Page 10
0 = 0% ; 63 = 50% ; 127 = 100% Center B 0-127 0 = Back ; 1 = Front Position B LITTLE BASTARD 2.N LITTLE BASTARD 2.N USER GUIDE USER GUIDE 0 = -95dB ; 95 = 0dB ; 107 = 12dB...
Notice for customer: the following information is only applicable to equipment sold in countries applying EU directives Manufacturer: Ashdown Engineering Ltd. The Old Maltings, Hall Road, Heybridge, Essex, England, CM9 4NJ.
Page 13
LITTLE BASTARD 2.N LITTLE BASTARD 2.N USER GUIDE USER GUIDE FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates, uses and can...
Page 14
C’est une machine et il faut en prendre soin, veuillez lire grâce à ce manuel d’utilisation qui vous aidera à tirer le meilleur parti de votre nouvel Ashdown et faites-le fonctionner aussi longtemps que certains de nos clients les plus heureux et très célèbres.
Page 15
1.ENTRÉE INSTRUMENT 8. PRÉRÉGLÉ Choisissez parmi 6 enceintes à réponse impulsionnelle Ashdown Two notes DynIR Il y a deux entrées d’instrument, avec deux options de sensibilité. La bascule haute sensibilité est une bascule à haute impédance adaptée aux instruments de officielles disponibles à...
Page 16
LITTLE BASTARD 2.N LITTLE BASTARD 2.N MODE D’EMPLOI MODE D’EMPLOI 12. ÉCOUTEUSES Il y a une sortie casque de 32 ohms pour une utilisation silencieuse. La sortie casque est dérivée du transformateur de sortie de l’amplificateur et n’inclut pas la simulation d’enceinte.
Page 17
LITTLE BASTARD 2.N LITTLE BASTARD 2.N MODE D’EMPLOI MODE D’EMPLOI 19. USB - PROGRAMMER/CHARGER Définissez un canal MIDI pour que l’unité reçoive. Vous pouvez choisir de recevoir Pour programmer le micrologiciel embarqué Two notes Torpedo ou avec l’option tous les canaux, ce qui est utile lorsque vous ne savez pas exactement sur quel canal pratique pour garder votre périphérique USB chargé...
Page 18
LITTLE BASTARD 2.N LITTLE BASTARD 2.N MODE D’EMPLOI MODE D’EMPLOI LA TECHNOLOGIE TORPEDO REMARQUES: Pour vous apporter réalisme et confort de jeu, Two notes a développé une technologie unique basée sur une adaptation des techniques de convolution. En commençant par la mesure d’une configuration réelle d’enceinte et de microphone, le Two notes Torpedo intégré...
Page 19
LITTLE BASTARD 2.N LITTLE BASTARD 2.N MODE D’EMPLOI MODE D’EMPLOI SILENT LIVE INPUT 1 INPUT 1 INPUT 2 INPUT 2 4 OHM or 2 x 8 OHM CABs MIXING DESK MIXING DESK AUDIO INTERFACE AUDIO INTERFACE 8 OHM CAB NO LOAD REQUIRED...
Page 20
LITTLE BASTARD 2.N LITTLE BASTARD 2.N MODE D’EMPLOI MODE D’EMPLOI LA SÉLECTION DES BASSES RE-AMP Nous avons mis un point d’honneur à capturer une offre diversifiée d’armoires cou- vrant toute la gamme, de la tristement célèbre gamme ABM à notre cabine unique CL-310 conçue pour Guy Pratt.
Page 21
LITTLE BASTARD 2.N LITTLE BASTARD 2.N MODE D’EMPLOI MODE D’EMPLOI DEUX NOTES : COMMENCEZ compte gratuit et enregistrer votre LB 30 2.N afin qu’il soit lié à votre compte. Cela vous permet de sauvegarder tous les préréglages créés par l’utilisateur et d’acheter plus de cartes SIM CAB à...
Page 22
LITTLE BASTARD 2.N LITTLE BASTARD 2.N MODE D’EMPLOI MODE D’EMPLOI nouvellement créé. 14. La sortie CAB SIM XLR est post-EQ, post-Master Volumes, post-FX LOOP, ce qui signifie que toutes les commandes du panneau avant affecteront le signal CAB SIM. Vous pouvez ajouter n’importe quel nombre de pédales dans l’entrée du LB 30 2.N et dans la boucle FX,...
Page 23
0 = 0% ; 63 = 50% ; 127 = 100% Center B 0-127 0 = Back ; 1 = Front Position B LITTLE BASTARD 2.N LITTLE BASTARD 2.N MODE D’EMPLOI MODE D’EMPLOI 0 = -95dB ; 95 = 0dB ; 107 = 12dB...
Avis au client : les informations suivantes ne s’appliquent qu’aux équipements vendus dans les pays appliquant les directives de l’UE Fabricant: Ashdown Engineering Ltd. The Old Maltings, Hall Road, Heybridge, Essex, England, CM9 4NJ.
Page 26
LITTLE BASTARD 2.N LITTLE BASTARD 2.N MODE D’EMPLOI MODE D’EMPLOI DÉCLARATION D’INTERFÉRENCE DE LA COMMISSION FÉDÉRALE DES COMMUNICATIONS Cet équipement a été testé et déclaré conforme aux limites d’un appareil numérique de classe B, conformément à la partie 15 des règles de la FCC. Ces limites sont conçues pour fournir une protection raisonnable contre les interférences nuisibles dans une installation résidentielle.
Es ist jedoch eine Maschine und muss gepflegt werden, bitte lesen durch dieses Benutzerhandbuch, das Ihnen helfen wird, das Beste daraus zu machen Ihr neues Ashdown und halten Sie es so lange am Laufen wie einige unserer glücklichsten und sehr berühmten Kunden. ENTWICKELT FÜR DAS LEBEN „Designed For Life“...
Page 28
8. VOREINGESTELLT Es gibt zwei Instrumenteneingänge mit zwei Empfindlichkeitsoptionen. Der High Wählen Sie aus 6 an Bord verfügbaren offiziellen Ashdown Two Notes DynIR- Sensitivity Toggle ist ein hochohmiger Toggle für passive Bassinstrumente. Der Umschalter für niedrige Empfindlichkeit hat eine Impedanz, um das Signal von Impulsantwortschränken, die von uns für Sie entwickelt wurden.
Page 29
LITTLE BASTARD 2.N LITTLE BASTARD 2.N BENUTZERHANDBUCH BENUTZERHANDBUCH 12. KOPFHÖRER Es gibt einen 32-Ohm-Kopfhörerausgang für stilles Üben. Der Kopfhörerausgang wird vom Ausgangsübertrager des Verstärkers abgeleitet und beinhaltet nicht die Gehäusesimulation. Dies ist für stilles Üben und Überwachen in Echtzeit gedacht.
Page 30
LITTLE BASTARD 2.N LITTLE BASTARD 2.N BENUTZERHANDBUCH BENUTZERHANDBUCH 19. USB - PROGRAMMIEREN/LADEN Stellen Sie einen MIDI-Kanal ein, den das Gerät empfangen soll. Sie können wählen, Um entweder die integrierte Two Notes Torpedo-Firmware zu programmieren oder ob Sie alle Kanäle empfangen möchten, was nützlich ist, wenn Sie nicht genau mit der praktischen Option, Ihr USB-Gerät aufgeladen zu halten ...
Page 31
LITTLE BASTARD 2.N LITTLE BASTARD 2.N BENUTZERHANDBUCH BENUTZERHANDBUCH DIE TORPEDO-TECHNOLOGIE ANMERKUNGEN: Um Ihnen Realismus und Spielkomfort zu bieten, hat Two Notes eine einzigartige Technologie entwickelt, die auf einer Anpassung von Faltungstechniken basiert. Beginnend mit der Messung eines tatsächlichen Gehäuse- und Mikrofon-Setups kann der eingebettete Two Notes Torpedo das System genau so reproduzieren, wie es gemessen wurde, sowie die Position des Mikrofons im Raum.
Page 32
LITTLE BASTARD 2.N LITTLE BASTARD 2.N BENUTZERHANDBUCH BENUTZERHANDBUCH SILENT LIVE INPUT 1 INPUT 1 INPUT 2 INPUT 2 4 OHM or 2 x 8 OHM CABs MIXING DESK MIXING DESK AUDIO INTERFACE AUDIO INTERFACE 8 OHM CAB NO LOAD REQUIRED...
Page 33
LITTLE BASTARD 2.N LITTLE BASTARD 2.N BENUTZERHANDBUCH BENUTZERHANDBUCH DIE BASSAUSWAHL RE-AMP Wir haben Wert darauf gelegt, ein vielfältiges Angebot an Gehäusen zu erfassen, das die gesamte Palette von der berüchtigten ABM-Reihe bis zu unserer einzigar- tigen, für Guy Pratt entworfenen CL-310-Kabine umfasst. Das Sortiment von sechs Boxen umfasst die ABM-810H-EVO IV, ABM-410H-EVO IV, ABM-210H-EVO IV, ABM-115-EVO IV, RM-212-EVO II und die CL-310 DH.
Page 34
LITTLE BASTARD 2.N LITTLE BASTARD 2.N BENUTZERHANDBUCH BENUTZERHANDBUCH ZWEI HINWEISE: BEGINNEN SIE tenloses Konto anmelden und Ihr LB 30 2.N registrieren, damit es mit Ihrem Konto verknüpft wird. Auf diese Weise können Sie alle vom Benutzer erstellten Presets sichern und weitere CAB-SIMs zur Verwendung mit Ihrem Verstärker kaufen.
Page 35
LITTLE BASTARD 2.N LITTLE BASTARD 2.N BENUTZERHANDBUCH BENUTZERHANDBUCH auf dem LB 30 2.N auf Position 1 greift auf das neu erstellte Preset zu. 14. Der CAB SIM XLR-Ausgang ist Post-EQ, Post-Master Volumes, Post-FX LOOP, was bedeutet, dass alle Bedienelemente auf der Frontplatte das CAB SIM-Signal beeinflussen.
Page 36
0 = 0% ; 63 = 50% ; 127 = 100% Center B 0-127 0 = Back ; 1 = Front Position B LITTLE BASTARD 2.N LITTLE BASTARD 2.N BENUTZERHANDBUCH BENUTZERHANDBUCH 0 = -95dB ; 95 = 0dB ; 107 = 12dB...
Gemeindeverwaltung, Ihren Entsorgungsdienst für Haushaltsabfälle oder das Geschäft, in dem Sie das Produkt gekauft haben. Hinweis für Kunden: Die folgenden Informationen gelten nur für Geräte, die in Ländern verkauft werden, in denen EU-Richtlinien gelten Hersteller: Ashdown Engineering Ltd. The Old Maltings, Hall Road, Heybridge, Essex,...
Page 39
LITTLE BASTARD 2.N LITTLE BASTARD 2.N BENUTZERHANDBUCH BENUTZERHANDBUCH INTERFERENZERKLÄRUNG DER FEDERAL COMMUNICATION COMMISSION Dieses Gerät wurde getestet und entspricht den Grenzwerten für ein digitales Gerät der Klasse B gemäß Teil 15 der FCC-Bestimmungen. Diese Grenzwerte sollen einen angemessenen Schutz vor schädlichen Interferenzen in Wohngebieten bieten.
LITTLE BASTARD 2.N GUÍA DEL USUARIO GRACIAS ¡Gracias por comprar su producto Ashdown Engineering y bienvenido a la familia! Realmente creemos que ha tomado la decisión correcta y sabemos que este ampli- ficador le brindará años de excelente tono y servicio.
Page 41
1.ENTRADA DE INSTRUMENTO 8.PREESTABLECIDA Seleccione entre los 6 gabinetes de respuesta de impulso DynIR oficiales Ashdown Two Hay dos entradas de instrumento, con dos opciones de sensibilidad. El conmutador notes disponibles a bordo diseñados por nosotros para usted. Consulte la tabla *T.1 de alta sensibilidad es un conmutador de alta impedancia que se adapta a los instrumentos de bajo pasivos.
Page 42
LITTLE BASTARD 2.N LITTLE BASTARD 2.N GUÍA DEL USUARIO GUÍA DEL USUARIO 12. AURICULARES Hay una salida de auriculares de 32 ohmios para usar en la práctica silenciosa. La salida de auriculares se deriva del transformador de salida del amplificador y no incluye la simulación de gabinete.
Page 43
LITTLE BASTARD 2.N LITTLE BASTARD 2.N GUÍA DEL USUARIO GUÍA DEL USUARIO 19. USB - PROGRAMA/CARGA Configure un canal MIDI para que la unidad lo reciba. Puede elegir recibir todos Para programar el firmware integrado Two notes Torpedo integrado o con la los canales, lo que es útil cuando no sabe exactamente en qué...
Page 44
LITTLE BASTARD 2.N LITTLE BASTARD 2.N GUÍA DEL USUARIO GUÍA DEL USUARIO LA TECNOLOGÍA DE TORPEDOS NOTAS: Para brindarle realismo y comodidad al tocar, Two notes ha desarrollado una tecnología única basada en una adaptación de las técnicas de convolución.
Page 45
LITTLE BASTARD 2.N LITTLE BASTARD 2.N GUÍA DEL USUARIO GUÍA DEL USUARIO SILENT LIVE INPUT 1 INPUT 1 INPUT 2 INPUT 2 4 OHM or 2 x 8 OHM CABs MIXING DESK MIXING DESK AUDIO INTERFACE AUDIO INTERFACE 8 OHM CAB...
Page 46
LITTLE BASTARD 2.N LITTLE BASTARD 2.N GUÍA DEL USUARIO GUÍA DEL USUARIO LA SELECCIÓN DE BAJOS RE-AMP Nos propusimos capturar una oferta diversa de gabinetes que abarcan toda la gama, desde la infame gama ABM hasta nuestra exclusiva cabina CL-310 diseñada para Guy Pratt.
Page 47
LITTLE BASTARD 2.N LITTLE BASTARD 2.N GUÍA DEL USUARIO GUÍA DEL USUARIO DOS NOTAS: COMENZAR dos por el usuario y comprar más tarjetas SIM CAB para usar con su amplificador. Se podrá acceder fácilmente a todas sus licencias a través de la interfaz del software que lo conecta a su cuenta en línea.
Page 48
LITTLE BASTARD 2.N LITTLE BASTARD 2.N GUÍA DEL USUARIO GUÍA DEL USUARIO 14. La salida CAB SIM XLR es post-EQ, post-Master Volumes, post-FX LOOP, lo que sig- nifica que todos los controles del panel frontal afectarán la señal CAB SIM. Puede agregar cualquier cantidad de pedales en la entrada del LB 30 2.N y en el FX LOOP, todos estos se...
Page 49
0 = 0% ; 63 = 50% ; 127 = 100% Center B 0-127 0 = Back ; 1 = Front Position B LITTLE BASTARD 2.N LITTLE BASTARD 2.N GUÍA DEL USUARIO GUÍA DEL USUARIO 0 = -95dB ; 95 = 0dB ; 107 = 12dB...
Aviso para el cliente: la siguiente información solo se aplica a los equipos vendidos en países que aplican las directivas de la UE Fabricante: Ashdown Engineering Ltd. The Old Maltings, Hall Road, Heybridge, Essex, England, CM9 4NJ.
Page 52
LITTLE BASTARD 2.N LITTLE BASTARD 2.N GUÍA DEL USUARIO GUÍA DEL USUARIO DECLARACIÓN DE INTERFERENCIA DE LA COMISIÓN FEDERAL DE COMUNICACIONES Este equipo ha sido probado y se encontró que cumple con los límites para un dispositivo digital de Clase B, de conformidad con la Parte 15 de las Reglas de la FCC. Estos límites están diseñados para brindar una protección razonable contra interferencias dañinas en una...
