Leviton Decora ODS0D-TDx Installation Instructions

DESIGNER WALL SWITCH
OCCUPANCY SENSOR
CEC Title 24 Compliant
Single Pole (One Location)
or Multi-Location
Rated: 120/277V, 60Hz
Cat. No. ODSØD-TDx
Incandescent
800W @ 120V Primary
800W @ 120V Secondary
Fluorescent
1200VA @ 120V Primary
800VA @ 120V Secondary
Fluorescent
2700VA @ 277V Primary
1200VA @ 277V Secondary
Supplemental
1/4hp @ 120V Primary
1/4hp @ 120V Secondary
No Minimum Load Required
Compatible with electronic and magnetic ballasts, electronic and
magnetic low-voltage ballasts, incandescent lamps, and fans.
INSTALLATION INSTRUCTIONS
DI-00X-ODS0D-00A
LIMITED 5 YEAR WARRANTY AND EXCLUSIONS
Leviton warrants to the original consumer purchaser and not for the benefit
of anyone else that this product at the time of its sale by Leviton is free of
defects in materials and workmanship under normal and proper use for five
years from the purchase date. Leviton's only obligation is to correct such
defects by repair or replacement, at its option, if within such five year period
the product is returned prepaid, with proof of purchase date, and a description
of the problem to Leviton Manufacturing Co., Inc., Att: Quality Assurance
Department, 59-25 Little Neck Parkway, Little Neck, New York 11362-2591.
This warranty excludes and there is disclaimed liability for labor for removal
of this product or reinstallation. This warranty is void if this product is installed
improperly or in an improper environment, overloaded, misused, opened,
abused, or altered in any manner, or is not used under normal operating
conditions or not in accordance with any labels or instructions. There are no
other or implied warranties of any kind, including merchantability and
fitness for a particular purpose, but if any implied warranty is required by
the applicable jurisdiction, the duration of any such implied warranty, including
merchantability and fitness for a particular purpose, is limited to five years.
Leviton is not liable for incidental, indirect, special, or consequential
damages, including without limitation, damage to, or loss of use of,
any equipment, lost sales or profits or delay or failure to perform this
warranty obligation. The remedies provided herein are the exclusive
remedies under this warranty, whether based on contract, tort or otherwise.
For Technical Assistance Call:
1-800-824-3005 (U.S.A. Only)
1 800 405-5320 (Canada Only)
www.leviton.com
DI-00X-ODS0D-00A
CHARACTERISTICS
• Leviton's Decora style design • Switches 2 separate lighting loads
®
• Low Profile, tamper-resistant lens • Adapting time and ambient light
INTRODUCTION
Leviton Cat. No. ODSØD-TDx, Designer Wall Switch Occupancy Sensor, is designed to detect motion from a heat-emitting source (such as a person
entering a room) within its field-of-view (monitored space) and automatically switch lights ON and OFF.
Cat. No. ODSØD-TDx is an Occupancy Sensor that is designed to control two separate lighting circuits from a single unit. This allows the user to replace
two standard switches with a single unit that will also provide the convenience and energy savings of an occupancy sensor.
The sensor has a 30 minute maximum adjustable time-delay setting for both relays and is Manual-ON only for the second relay.
Daylight Savings Mode:
In this mode, the Sensor will take a measurement of the ambient light in the room when it first detects motion. If there is enough light in the room, the
Sensor will leave the lights connected to the first relay OFF. If there is not enough light in the room, the Sensor will turn the lights connected to the first relay
ON. The lights connected to the second relay turn ON manually with the second PUSH BUTTON.
Note that the Sensor will time out and turn the lights OFF after no motion is detected.
Cat. No. ODSØD-TDx is UL listed, CSA certified and conforms to California Title 24 requirements.
DESCRIPTION
The Occupancy Sensor senses motion within its coverage area of 2400 sq. ft (223.3 m
contained device which provides sensing and light control. The Occupancy Sensor will turn the lights ON when motion is initially detected, and keep the
lights ON for as long as motion is detected.
The Occupancy Sensor uses a small semiconductor heat detector that resides behind a multi-zone optical lens. This Fresnel lens establishes dozens of
zones of detection. The sensor is sensitive to the heat emitted by the human body. In order to trigger the Sensor, the source of heat must move from one
zone of detection to another. The device is most effective in sensing motion across its field-of-view, and less effective sensing motion towards or away from
its field-of-view (refer to figures 1 and 1A). Keep this in mind when selecting the installation location (refer to figures 1 and 1A).
Note that occupancy sensors respond to rapid changes in temperature, so care should be taken not to mount the device near a climate control source (i.e.
radiators, air exchanges, and air conditioners). Hot or cold drafts will look like body motion to the device and will trigger it if the unit is mounted too close. It
is recommended to mount the Occupancy Sensor at least 6 ft. away from the climate control source. The device can be mounted in a single gang
wall box.
In addition, it is also recommended NOT to mount the Occupancy Sensor directly under a large light source. Large wattage bulbs (greater than 100W
incandescent) give off a lot of heat and switching the bulb causes a temperature change that can be detected by the device. Mount the Occupancy Sensor
at least 6 ft. away from large bulbs. If it necessary to mount the device closer, lower the wattage of the bulb directly overhead.
FCC COMPLIANCE STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device must not cause harmful
interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
INSTALLATION INSTRUCTIONS
WARNING:
TO BE INSTALLED AND/OR USED IN ACCORDANCE WITH APPROPRIATE ELECTRICAL CODES AND REGULATIONS.
WARNING: IF YOU ARE NOT SURE ABOUT ANY PART OF THESE INSTRUCTIONS, CONSULT A QUALIFIED ELECTRICIAN.
WARNING:
CONTROLLING A LOAD IN EXCESS OF THE SPECIFIED RATINGS WILL DAMAGE THE UNIT AND POSE RISK OF FIRE, ELECTRIC
SHOCK, PERSONAL INJURY OR DEATH. CHECK YOUR LOAD RATINGS TO DETERMINE SUITABILITY FOR YOUR APPLICATION.
WARNING:
DO NOT INSTALL THIS UNIT TO CONTROL A RECEPTACLE.
OTHER CAUTIONS AND NOTES:
1. DISCONNECT POWER WHEN SERVICING FIXTURE OR CHANGING BULBS.
2. U SE THIS DEVICE WITH COPPER OR COPPER CLAD WIRE ONLY. WITH ALUMINUM WIRE, USE DEVICES MARKED CO/ALR OR
CU/AL ONLY.
3. DO NOT TOUCH THE SURFACE OF THE LENS. CLEAN OUTER SURFACE WITH A DAMP CLOTH ONLY.
4. THE CAT. NO. ODSØD-TDx OCCUPANCY SENSOR IS INTENDED TO REPLACE A STANDARD LIGHT SWITCH.
TO INSTALL:
NOTE: Cat. No. ODSØD-TDx requires a ground connection in order to operate. Use the ground wire in the electrical box for ground connection. If there is
no ground wire, make sure the electrical box is grounded and attach the ground wire to the box with a screw.
1. WARNING : TO AVOID FIRE, SHOCK, OR DEATH: TURN OFF POWER AT CIRCUIT BREAKER OR FUSE AND TEST THAT THE POWER IS OFF
BEFORE WIRING.
2. Connect wires per appropriate WIRING DIAGRAM as follows: BLACK wire to LINE (phase 1). One RED wire to Line (phase 2). If only one phase is
used, connect BLACK and RED wires together. The remaining RED wire to BANK 2. BLUE wire to LOAD (or BANK 1). GREEN wire to GROUND. Twist
strands of each lead tightly and, with circuit conductors, push firmly into the appropriate wire connector. Screw connector on clockwise making sure that
no bare wire shows below the connector. Secure each wire connector with electrical tape.
NOTE: THE BLUE WIRE IS THE PRIMARY LOAD CONNECTION (HIGHER RATED).
3. Carefully position the wires into the wall box, then mount the Sensor Unit into the wall box.
4. Secure device using long mounting screws provided.
5. Restore power at circuit breaker or fuse.
NOTE: Cat. No. ODSØD-TDx will beep once 5 seconds after power is applied. After approximately 25 seconds the lights will turn ON. Both lights always
turn ON 25 seconds after power is applied. Allow approximately 1 minute for charge-up. If the lights turn ON and the LED blinks when a hand is
waved in front of the lens, then the Sensor was installed properly. If the operation is different, refer to the Troubleshooting Section.
C at. No. ODSØD-TDx is factory preset to work without any adjustments. If you desire to change the factory settings, refer to the Settings
section below.
6. A ttach the Control Panel cover, and a Decora ® Wallplate (not included). INSTALLATION IS COMPLETE. Leave the room and the lights
will turn OFF after the selected time-out expires.
• CEC Title 24 Compliant Factory Settings: The Sensor is shipped from the factory to work in almost all situations without any added adjustments. The factory settings are: Blinders
open, Base time-out 10 minutes, Lights always turn ON regardless of existing light levels, and Maximum range.
• 30 minute maximum time-out on second relay
Blinders: The blinders are two independent shutters that can narrow the field-of-view from a maximum of 180° down to 32°. The blinders are operated by
moving the blinder levers towards or away from the center of the Sensor. The blinder levers can be found above the control dials in the control panel (refer
to figure 2A).
Time-Outs: The Sensor has three types of Time-Outs: Walk-through, Base Time, and Adapting.
• Walk-through Time-Out: The value of this time-out is preset to 2.5 minutes. It is used by the Sensor as a starting point in adjusting the other types of
• Base Time-Out: The value of this time-out is user selected through the use of the Time Control Setting.
• Adapting Time-Out: When activated, the value of this time-out is changed by the Sensor based on room occupancy and lighting conditions.
Walk-Through: The walk-through feature is useful when a room is momentarily occupied. With this feature, the Sensor will turn the lights OFF shortly after
the person leaves the room.
The walk-through feature works in the following manner: When a person enters the room, the lights on the first relay will turn ON. If the person leaves the
room before the default walk-through time-out of 2.5 minutes, the Sensor will turn the lights OFF. If the person stays in the room for longer than 2.5 minutes,
the Sensor will instead use the time-out per the Time Control Setting (refer to Time Control Setting in the following sections).
The walk-through feature may be user disabled (refer to Non-Adapting Mode in the following sections).
Audio Warning: The Sensor is equipped with a beeper to give the user feedback of unit operation. During normal operation, the Sensor will issue three
) maximum and controls the connected lighting. This is a self-
2
short beeps 20 seconds before the time-out is over to alert the user that the lights are going to turn OFF. The occupant must move in order for the lights to
remain ON. The Sensor issues two short beeps to let the occupant know that motion was detected and that the lights will stay ON.
Adapting Time Delay: The Sensor has built in adapting intelligence that changes the adapting time-out duration in response to the occupancy conditions
of the room it is installed in.
If the Sensor detects "large" motions (as a person walking by), it will NOT change the time-out duration. If the Sensor detects "small", infrequent motion (as
a person sitting down and writing), it will INCREASE the Adapting Time-Out duration. If the Sensor detects "small", frequent motion (as in several persons
in a room during a meeting), it will DECREASE the Time-Out duration only if it was NEVER increased (this is because the built-in intelligence will always
proceed in the direction of "increasing" adapting time-out once it has increased it for any of the occupancy conditions sensed).
If the room is occupied for longer than 2.5 minutes, the Sensor will enter the Occupied Mode with the Time-Out duration specified by the Time Control
Setting. This Time-Out is used as the starting point for adapting. After a few days, the Time-Out value will adapt to the "best" value based on the occupancy
conditions detected in the room.
If the Sensor detects motion immediately after the audio warning beep, it will determine that the existing Time-Out value is too short. The Sensor will thus
increase the Time-Out value by 1.5 times the existing value.
If the Sensor detects motion within 30 seconds after the lights turn OFF, it will turn the lights ON and increase the Time-Out value by 1.5 times the existing
value.
The adapted Time-out may be reset to the base value by rotating the Time Control to a new time selection value (refer figure 2A).
Time Control Setting: The base Time-Out value is selected by rotating the Time Control dial.
There are four (4) values from which to choose. Each mark around the dial corresponds to a
different value as indicated below (refer to figure 2A). The Sensor will beep once to indicate
that a new time value has been selected.
NOTE: All time durations is approximate within ±10 seconds.
Adapting Ambient Light Override: The Ambient Light Override is used to keep the lights
OFF if there is already enough natural light in the room. For proper operation, the Ambient Light
Override adjustment must be performed when there is enough natural light (refer to the Settings section). If the adjustment is made when there is less
natural light, the lights may not turn ON even though they are needed. This will require manual activation of the push-buttons to turn the lights ON.
If the Ambient Light Override Adjustment is not performed properly, the Adapting feature will adjust this setting. The Sensor will use the light level prior to
turning the lights ON as the new Ambient Light value and increase it slightly so that next time the same conditions are present, it will turn the lights ON. This
adapting feature may take a few cycles prior to adjusting to the proper light level.
If the Ambient Light Override is not performed, the adapting feature will not be utilized (refer to Ambient Light Dial in the following section).
NOTE: The ambient light level in the center of a room will be different than the level at the wall where the switch is located.
NOTE: The adapting light level only affects the Primary load.
Ambient Light Dial: The ambient light setting is adjusted with the Ambient Light dial (refer to figure 2A). Turning the Light Dial fully counter-clockwise
(CCW), sets the Sensor to manual ON mode (lights always turn ON) (see following section). All other settings will cause the lights to turn ON only when
the light level is less than the setting.
To prevent false low light levels from the user standing in front of the device during adjustment, the Sensor remembers the Ambient Light level from 1
minute ago.
There are two ways the Adapted Ambient Light level can be reset to the level set by the dial: (1) By rotating the Light Dial, the adapted value will be
replaced by the new value corresponding to the new position of the dial. (2) By pressing and holding either button for 3 seconds; the Sensor will beep once
and reset the Adapted Light Level value to the dial setting.
NOTE: When the setting is at the minimum CCW level, the lights will stay OFF when the room is dim. When the setting is at the maximum level clockwise
(CW), the lights will turn ON when the room is bright.
Manual ON Mode: When the light control is in the fully CCW position the Primary load will never automatically turn ON. In this mode the lights need to be
manually turned ON by the push-button, and will turn OFF with the absence of motion. If the light control is in the fully CW position,
the Primary load will turn ON whenever motion is detected, even in full daylight. Intermediate settings will cause the lights to turn ON only when the ambient
light is below the level selected by the light control. The Secondary load is always a Manual-ON only mode.
NOTE: The ambient light in a room will change with the time of day and the season of the year.
NOTE: The Primary load always turns ON.
RANGE: To decrease detection range and sensitivity, rotate the knob CCW (refer to figure 2A). The detection range can be adjusted from 100%
down to 36%.
FEATURES
time-outs.
Face Marking Value of Time
(/) Slash Mark 30 second test mode, NO walk-through
1 5 minutes base time-out
2 10 minutes base time-out
3 20 minutes base time-out
