Operation Manual & Parts List
USER MANUAL
AUTO H
O
2
RANDOM SEMI-AUTOMATIC-WAT-EU
RSA 2024-WAT-EU
CASE SEALER
For Serial Numbers:
TM905 XX X XXX
For Machines Starting With Serial Number TM905 XX X XXX/TM914 XX X XXX
For all other serial numbers, contact Customer Service @ 800-474-8273 (Menu #3)
This manual also available at
www.Intertapepolymer.com
ape Polymer Group © 2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BETTER PACKAGES RSA 2024-WAT-EU and is the answer not in the manual?

Questions and answers

Related Manuals for IPG BETTER PACKAGES RSA 2024-WAT-EU

Summary of Contents for IPG BETTER PACKAGES RSA 2024-WAT-EU

  • Page 1 Operation Manual & Parts List USER MANUAL AUTO H RANDOM SEMI-AUTOMATIC-WAT-EU RSA 2024-WAT-EU CASE SEALER For Serial Numbers: TM905 XX X XXX For Machines Starting With Serial Number TM905 XX X XXX/TM914 XX X XXX For all other serial numbers, contact Customer Service @ 800-474-8273 (Menu #3) This manual also available at www.Intertapepolymer.com ape Polymer Group ©...

  • Page 4: Table Of Contents

    RSA2024-WAT-EU Table of Contents Table of Contents Chapter Title Page GENERAL INFORMATION ....................Revision Control ........................1-1 Technical Support ........................1-1 Replacement Parts ........................1-1 Field Service Assistance ......................1-2 Warranty ..........................1-2 Description of RSA2024-WAT-EU Case Sealer ..............1-3 Optional Equipment .........................

  • Page 5: Chapter Title Page

    Table of Contents RSA2024-WAT-EU Chapter Title Page Connecting Utilities ......................... 4-7 4.6.1 Electrical Utilities ......................... 4-7 4.6.2 Pneumatic Utilities ....................... 4-8 Operator Control Box ......................4-10 Operator Control Box Relocation ................... 4-11 Top Tape Head Loading/Threading ..................4-12 4.9.1 Direction of Top Tape Unwind ...................
  • Page 6 RSA2024-WAT-EU Table of Contents Chapter Title Page Cleaning the Cutter Blade (Top Tape Head) ................7-7 Cleaning the Cutter Blade (Bottom Tape Head) ..............7-8 Cutter Blade Maintenance ...................... 7-9 7.10 Cutter Blade Replacement ....................7-10 MACHINE MAINTENANCE & ADJUSTMENT ............
  • Page 7 Table of Contents RSA2024-WAT-EU List of Figures Figure Name Page Figure 1-1 RSA2024-WAT-EU Case Sealer ....................1-3 Figure 1-2 Optional Equipment ........................1-4 Figure 2-1 Safety Label Placement ......................2-2 Figure 3-1 Machine Dimensions ........................3-1 Figure 3-2 Machine Components ........................

  • Page 8: Name Page

    RSA2024-WAT-EU Table of Contents Figure Name Page Figure 5-1 E-stop Locations ........................5-1 Figure 5-2 Fold Minor Flaps ........................5-2 Figure 5-3 Fold Major Flaps ........................5-2 Figure 5-4 Overfill ............................5-2 Figure 5-5 Void Fill............................5-2 Figure 5-6 Control Box ..........................
  • Page 9 Table of Contents RSA2024-WAT-EU Figure Name Page Figure 7-23 Remove Water Pot ........................7-8 Figure 7-24 Clean Striker Plate ........................7-8 Figure 7-25 Cutter Blade Maintenance ......................7-9 Figure 7-26 Striker Plate and Cutting Blade ....................7-10 Figure 7-27 Striker Plate ..........................

  • Page 10: General Information

    RSA2024-WAT-EU General Information Chapter 1 GENERAL INFORMATION 1.1 R EVISION ONTROL REV00 ................................Initial Release 1.2 T ECHNICAL UPPORT This is the Interpack Model AUTO H O Random Semi-Automatic-WAT-EU (RSA2024-WAT-EU) Side-Belt Case Sealer you ordered. It has been set up and tested in our factory with Intertape manufactured water activated tapes. If any problems occur when setting up or operating this equipment, please contact the authorized distributor from where you purchased this item.

  • Page 11: Field Service Assistance

    General Information RSA2024-WAT-EU 1.4 F IELD ERVICE SSISTANCE This machine is designed to provide years of trouble-free operation. If any problems arise with this machine during the normal course of operation, your properly trained and qualified internal service personnel should be able to repair any issues after consulting Chapter 6, Troubleshooting.

  • Page 12: Description Of Rsa2024-Wat-Eu Case Sealer

    RSA2024-WAT-EU General Information 4. Failure is due to equipment, which has been altered by anyone other than an authorized representative of Intertape Polymer Group. 5. Failure is due to an attempt by the purchaser to correct alleged defective equipment. In this event the purchaser is responsible for all expenses incurred.

  • Page 13: Optional Equipment

    General Information RSA2024-WAT-EU 1.7 O PTIONAL QUIPMENT Figure 1-2 Optional Equipment...

  • Page 14: Important Safeguards

    RSA2024-WAT-EU Important Safeguards Chapter 2 IMPORTANT SAFEGUARDS 2.1 S AFETY ABELS There are a number of safety labels used on the RSA2024-WAT-EU Case Sealer. These labels are placed at different locations on the machine to warn operators and service personnel of possible dangers (refer to Figure 2-1).

  • Page 15: Safety Label Placement

    Important Safeguards RSA2024-WAT-EU 2.2 S AFETY ABEL LACEMENT Figure 2-1 Safety Label Placement...

  • Page 16: Safety Label Descriptions

    RSA2024-WAT-EU Important Safeguards 2.3 S AFETY ABEL ESCRIPTIONS The label shown is affixed to the upper tape head assembly on both sides of the machine. It warns operators and service personnel of the presence of the cutting blade that may not be visible.
  • Page 17 Important Safeguards RSA2024-WAT-EU The label shown is located on the side of the column. This label provides convenient safety instructions for the operator and service personnel in the operation of the Intertape Case Sealing Equipment. The label shown is located on the in-feed end of the machine.
  • Page 18 RSA2024-WAT-EU Important Safeguards The label shown is located on the chain side of the machine. The label warns the operators and service personnel of the pinch points. The label shown is located on the side of the outfeed table. The label warns the operators and service personnel to keep fingers clear of lower tape mandrel.

  • Page 19: Explanation Of Signal Word Consequences

    Important Safeguards RSA2024-WAT-EU 2.4 E XPLANATION OF IGNAL ONSEQUENCES WARNING: Indicates a potentially hazardous situation that, if not avoided, could result in death or serious injury or property damage. CAUTION: Indicates a potentially hazardous situation that, if not avoided, could result in minor or moderate injury or property damage.

  • Page 20: Operator Skill Level Descriptions

    RSA2024-WAT-EU Important Safeguards 2.5 O PERATOR KILL EVEL ESCRIPTIONS Important: The area supervisor must ensure that the operator has been properly trained on all machine functions before operating the machine. 2.5.1 Skill “A” Machine Operator This operator is trained to use the machine with the machine controls. This operator can feed cases into the machine, make adjustments for different case sizes, change tapes, and start/stop, and re-start production.
  • Page 21 Important Safeguards RSA2024-WAT-EU Notes...

  • Page 22: Specifications

    RSA2024-WAT-EU Specifications Chapter 3 SPECIFICATIONS 3.1 M ACHINE IMENSIONS Machine Weight: 544kg (1200 lbs) crated Figure 3-1 Machine Dimensions...

  • Page 23: Machine Components

    Specifications RSA2024-WAT-EU 3.2 M ACHINE OMPONENTS Figure 3-2 Machine Components...

  • Page 24: Machine Operating Conditions

    3.3.3 Tape Specifications Use IPG Water-Activated Tape. The machine can accommodate tape widths of 48 - 75mm (2 - 3 in.). A maximum tape roll length of 1371.6m (4500 ft) can be installed on the tape heads. This machine can accommodate all Intertape brand, water-activated tape within listed specifications.

  • Page 25: Case Processing Stability

    Specifications RSA2024-WAT-EU Case Size Carton Size Length Width Height Minimum 152mm (6 in.) 165mm (6.5 in.) 127mm (5 in.) Maximum Infinite 508mm (20 in.) 610mm (24 in.) 3.3.5 Case Processing Stability For optimal performance, the cases should be stable when processing through the machine. Unstable cases may tilt backwards upon contact with the upper tape head causing the machine to jam.

  • Page 26: Set-Up Procedures

    RSA2024-WAT-EU Set-Up Procedures Chapter 4 SET-UP PROCEDURES 4.1 R ECEIVING AND ANDLING The machine is shipped to the customer fixed to a pallet. The machine is enclosed with either a corrugated sleeve and cap or an HSC corrugated box. The sequence below is step by step instructions to remove all packing materials.

  • Page 27: Caster Installation (If Purchased)

    Set-Up Procedures RSA2024-WAT-EU 4.2 C ASTER NSTALLATION URCHASED WARNING: Caster installation requires raising the machine to access the bottom of each leg. Follow all possible safety procedures prior to and during this process. 1. With a forklift, raise the machine to allow access to the bottom of each leg. 2.

  • Page 28: Machine Height Adjustment

    RSA2024-WAT-EU Set-Up Procedures 4.3 M ACHINE EIGHT DJUSTMENT WARNING: Machine height adjustment requires raising the machine to adjust each leg. Follow all possible safety procedures prior to and during this process. The RSA2024-WAT-EU Case Sealer must be installed on near-level ground. Use the adjustable legs to ensure that the machine is level and firmly on the ground (no rocking).
  • Page 29 Set-Up Procedures RSA2024-WAT-EU 4.4 I NSTALLATION OF NTERPACK RAND OLLER ABLES URCHASED Case Direction Figure 4-4 Case Direction 1. Loosely install two carriage bolts into top two mounting holes on roller table with hardware included (refer to Figure 4-5). Figure 4-5 Carriage Bolt Installation...

  • Page 30: Figure 4-6 Roller Table To Machine Base

    RSA2024-WAT-EU Set-Up Procedures 2. Utilizing the slots on the machine base, attach roller table to machine base by locating carriage bolts in slots on machine base and push down to lock in place (refer to Figure 4-6). Make sure carriage bolts are properly aligned into slot when pushed down to lock in place before proceeding.

  • Page 31: Installation Of External In-Feed And Exit Conveyors

    Set-Up Procedures RSA2024-WAT-EU 4.5 I NSTALLATION OF XTERNAL EED AND ONVEYORS 1. Customer supplied in-feed conveyor (if used) should provide straight and level entry into the case sealer. 2. Customer supplied gravity exit conveyor (if used) should be straight and declined no more than 20mm/meter away from the machine to convey the sealed cartons away from the machine.

  • Page 32: Connecting Utilities

    RSA2024-WAT-EU Set-Up Procedures 4.6 C ONNECTING TILITIES 4.6.1 Electrical Utilities A 3657.6mm (12 ft) standard three-conductor power cord with plug is provided for 220V, 50HZ, 10A electric service. The receptacle must be properly grounded. Before the machine is plugged into the receptacle, ensure that all materials are removed from the machine.

  • Page 33: Pneumatic Utilities

    Set-Up Procedures RSA2024-WAT-EU 4.6.2 Pneumatic Utilities Note: The pressure setting for the main air regulator (Figure 4-10) is factory set. The values will need to be adjusted as needed by customer supplied pressure and volume. The main air regulator has a male quick disconnect adaptor (refer to Figure 4-10). Connect clean dry compressed air to this adaptor.

  • Page 34: Figure 4-11 Pressure Regulators

    RSA2024-WAT-EU Set-Up Procedures The pressure regulators in (refer to Figure 4-11) control various operations of the machine. The regulators on the left labeled “OPEN” and “CLOSE” control the pressure for the drive bases. The recommended pressure settings for the “OPEN” and “CLOSE” regulators is 30 PSI. The third regulator from the left labeled “UP” controls the pressure for the top tape head box rising.

  • Page 35: Figure 4-12 Operator Control Box

    Set-Up Procedures RSA2024-WAT-EU 4.7 O PERATOR ONTROL Make sure machine is connected to air supply of at least 90 PSI and machine regulator is set at 75 PSI. The following describes the use of control box buttons: 1. Clear button (Operational in Auto Mode only). This button is used to simplify clearing a jam during production.

  • Page 36: Operator Control Box

    RSA2024-WAT-EU Set-Up Procedures 4.8 O PERATOR ONTROL ELOCATION Moving the control box to the opposite side of the machine requires detaching and reattaching the control box from the columns and reconnecting electrical wires and components. Note: Only trained and qualified service technicians should perform the relocation. Ensure that you follow all possible safety procedures prior to and during this process.

  • Page 37: Top Tape Head Loading/Threading

    Set-Up Procedures RSA2024-WAT-EU 4.9 T OADING HREADING 4.9.1 Direction of Top Tape Unwind As shown in the diagram below, tape should be mounted with a counterclockwise, unwind direction. The adhesive side of tape will be facing up as it goes around the peel-off roller. 4.9.2 Top Tape Path The diagram below shows the threaded tape path using the red line/arrow as the tape.

  • Page 38: Figure 4-15 Control Box - Top Threading

    RSA2024-WAT-EU Set-Up Procedures 4.9.3 Top Tape Threading/Loading Instructions The instructions below will assist in threading tape on the top tape head. Top Threading diagram is located on page 4-12. 1. Put machine in Manual Mode using Manual/Auto selector switch (Figure 4-15, Item 1). 2.

  • Page 39: Bottom Tape Head Loading/Threading

    Set-Up Procedures RSA2024-WAT-EU 4.10 B OTTOM OADING HREADING 4.10.1 Direction of Bottom Tape Unwind As shown in the diagram below, tape should be mounted with a clockwise, unwind direction. The adhesive side of tape will be facing down as it goes around the peel-off roller. 4.10.2 Bottom Tape Path The diagram below shows the threaded tape path using the red line/arrow as the tape.

  • Page 40: Bottom Tape Head Threading/Loading Instructions

    RSA2024-WAT-EU Set-Up Procedures 4.10.3 Bottom Tape Threading/Loading Instructions The instructions below will assist in threading of tape on the bottom tape head. Bottom Threading diagram is located on page 4-14. 1. Put machine in Manual Mode using Manual/Auto selector switch (Figure 4-18, Item 1). 2.

  • Page 41: Adding Water To The System

    Set-Up Procedures RSA2024-WAT-EU Figure 4-20 Bottom Tape Head Loading/Threading 4.11 A DDING ATER YSTEM 1. Remove the water bottles by pulling them straight up from support brackets (refer to Figure 4-21). 2. Turn the bottles over so the water will not spill. 3.
  • Page 42 RSA2024-WAT-EU Set-Up Procedures Notes 4-17...
  • Page 43 Set-Up Procedures RSA2024-WAT-EU THIS PAGE INTENTIONALLY LEFT BLANK 4-18...

  • Page 44: Operating Instructions

    RSA2024-WAT-EU Operating Instructions Chapter 5 OPERATING INSTRUCTIONS 5.1 I NTRODUCTION TO PERATING NSTRUCTIONS Once the tape has been loaded and threaded on both the top and bottom, allow up to 10 minutes of being powered on for the machine to become completely ready to process regular slotted cases. The following instructions are presented in the order recommended for processing cases successfully through the RSA2024-WAT-EU Case Sealer.

  • Page 45: Preparing Case To Be Processed

    Operating Instructions RSA2024-WAT-EU 15. The top tape head box will lower or rise to match case height, the side belts will travel horizontally to match case width and process case through machine. 16. Once box has been processed, machine is ready for production. 5.2 P REPARING ASE TO BE...

  • Page 46: Control Box

    RSA2024-WAT-EU Operating Instructions 5.3 C ONTROL The RSA2024-WAT-EU Case Sealer has three operating modes. The operator selects these modes, using the 2-position switch and push button on the Control Box (refer to Figure 5-6). When the case sealer is turned on, the top tape head box will rise to the uppermost position and side belt drives will come out to their outermost position.

  • Page 47: Manual Mode

    Operating Instructions RSA2024-WAT-EU 5.3.2 Manual Mode This mode is used for troubleshooting and loading tape on to machine. 1. Ensure that the compressed air is plugged in and at 90 PSI. 2. Turn the control selector to Manual mode (refer to Figure 5-6). 3.
  • Page 48 RSA2024-WAT-EU Operating Instructions...
  • Page 49 Operating Instructions RSA2024-WAT-EU THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 50: Troubleshooting

    RSA2024-WAT-EU Troubleshooting Chapter 6 TROUBLESHOOTING The RSA2024-WAT-EU Case Sealer is fabricated with high quality components that provide trouble-free operation for a long period of time. However, should a problem occur, we recommend that you consult the following table. If the problem you encounter is not discussed in this table, call Interpack Technical Support.
  • Page 51 Troubleshooting RSA2024-WAT-EU Trouble Possible Causes Solutions Drive belts start then stop. Motor starter trips. Call maintenance. Product height exceeds case height. Reduce product in case to match case height. Overfilled cases do not Increase case height to match process properly. product height.
  • Page 52 RSA2024-WAT-EU Troubleshooting Trouble Possible Causes Solutions Roller dry; no or low water pot level. Add water or adjust water bottle level (page 4-16). Tape is jamming. Water pot not seated properly. Re-seat water pot (page 4-16). Worn roller. Replace roller. Water level in water pot too low.
  • Page 53 Troubleshooting RSA2024-WAT-EU Trouble Possible Causes Solutions Case not introduced to machine Make sure to introduce box in straight. square and straight. Case is overfilled. Make sure case is not overfilled. Rear wipe down arm timing is off. Adjust rear wipe down arm timing in HMI.

  • Page 54: Preventive Maintenance

    RSA2024-WAT-EU Preventive Maintenance Chapter 7 PREVENTIVE MAINTENANCE 7.1 M ACHINE REVENTIVE AINTENANCE The RSA2024-WAT-EU Case Sealer has been designed and manufactured with the finest components to provide long, trouble-free performance. General preventive maintenance will improve performance and prolong the life of the case sealer. Review the illustrations and chart below for information regarding machine maintenance.

  • Page 55: Cleaning The Machine

    Preventive Maintenance RSA2024-WAT-EU 7.2 C LEANING THE ACHINE WARNING: Exercise all safety precautions prior to starting this procedure. Disconnect electrical power and wear approved safety glasses. 7.2.1 Side Belt Drive Base Insert an air nozzle along the top edge of the belt into the opening of the drive base and clean out any dust and dirt (refer to Figure 7-2).

  • Page 56: Changing The Air Regulator Filter

    RSA2024-WAT-EU Preventive Maintenance 7.3 C HANGING THE EGULATOR ILTER WARNING: Ensure that the case sealer has been disconnected from the power source and the airline before conducting any maintenance procedures. The filter on the air regulator removes dirt and moisture from air plant before it enters the carton sealer. To remove metal protective guard, press down on locking tab located towards the top of the guard, rotate guard and pull down (refer to Figure 7-3).

  • Page 57: Lubricating The Machine

    Preventive Maintenance RSA2024-WAT-EU 7.4 L UBRICATING THE ACHINE 7.4.1 Acme Drive Base Shafts Lubricate both shafts with light machine grease. 7.4.2 Centering Chain Lubricate Chain With Chain Lubricant. Figure 7-6 Lubricating the Machine...
  • Page 58 RSA2024-WAT-EU Preventive Maintenance 7.5 R EMOVING THE For cutter blade maintenance and replacement, removal of the tape heads is required for ease of access. Make sure tape has been removed from the top tape head before attempting to remove them from machine. 1.

  • Page 59: Removing The Bottom Tape Head

    Preventive Maintenance RSA2024-WAT-EU 7.6 R EMOVING THE OTTOM For cutter blade maintenance and replacement, removal of the tape heads is required for ease of access. Make sure tape has been removed from the bottom tape head before attempting to remove them from machine. 1.

  • Page 60: Cleaning The Cutter Blade (Top Tape Head)

    RSA2024-WAT-EU Preventive Maintenance 7.7 C LEANING THE UTTER LADE WARNING: The knife contained in the tape heads is extremely sharp. Use caution when threading the tape or performing maintenance to avoid injury. 1. Remove top cover from tape head, (refer to Figure 7-19). 2.

  • Page 61: Cleaning The Cutter Blade (Bottom Tape Head)

    Preventive Maintenance RSA2024-WAT-EU 7.8 C LEANING THE UTTER LADE OTTOM WARNING: The knife contained in the tape heads is extremely sharp. Use caution when threading the tape or performing maintenance to avoid injury. 1. Remove tape shoe and water pot from tape head, (refer to Figures 7-22 and 7-23), to gain access to cutter blade area.

  • Page 62: Cutter Blade Maintenance

    RSA2024-WAT-EU Preventive Maintenance 7.9 C UTTER LADE AINTENANCE WARNING: The knife contained in the tape heads is extremely sharp. Use caution when threading the tape or performing maintenance to avoid injury. The cutter blade must rise when tape is being processed to allow the tape to proceed underneath.

  • Page 63: Cutter Blade Replacement

    Preventive Maintenance RSA2024-WAT-EU 7.10 C UTTER LADE EPLACEMENT WARNING: The knife contained in the tape heads is extremely sharp. Use caution when threading the tape or performing maintenance to avoid injury. 1. Remove tape shoe from tape head from Cutting Blade Striker Plate top tape head, (refer to Section...

  • Page 64: Machine Maintenance & Adjustment

    RSA2024-WAT-EU Machine Maintenance & Adjustment Chapter 8 MACHINE MAINTENANCE & ADJUSTMENT 8.1 D RIVE EPLACEMENT Using a 4mm Allen key, remove two screws and remove drive base cover. Using appropriate Allen key and wrench, loosen belt tensioning bolts. Remove worn belt and replace with new belt. Using appropriate Allen key and wrench, tighten belt tensioning bolts.

  • Page 65: Drive Belt Adjustment

    Intertape S/B drive idler pulleys are engineered to self- track to center. After tensioning, if the belts do not track on center, contact maintenance or your IPG Distributor. Using a 4mm Allen key, replace drive base cover, as shown. 8.2 D...
  • Page 66 Machine Maintenance & Adjustment Intertape S/B drive idler pulleys are engineered to self- track to center. After tensioning, if the belts do not track on center, contact maintenance or your IPG Distributor. Using a 4mm Allen key, replace drive base cover as shown.
  • Page 67 Machine Maintenance & Adjustment RSA2024-WAT-EU Notes...

  • Page 68: Illustrated Parts List

    RSA2024-WAT-EU Illustrated Parts List Chapter 9 ILLUSTRATED PARTS LIST List of Assemblies Section Name Page UM905TW - RSA2024-WAT-EU TOP LEVEL ASSEMBLY ............9-4 UAM0534 - FRONT DOOR GUARDING ASSEMBLY ..............9-6 UAM0519 – SINGLE DOOR GUARDING ASSEMBLY .............. 9-8 9.3.1 M8141 –...
  • Page 69 Illustrated Parts List RSA2024-WAT-EU 9.12.2.1 UAM0528 – DOOR GUARDING RIGHT HAND DOOR ASSEMBLY ........9-62 9.12.2.2 UAM0527 – DOOR GUARDING LEFT HAND DOOR ............9-64 9.13 UAM0512 – BRIDGE ASSEMBLY .................... 9-66 9.13.1 UAM0513 – BRIDGE BASE ASSEMBLY ................9-68 9.13.1.1 UAM0530 –...
  • Page 70 RSA2024-WAT-EU Illustrated Parts List 9.16 UAM0536 – COLUMN ASSEMBLY ..................9-136 9.16.1 UAM0529 – COLUMN BRIDGE MOUNT CART ASSEMBLY ........... 9-138 9.17 UAM0503 – ELECTRICAL BOX ..................... 9-140 9.18 UAM0025 – CLUTCH MECHANISM ..................9-143 9.19 WST1048 – RSA WAT BOTTOM T.H. MAIN ASSEMBLY .............

  • Page 71: Um905Tw - Rsa2024-Wat-Eu Top Level Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.1 UM905TW - RSA2024-WAT-EU T EVEL SSEMBLY...
  • Page 72 RSA2024-WAT-EU Illustrated Parts List UM805T - RSA2024-WAT-EU CASE SEALER ITEM PART NUMBER DESCRIPTION QTY. UAM0534 EU FRONT DOOR GUARDING ASSEMBLY UAM0511 DRIVE UNIT, R.H UAM0510 DRIVE UNIT, L.H Z5310-00BA00 GUIDE ADJUSTMENT ASSEMBLY USM0867 BASE ASSEMBLY UAM0518 EU CONTROL BOX UAM0489 OUTPUT TABLE UAM0535 EU REAR DOOR GUARDING ASSEMBLY...

  • Page 73: Uam0534 - Front Door Guarding Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.2 UAM0534 - FRONT DOOR GUARDING ASSEMBLY...
  • Page 74 RSA2024-WAT-EU Illustrated Parts List UAM0534 - FRONT DOOR GUARDING ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UAM0520 RSA FIXED GUARD ASSEMBLY UF1250EV BHCS M6-1.0X16L UF3399 M6 INSERT NUT RSA SINGLE DOOR GUARD UAM0519 ASSEMBLY DOOR GUARDING CORNER UPM6277 BRACKET UPM6296 DOOR GUARDING FRAME...

  • Page 75: Uam0519 - Single Door Guarding Assembly

    Illustrated Parts List RSA2024-WAT-EU UAM0519 – SINGLE DOOR GUARDING ASSEMBLY...
  • Page 76 RSA2024-WAT-EU Illustrated Parts List UAM0519 – SINGLE DOOR GUARDING ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UPM6286 DOOR GAURDING LATCH ACTUATOR UF6363 LW M6 UF3681 M4 LW UF7023 LW M5 UF6371 LW M10 UF1828 FW M6 UF3710 FW M4 UF1827 FW M5 UF3680 FW M10 UF0012...
  • Page 77 Illustrated Parts List RSA2024-WAT-EU 9.3.1 M8141 – DOOR SWITCH 9-10...

  • Page 78: M8141 - Door Switch

    RSA2024-WAT-EU Illustrated Parts List M8141 – DOOR SWITCH ITEM PART NUMBER DESCRIPTION QTY. UF0038 SHCS M6-1.0X12 UF6363 M6 LW UF1828 M6 FW UPM6288 "DOOR GUARDING LOWER MOUNT SM-L UF0025 M6 INSERT NUT UF6376 M4 LOCK-NUT UPM6283 DOOR GUARDING LATCH UF3710 M4 FW UF4050EV BHCS M4-0.7X20...

  • Page 79: Uam0520 - Fixed Guarding Assembly

    Illustrated Parts List RSA2024-WAT-EU UAM0520 – FIXED GUARDING ASSEMBLY 9-12...
  • Page 80 RSA2024-WAT-EU Illustrated Parts List UAM0520 – FIXED GAURDING ASSEMBLY ITEM NO. PART NUMBER DESCRIPTION QTY. UPM6284 DOOR GUARDING CORNER UPM6296 DOOR GUARDING FRAME 1014L UF3710 FW M4 UF3681 M4 LW UF0869 SHCS M4-0.7X8 UPM5733 E-STOP UPM6293 GUARDING E-STOP MOUNTING BRACKET UF6404 BHCS M10-1.5X25 UPM6289...

  • Page 81: Usm8075 - Second E-Stop

    Illustrated Parts List RSA2024-WAT-EU USM8075 – SECOND E-STOP 9-14...
  • Page 82 RSA2024-WAT-EU Illustrated Parts List USM8075 – SECOND E-STOP ITEM PART NUMBER DESCRIPTION QTY. UPM5873 CABLE GLANDS UPM5733 E-STOP UPM6045 E-STOP LABEL UPM6170 BUTTON BOX 9-15...

  • Page 83: Uam0510 - Drive Unit, Left Hand

    Illustrated Parts List RSA2024-WAT-EU UAM0510 – DRIVE UNIT, LEFT HAND 9-16...
  • Page 84 RSA2024-WAT-EU Illustrated Parts List UAM0510 – DRIVE UNIT, LEFT HAND ITEM PART NUMBER DESCRIPTION QTY. UPM4975 COVER LEFT SIDE UPM7468 DRIVING BELT 50 x 2360L UPM4883 DRIVE PULLEY UF3683 M6-1.0-SSS UF3752 BHCS M6-1.0×30L UF3712 FHCS M6-1.0×30L UPM6163 DRIVE WELDMENT, L.H UPM4008 MOTOR 1/3HP 25:1 NEMA4 UF0103...

  • Page 85: Uam0511 - Drive Unit, Right Hand

    Illustrated Parts List RSA2024-WAT-EU UAM0511 – DRIVE UNIT, RIGHT HAND 9-18...
  • Page 86 RSA2024-WAT-EU Illustrated Parts List UAM0511 – DRIVE UNIT, RIGHT HAND ITEM PART NUMBER DESCRIPTION QTY. UPM4973 COVER RIGHT SIDE UF5600 BHCS M6-1.0×12L UPM7468 DRIVING BELT 50 x 2360L UF0017 Ø12MM SNAP RING UPM0324 BEARING PULLEY UPM0109 IDLER PULLEY SPACER UPM4885 IDLER PULLEY UPM1233EV IDLER PULLEY SHAFT 50mm...

  • Page 87: Uam0508 - Guide Adjustment Assembly

    Illustrated Parts List RSA2024-WAT-EU UAM0508 – GUIDE ADJUSTMENT ASSEMBLY 9-20...
  • Page 88 RSA2024-WAT-EU Illustrated Parts List UAM0508 – GUIDE ADJUSTMENT ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UAM0141 DRIVE SUPPORT RSA2024 2000 UPM3330 SHAFT COLLAR 20mm / SS UF0079 SHCS M6-1.0X16 UPM3250 / 6079 SHAFT ANCHOR PLATE / SS UF0867 M8 LW UF0866 M8-1.25 HNR UF0048 M20 FW...

  • Page 89: Usm0867 - Base Assembly

    Illustrated Parts List RSA2024-WAT-EU USM0867 – BASE ASSEMBLY 9-22...
  • Page 90 RSA2024-WAT-EU Illustrated Parts List USM0867 – BASE ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UAM0477 ROLLER ASSEMBLY, R.H. UPM4930 SIDE COVER UF0086 SHCS M6-1.0X8 UPM6267 WIRING BOX UAM0533 CORD SLEEVE ASSEMBLY UPM3226 PVC ROL CHARCOAL DIA 1.9 X 12.00 UPM5873 CABLE GLANDS UAM0468 FRAME ASSEMBLY UPM0602 / 2830...

  • Page 91: Uam0468 - Frame Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.9.1 UAM0468 - FRAME ASSEMBLY 9-24...
  • Page 92 RSA2024-WAT-EU Illustrated Parts List UAM0468 - FRAME ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UAM0478 OUTLET TABLE ASSEMBLY UAM0473 INLET TABLE ASSEMBLY UF122 SHCS M6-1.0X6 UF4020 W3/8"-16×1"-CARRIAGE BOLT UAM0469 BASE WELDMENT UF3680 FW M10 UF6371 LW M10 UF1540 HNR 3/8"-16 UPM6386 FRAME COVER UF5601 BHCS M5-0.8X6...

  • Page 93: Uam0469 - Base Weldment

    Illustrated Parts List RSA2024-WAT-EU 9.9.2 UAM0469 - BASE WELDMENT 9-26...
  • Page 94 RSA2024-WAT-EU Illustrated Parts List UAM0469 - BASE WELDMENT ITEM PART NUMBER DESCRIPTION QTY. UPM5946 BEAM UAM0482 LOWER HOST BASE ASSEMBLY UPM5941 SIDE PANEL UPM5944 FRONT BEAM 9-27...

  • Page 95: Uam0484 - Pneumatic Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.9.3 UAM0484 – PNEUMATIC ASSEMBLY 9-28...
  • Page 96 RSA2024-WAT-EU Illustrated Parts List UAM0484 – PNEUMATIC ASEMBLY ITEM PART NUMBER DESCRIPTION QTY. UPM5973 FLOW CONTROL, 1/8 UF1827 FW M5 UF0044 SHCS M5-0.8X75 UPM5981 WIRE CONNECTOR UPM5544 SOLENOID VALVE UPM6363 PNEUMATIC 1/8 90 DEG QUICK CONNECT UPM5980 SOLENOID VALVE UPM5680 SOLENOID VALVE UPM6172 RAIL...

  • Page 97: Uam0482 - Lower Host Base Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.9.4 UAM0482 – LOWER HOST BASE ASSEMBLY 9-30...
  • Page 98 RSA2024-WAT-EU Illustrated Parts List UAM0482 – LOWER HOST BASE ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UPM6148 LOWER HOST BASE, R.H. UF3680 M10 FW UF6371 M10 LW UF4252 M10-1.5-BHCS UPM6252 SHAFT, 140L UPM5970 LOWER HOIST COVER UF1827 M5 FW UF7023 M5 LW UF3686 BHCS M5-0.8X10 UF1828...

  • Page 99: Uam0483 - Inlet Stop Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.9.5 UAM0483 – INLET STOP ASSEMBLY 9-32...
  • Page 100 RSA2024-WAT-EU Illustrated Parts List UAM0483 – INLET STOP ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UF3264 FHCS M8-1.25×20L UPM7513 STOP UPM5972 CYLINDER W/ GUIDE ROD UPM5974 PLUG, G1/8 UPM5973 FLOW CONTROL, 1/8 UPM5971 STOP BRACKET UF0103 M6 FW, 19MM OD 2MM THK UF6363 LW M6 UF5600...

  • Page 101: Uam0515 - Water Bottle Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.9.6 UAM0515 – WATER BOTTLE ASSEMBLY 9-34...
  • Page 102 RSA2024-WAT-EU Illustrated Parts List UAM0515 – WATER BOTTLE ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UF5404 FHCS M5-0.8X16 UPM5116 FRAME UF1828 M6 FW UF0454 HHCS M6-1.0X16 UPM5120 WT BOTTLE HOLDER UPM5689 WATER RESERVOIR UPM4945 CUP HOLDER UF6340 M5 FW SS UF7021 M5 SS LW UF3283 BHCS M5-0.8X10 SS...

  • Page 103: Uam0478 - Outlet Table Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.9.7 UAM0478 – OUTLET TABLE ASSEMBLY 9-36...
  • Page 104 RSA2024-WAT-EU Illustrated Parts List UAM0478 – OUTLET TABLE ASSEMBLY ITEM PART# DESCRIPTION QTY. UF0075 M5-0.8-SELF TAPPING UPM5962 SLIP PAD, R.H. UF6305 FHCS M5-0.8×10L UPM5964 COVER UPM5965 BRUSH UF1827 M5 FW UF0039 SHCS M5-0.8 x 10mm UF7021 LW M5 UF7003 SHCS M5-0.8 x 12mm UPM5960 REAR SUPPORT SEAT, R.H.

  • Page 105: Uam0473 - Inlet Table Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.9.8 UAM0473 – INLET TABLE ASSEMBLY 9-38...
  • Page 106 RSA2024-WAT-EU Illustrated Parts List UAM0473 – INLET TABLE ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UF0075 M5-0.8-SELF TAPPING UPM4954 SLIDING PAD UF0039 SHCS M5-0.8X10 UF7021 LW M5 UF1827 FW M5 UPM5956 SENSOR SUPPORT UF7003 SHCS M5-0.8X12 UPM5952 FRONT SEAT, R.H. UPM5953 SHIM 0.1mm Z5309-00AA10 SHIM 0.2mm...

  • Page 107: Uam0474 - Roller Assembly, Left Hand

    Illustrated Parts List RSA2024-WAT-EU 9.9.9 UAM0474 – ROLLER ASSEMBLY, LEFT HAND 9-40...
  • Page 108 RSA2024-WAT-EU Illustrated Parts List UAM0474 – ROLLER ASSEMBLY, LEFT HAND ITEM PART NUMBER DESCRIPTION QTY. UF3710 M4 FW UF3749 LW M4 UF9148 SHCS M4-0.7×10L UPM4941 ROLLER UPM4942 ROLLER SHAFT UF3393 LOCK-NUT UF1827 M5 FW UF3170 SHCS M6-1.0×8L UF0039 SHCS M5-0.8 x 10mm UPM5957 ROLLER PLATE 9-41...

  • Page 109: Uam0477 - Roller Assembly, Right Hand

    Illustrated Parts List RSA2024-WAT-EU 9.9.10 UAM0477 – ROLLER ASSEMBLY, RIGHT HAND 9-42...
  • Page 110 RSA2024-WAT-EU Illustrated Parts List UAM0477 – ROLLER ASSEMBLY, RIGHT HAND ITEM PART NUMBER DESCRIPTION QTY. UPM4942 ROLLER SHAFT UPM4941 ROLLER UF3710 M4 FW UF9148 SHCS M4-0.7×10L UF3749 LW M4 UF0039 SHCS M5-0.8 x 10mm UPM5958 ROLLER PLATE UF3170 SHCS M6-1.0×8L UF1827 M5 FW UF3393...

  • Page 111: Uam0533 - Cord Sleeve

    Illustrated Parts List RSA2024-WAT-EU 9.9.11 UAM0533 – CORD SLEEVE 9-44...
  • Page 112 RSA2024-WAT-EU Illustrated Parts List UAM0533 – CORD SLEEVE ITEM PART NUMBER DESCRIPTION QTY. UPM6360 FLEXIBLE CORD SLEEVE UPM6361 RIGID CORD SLEEVE UF1195 BHCS M6-1.0X12L UF1828 FW M6 UF3681 M4 LW UF5929 BHCS M4-0.7X6 UF1827 FW M5 UF7023 LW M5 UF5201 SHCS M5-0.8X10 UPM6362 RIDGID CORD SLEEVE COVER...

  • Page 113: Uam0518 - Control Box

    Illustrated Parts List RSA2024-WAT-EU 9.10 UAM0518 – CONTROL BOX 9-46...
  • Page 114 RSA2024-WAT-EU Illustrated Parts List UAM0518 – CONTROL BOX ITEM PART NUMBER DESCRIPTION QTY. UPM4926 ILLUMINATED PB, MUSHROOM, BLUE UPM6273 EU CONTROL BOX FRAME UPM4905 CORD GRIP UPM6275 EU CONTROL BOX SEAL UPM6274 EU CONTROL BOX FACE PLATE UF0069 BHCS M4-0.7x25 UPM5709 PUSH BUTTON UPM5733...

  • Page 115: Uam0489 - Output Table

    Illustrated Parts List RSA2024-WAT-EU 9.11 UAM0489 – OUTPUT TABLE 9-48...
  • Page 116 RSA2024-WAT-EU Illustrated Parts List UAM0489 – OUTPUT TABLE ITEM PART NUMBER DESCRIPTION QTY. UAM0504 OUTPUT TABLE TOP UF0864 SHCS M8-1.25×20L UF0867 M8 LW UF3643 M8 FW UPM6039 TAPE ROLL CARRIAGE UAM0506 BTM TAPE CARRAGE UPM0847 LEG ADJUSTMENT WELDMENT UPM0931 LEG FRICTION PLATE UF4230 M12 LW UF4231...

  • Page 117: Uam0504 - Output Table Top

    Illustrated Parts List RSA2024-WAT-EU 9.11.1 UAM0504 – OUTPUT TABLE TOP 9-50...
  • Page 118 RSA2024-WAT-EU Illustrated Parts List UAM0504 – OUTPUT TABLE TOP ITEM PART NUMBER DESCRIPTION QTY. UF1318 BHCS M8-1.25×20L UPM5222 CHAIN SHIELD UPM4969 CHAIN COVER UF5601 BHCS M5-0.8×6L UPM4891 CHAIN #40, 12 PITCH UPM4890 CHAIN #40, 25 PITCH UAM0505 OUTPUT TABLE WELDMENT UPM5124 CHAIN COVER UF6340...

  • Page 119: Uam0506 - Bottom Tape Carriage

    Illustrated Parts List RSA2024-WAT-EU 9.11.2 UAM0506 – BOTTOM TAPE CARRIAGE 9-52...
  • Page 120 RSA2024-WAT-EU Illustrated Parts List UAM0506 – BOTTOM TAPE CARRIAGE ITEM PART NUMBER DESCRIPTION QTY. M8-1.25×25L M8-1.25-FHCS M8 LW M8-1.25 M8-1.25-HNR M24-1.5 M24-1.5-HNR M5-0.8×25L M5-0.8-FHCS UPM5114 UPM6143 BACK FRAME UPM5109 STEPPED SHAFT L.H. UF3815 RET'G RING, ID 10 UAM0479 DANCER ARM ASSEMBLY UPM5111 PANCAKE UAM0195...

  • Page 121: Upm6039 - Tape Roller Carriage

    Illustrated Parts List RSA2024-WAT-EU 9.11.3 UPM6039 – TAPE ROLLER CARRIAGE 9-54...
  • Page 122 RSA2024-WAT-EU Illustrated Parts List UPM6039 – TAPE ROLLER CARRIAGE ITEM PART NUMBER DESCRIPTION QTY. UPM6042 BRACKET UF1250EV BHCS M6-1.0×16L UF6363 LW M6 UF1828 M6 FW UF0098 SHCS M8-1.25×25L UF3640 LW M8 UF0105 M8 FW UPM6142 SHUTTLE BLOCK UPM6043 SHAFT UF3680 M10 FW UF3743 LW M10...

  • Page 123: Uam0535 - Rear Door Guarding Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.12 UAM0535 – REAR DOOR GUARDING ASSEMBLY 9-56...
  • Page 124 RSA2024-WAT-EU Illustrated Parts List UAM0535 – REAR DOOR GUARDING ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UPM6296 DOOR GUARDING FRAME 996L UPM6277 DOOR GUARDING CORNER BRACKET DOOR GUARDING DOUBLE DOOR UAM0522 ASSEMBLY UF3399 M6 INSERT NUT UF1250EV BHCS M6-1.0X16L DOOR GUARDING HALF DOOR UAM0523 ASSEMBLY 9-57...

  • Page 125: Uam0522 - Door Guarding Double Door Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.12.1 UAM0522 – DOOR GUARDING DOUBLE DOOR ASSEMBLY 9-58...
  • Page 126 RSA2024-WAT-EU Illustrated Parts List UAM0522 – DOOR GUARDING DOUBLE DOOR ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UF0038 SHCS M6-1.0X12L UPM6287 DOOR GUARDING LOWER BRACKET UF0830 SHCS M6-1.0X16 UPM6289 DOOR GUARDING LOWER MOUNT LG UPM6286 DOOR GUARDING LATCH ACTUATOR UF6363 LW M6 UF1828 FW M6 UPM6289...

  • Page 127: Uam0523 - Door Guarding Half Door Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.12.2 UAM0523 – DOOR GUARDING HALF DOOR ASSEMBLY UAM0523 – DOOR GUARDING HALF DOOR ASSEMBLY 9-60...
  • Page 128 RSA2024-WAT-EU Illustrated Parts List ITEM PART NUMBER DESCRIPTION QTY. UPM6286 DOOR GUARDING LATCH ACTUATOR UF0038 SHCS M6-1.0X12L UF0830 SHCS M6-1.0X16 UPM6294 DOOR GUARDING LOWER BRACKET SM UPM6289 DOOR GUARDING LOWER MOUNT UF6363 LW M6 UF1828 FW M6 INSERT NUT UPM6287 DOOR GUARDING LOWER BRACKET UPM6296 DOOR GUARDING FRAME 901L...

  • Page 129: Uam0528 - Door Guarding Right Hand Door Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.12.2.1 UAM0528 – DOOR GUARDING RIGHT HAND DOOR ASSEMBLY 9-62...
  • Page 130 RSA2024-WAT-EU Illustrated Parts List UAM0528 – DOOR GUARDING RIGHT HAND DOOR ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UPM6279 DOOR GUARDING HINGE UF3399 M6 INSERT NUT UF1241EV BHCS M6-1.0X20L UF5900 M6 LOCK-NUT UF5600 BHCS M6-1.0X12L UPM6281 DOOR GUARDING HANDLE UF4050EV BHCS M4-0.7X20 UF3710 FW M4 UPM6283...

  • Page 131: Uam0527 - Door Guarding Left Hand Door

    Illustrated Parts List RSA2024-WAT-EU UAM0527 – DOOR GUARDING LEFT HAND DOOR 9.12.2.2 9-64...
  • Page 132 RSA2024-WAT-EU Illustrated Parts List UAM0527 – DOOR GUARDING LEFT HAND DOOR ITEM PART NUMBER DESCRIPTION QTY. UPM6280 DOOR GUARDING STOPPER PANEL UF6376 M4 LOCK-NUT UF3710 FW M4 UF0076 BHCS M6-1.0X25L UF1828 FW M6 UPM6283 DOOR GUARDING LATCH UPM6278 DOOR GUARDING DOOR PANEL UF4050EV BHCS M4-0.7X20 UPM6281...

  • Page 133: Uam0512 - Bridge Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.13 UAM0512 – BRIDGE ASSEMBLY 9-66...
  • Page 134 RSA2024-WAT-EU Illustrated Parts List UAM0512 – BRIDGE ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UAM0514 BRIDGE TAPE ROLL MOUNT ASSEMBLY UAM0515 WATER BOTTLE ASSEMBLY UAM0513 BRIDGE BASE ASSEMBLY USM7583 TOP TAPE CARRIAGE ASSEMBLY 9-67...

  • Page 135: Uam0513 - Bridge Base Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.13.1 UAM0513 – BRIDGE BASE ASSEMBLY 9-68...
  • Page 136 RSA2024-WAT-EU Illustrated Parts List UAM0513 – BRIDGE BASE ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UPM5102 SHAFT, dia 9.5 UPM4992 SPACER, 18L UPM4989 TOP COVER UF6375 SHCS M4-0.7X50 UPM1068 COMPRESSION SPRING UPH4004 BRUSH 4" TH UPM4968 BRUSH HOLDER ADAPTER UF0074 FHCS M5-0.8X50 UF1828 M6 FW UF6363...

  • Page 137: Uam0530 - Bridge Head Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.13.1.1 UAM0530 – BRIDGE HEAD ASSEMBLY 9-70...
  • Page 138 RSA2024-WAT-EU Illustrated Parts List UAM0530 – BRIDGE HEAD ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UPM3238 SPACER RSA 2024 2000 (UPM0733) UPM0733 MOUNTING BRACKET FOR M18 SENSOR UPM0014 FRONT PADDLE SENSOR IG5399 UPM0014-nut FRONT PADDLE SENSOR IG5399 NUT UF1192 FHCS M6-1.0X16 UPM6062 LOWER PIVOT SHAFT UF6376...

  • Page 139: Uam0531 - Bridge Snap Switch Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.13.1.1.1 UAM0531 – BRIDGE SNAP SWITCH ASSEMBLY 9-72...
  • Page 140 RSA2024-WAT-EU Illustrated Parts List UAM0531 – BRIDGE SNAP SWITCH ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UPM6346 SNAP ACTION SWITCH BRACKET UF1828 FW M6 UF6363 LW M6 UF0038 SHCS M6-1.0X12L UF3710 FW M4 UF3681 M4 LW UF5928 SHCS M4-0.7X8 UPM5711 SWITCH SNAP ACTION SPDT 10A 125V 9-73...

  • Page 141: Uam0532 - Bridge Head Photoelectric Sensor Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.13.1.1.2 UAM0532 – BRIDGE HEAD PHOTOELECTRIC SENSOR ASSEMBLY 9-74...
  • Page 142 RSA2024-WAT-EU Illustrated Parts List UAM0532 – BRIDGE HEAD PHOTOELECTRIC SENSOR ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UF5928 SHCS M4-0.7X8 UF3681 M4 LW UF3710 FW M4 UPM5969 PHOTOELECTRIC SENSOR BRIDGE HEAD PHOTOELECTRIC SENSOR UPM6357 BRACKET 9-75...

  • Page 143: Uam0514 - Bridge Tape Roll Mount Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.13.2 UAM0514 – BRIDGE TAPE ROLL MOUNT ASSEMBLY 9-76...
  • Page 144 RSA2024-WAT-EU Illustrated Parts List UAM0514 – BRIDGE TAPE ROLL MOUNT ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UF1318 BHCS M8-1.25X20 UF0867 M8 LW UAM0025 CLUTCH MECHANISM RSA UF0454 HHCS M6-1X16 UF6363 M6 LW UF1828 M6 FW UPM6165 BRIDGE WELDMENT UF3680 M10 FW UF6371 M10 LW UF4310...

  • Page 145: Usm7585 - Top Tape Carriage Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.13.3 USM7585 – TOP TAPE CARRIAGE ASSEMBLY 9-78...
  • Page 146 RSA2024-WAT-EU Illustrated Parts List USM7585 – TOP TAPE CARRIAGE ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UPM4889 HANDLE UF3815 RET'G RING, ID 10 UAM0195 MANDREL HUB UPM5111 PANCAKE UPM5109 STEPPED SHAFT R.H. UF4503 SS BHCS M6-1 x 40mm UPM5200 BACK COVER UF6339 SS FW M4 UF3749...

  • Page 147: Uam0479 - Dancer Arm Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.13.3.1 UAM0479 – DANCER ARM ASSEMBLY 9-80...
  • Page 148 RSA2024-WAT-EU Illustrated Parts List UAM0479 – DANCER ARM ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UPM9802 BREAK PAD UPM6238 PIVOT ARM R.H. UPM4498 EXTENSION SPRING UF0062 M6-1.0-HNR UF1241EV BHCS M6-1.0×20L UF6336 F.W. PTFE, 13 x 19 x 1 mm UF6363 LW M6 UPH9059 PEEL OFF ROLLER ET 72 UPH0949...

  • Page 149: Uam0195 - Mandrel Hub Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.13.3.2 UAM0195 – MANDREL HUB ASSEMBLY 9-82...
  • Page 150 RSA2024-WAT-EU Illustrated Parts List UAM0195 – MANDREL HUB ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UPM5074 SPRAG, Mandrel UPH1468 COMPRESSION SPRING UPM5073 MANDREL HUB UPM0324 BEARING PULLEY UF0101 INTERNAL RETAINING RING, 42mm UF9164 M3-0.5×12L UF5404 FHCS M5-0.8×16L 9-83...

  • Page 151: Usm0907 - Top Water Bottle Unit Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.13.4 USM0907 – TOP WATER BOTTLE UNIT ASSEMBLY 9-84...
  • Page 152 RSA2024-WAT-EU Illustrated Parts List USM0907 – TOP WATER BOTTLE UNIT ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UPM5116 FRAME UPM5120 WT BOTTLE HOLDER UF3751 SS HHCS M6-1.0 x 16mm UF6411 SS LW M6 UF1890 FLAT WASHER 1/4 x 3/4 x 1/16 UPM4945 CUP HOLDER UPM5165...

  • Page 153: Wst1036 - Bottom Tape Head Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.14 WST1036 – BOTTOM TAPE HEAD ASSEMBLY 9-86...
  • Page 154 RSA2024-WAT-EU Illustrated Parts List WST1036 – BOTTOM TAPE HEAD ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. WST1028 DRIVETRAIN ASS'Y WST1021 RIGHT FRAME ASS'Y WET0165 COVER BELT UF6339 SS FW M4 UF7009 SS BHCS M4-0.7 x 8 UF3749 SS LW M4 WST1030 REAR TUCKING ARM ASS'Y WST0058 BOTTOM KNIFE ARM ASS'Y...

  • Page 155: Wst1023 - Heater Plate Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.14.1 WST1023 – HEATER PLATE ASSEMBLY 9-88...
  • Page 156 RSA2024-WAT-EU Illustrated Parts List WST1023 – HEATER PLATE ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. WET0148 WATER RESERVOIR SUPPORT WET0186 HEATER PAD WET0185 THERMOSTAT UF3717 SS HEX NUT M3-0.5 UF6350 SS FHCS M3-0.5 x 8 mm 9-89...

  • Page 157: Wst0059 - Pinch Roller Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.14.2 WST0059 – PINCH ROLLER ASSEMBLY 9-90...
  • Page 158 RSA2024-WAT-EU Illustrated Parts List WST0059 – PINCH ROLLER ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UF7019 SS E RET'G RING EXTERNAL, 10 mm UF6389 NYLON FW10.5 x16 x 0.5 WST0009 WT PINCH ROLLER SA WET0149 SHAFT, dia 10mm 9-91...

  • Page 159: Wst0058 - Bottom Knife Arm Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.14.3 WST0058 – BOTTOM KNIFE ARM ASSEMBLY WST0058 – BOTTOM KNIFE ARM ASSEMBLY 9-92...
  • Page 160 RSA2024-WAT-EU Illustrated Parts List ITEM PART NUMBER DESCRIPTION QTY. WPT0048 WT KNIFE ARM PIVOT SHAFT WPT0004 OILITE FLANGE BEARING 10mm WPT0075 KNIFE ARM RIGHT FRAME UF3761 SS FHCS M4-0.7 x 12mm UF3274 SS FHCS M4-0.7 x 8 mm WPT0049 WT Cutter Blade Support WPT0050 CUTTER BLADE UF3553...

  • Page 161: Wst1025 - Pinch Roller Cylinder Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.14.4 WST1025 – PINCH ROLLER CYLINDER ASSEMBLY 9-94...
  • Page 162 RSA2024-WAT-EU Illustrated Parts List WST1025 – PINCH ROLLER CYLINDER ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UPM4493 8OD x 5ID x 6 BUSHING WET0152 CLEVIS WET0151 CYLINDER UPH4906 M5 x 4mm STRAIGHT FITTING WET0150 CYLINDER SUPPORT UF4323 SS BHCS M4 - 0.7 x 20mm WET0153 PIVOT ARM 9-95...

  • Page 163: Wst0057 - Solenoid Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.14.5 WST0057 – SOLENOID ASSEMBLY 9-96...
  • Page 164 RSA2024-WAT-EU Illustrated Parts List WST0057 – SOLINOID ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. WET0019 MOUNTING PLATE WET0026 SOLENOID UF3710 FW M4 UF3681 LW M4 UF7009 SS BHCS M4-0.7 x 8 9-97...

  • Page 165: Wst1027 - Tape Guide Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.14.6 WST1027 – TAPE GUIDE ASSEMBLY 9-98...
  • Page 166 RSA2024-WAT-EU Illustrated Parts List WST1027 – TAPE GUIDE ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. WET0190 Upper Guide Plate UF6351 SS FHCS M4-0.7 x 6 mm WET0154 WT TAPE GUIDE WPT0044 STRIKER PLATE WET0156 TAPE GUIDE SUPPORT UF7030 BRASS WASHER 5.18x12x.28mm THK UF3717 SS HEX NUT M3-0.5 UF4518...

  • Page 167: Wst1026 - Guide Roller Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.14.7 WST1026 – GUIDE ROLLER ASSEMBLY 9-100...
  • Page 168 RSA2024-WAT-EU Illustrated Parts List WST1026 – GUIDE ROLLER ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. WET0188 GUIDE ROLLER, 40OD UPM4936 RUBBER RING WET0189 ROLLER, dia 17, 72L WET0187 SHAFT, 115L 9-101...

  • Page 169: Wst1028 - Drive Train Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.14.8 WST1028 – DRIVE TRAIN ASSEMBLY 9-102...
  • Page 170 RSA2024-WAT-EU Illustrated Parts List WST1028 – DRIVE TRAIN ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. WET0198 ONE WAY CLUTCH BEARING UF6300 Ret'g Ring External 12mm WET0196 SHAFT, 140L WET0195 DRIVE ROLLER TAPE ASSIST WET0183 MOTOR, 2GH 20K UF2213 SQUARE KEY, ONE ROUND END UF4316 BHCS M8-1.25 x 35mm WET0194...

  • Page 171: Wst1030 - Rear Tuckin Arm Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.14.9 WST1030 – REAR TUCKIN ARM ASSEMBLY 9-104...
  • Page 172 RSA2024-WAT-EU Illustrated Parts List WST1030 – REAR TUCKIN ARM ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UF3752 SS BHCS M6-1 x 30mm WET0202 COLLAR WET0201 ROLLER CORE WET0005 WIPE ARM ROLLER REAR WET0203 SHAFT, dia 10 WET0157 REAR WIPE ARM UF3804 SS SSS M3-0.5 x 12mm UPH4904 M5 x 4mm OD, FLOW CONTROL...

  • Page 173: Wst1032 - Control Valve Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.14.10 WST1032 – CONTROL VALVE ASSEMBLY 9-106...
  • Page 174 RSA2024-WAT-EU Illustrated Parts List WST1032 – CONTROL VALVE ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UPH1503 FEMALE/MALE ELBOW UPM8001 PLUG, G/18 WET0208 MANIFOLD UPH4903 FLAT MUFFLER G1/8 UPH4904 M5 x 4mm OD, FLOW CONTROL WET0210 MANIFOLD WET0211 PRESSURE REGULATOR UPH4905 M5 x 4mm ELBOW FITTING WET0209 VALVE UF6339...

  • Page 175: Wst1022 - Tape Shoe Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.14.11 WST1022 – TAPE SHOE ASSEMBLY 9-108...
  • Page 176 RSA2024-WAT-EU Illustrated Parts List WST1022 – TAPE SHOE ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. WST1048 MAIN ASS'Y UPH4540 FINGER UPH3706 SPRING BLADE UF3145 SS SHCS M3-0.5 x 6 mm WST1049 HINGE ASS'Y UF7010 SS BHCS M5 - 0.8 x 8 mm UF6340 SS FW M5 UF3274...

  • Page 177: Wst1031 - Water Pot Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.14.12 WST1031 – WATER POT ASSEMBLY 9-110...
  • Page 178 RSA2024-WAT-EU Illustrated Parts List WST1031 – WATER POT ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. WET0205 PRESSURE PLATE WET0167 TAPE GUIDE ENTERANCE WET0206 TAPE GUIDE EXIT WET0207 SHAFT, 6mm UF3804 M3-0.5 X 8mm SSS UF3759 SS SHCS M4-0.7 x 10mm UF3710 FW M4 WET0204 WATER POT...

  • Page 179: Wst1029 - Front Wipe Down Arm Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.14.13 WST1029 – FRONT WIPE DOWN ARM ASSEMBLY 9-112...
  • Page 180 RSA2024-WAT-EU Illustrated Parts List WST1029 – FRONT WIPE DOWN ARM ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. WET0203 SHAFT, dia 10 WET0201 ROLLER CORE WET0202 COLLAR UF6325 M6-1 x 20 BHCS WET0158 FRONT WIPE ARM UF3804 SS SSS M3-0.5 x 12mm UPH4905 M5 x 4mm ELBOW FITTING UPH4917...

  • Page 181: Wst1047 - Top Tape Head

    Illustrated Parts List RSA2024-WAT-EU 9.15 WST1047 – TOP TAPE HEAD 9-114...
  • Page 182 RSA2024-WAT-EU Illustrated Parts List WST1047 – TOP TAPE HEAD ITEM PART NUMBER DESCRIPTION QTY. WST1039 TAPE SHOE ASS'Y WST0059 PINCH ROLLER ASS'Y WST1045 FRONT TUCKING ARM ASS'Y WST1044 REAR TUCKING ARM ASS'Y WET0221 TOP COVER WST1038 RIGHT FRAME ASS'Y WET0213 COVER BELT UF3276 SS BHCS M5-0.8 x 6...

  • Page 183: Wst1037 - Left Frame Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.15.1 WST1037 – LEFT FRAME ASSEMBLY 9-116...
  • Page 184 RSA2024-WAT-EU Illustrated Parts List WST1037 – LEFT FRAME ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. WET0214 LEFT FRAME PLATE UF7009 SS BHCS M4-0.7 x 8 WET0164 EXTENSION SPRING UF3169 SS SHCS M5-0.8 x 16mm UF3276 SS BHCS M5-0.8 x 6 WPT0004 OILITE FLANGE BEARING 10mm WET0216 ADAPTOR, 30L...

  • Page 185: Wst1038 - Right Frame Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.15.2 WST1038 – RIGHT FRAME ASSEMBLY 9-118...
  • Page 186 RSA2024-WAT-EU Illustrated Parts List WST1038 – RIGTH FRAME ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UF7007 SS HEX NUT M5-0.8 WET0182 TAPE SHOE LOCATOR UF3274 SS FHCS M4-0.7 x 8 mm UF1250 BHCS M6-1 x 16 WPT0004 OILITE FLANGE BEARING 10mm UF7009 SS BHCS M4-0.7 x 8 WET0216...

  • Page 187: Wst0060 - Top Knife Arm Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.15.3 WST0060 – TOP KNIFE ARM ASSEMBLY 9-120...
  • Page 188 RSA2024-WAT-EU Illustrated Parts List WST0060 – TOP KNIFE ARM ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. WPT0004 OILITE FLANGE BEARING 10mm WPT0075 KNIFE ARM RIGHT FRAME SHOULDER SCREW M5 x 15L UF2215 SHOULDER UF3761 SS FHCS M4-0.7 x 12mm UF3274 SS FHCS M4-0.7 x 8 mm WPT0049 WT Cutter Blade Support WPT0048...

  • Page 189: Wst1035 - Cover With Handle

    Illustrated Parts List RSA2024-WAT-EU 9.15.4 WST1035 – COVER WITH HANDLE 9-122...
  • Page 190 RSA2024-WAT-EU Illustrated Parts List WST1035 - COVER WITH HANDLE ITEM PART NUMBER DESCRIPTION QTY. WET0234 HANDLE WET0233 COVER PLATE UF7011 SS BHCS M5-0.8 X 12mm 9-123...

  • Page 191: Wst1040 - Top Tape Guide

    Illustrated Parts List RSA2024-WAT-EU 9.15.5 WST1040 – TOP TAPE GUIDE 9-124...
  • Page 192 RSA2024-WAT-EU Illustrated Parts List WST1040 – TOP TAPE GUIDE ITEM PART NUMBER DESCRIPTION QTY. WET0190 Upper Guide Plate UF6351 SS FHCS M4-0.7 x 6 mm WPT0044 STRIKER PLATE WET0156 TAPE GUIDE SUPPORT UF7030 BRASS WASHER 5.18x12x.28mm THK UF3717 SS HEX NUT M3-0.5 UF4518 SS BHCS M3 - 0.5 x 6 WET0237...

  • Page 193: Wst1043 - Drive Train Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.15.6 WST1043 – DRIVE TRAIN ASSEMBLY 9-126...
  • Page 194 RSA2024-WAT-EU Illustrated Parts List WST1043 – DRIVE TRAIN ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UF3735 SS HNR M8-1.25 UF3643 SS FW M8 UPH4919 BALL BEARING, 10ID, 35OD, 11t WET0193 SPROCKET GEAR WET0229 SPACER, dia 16, 4L UF4316 BHCS M8-1.25 x 35mm WET0230 MOTOR PLATE UF2213...

  • Page 195: Wst1044 - Rear Tucking Arm Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.15.7 WST1044 – REAR TUCKING ARM ASSEMBLY 9-128...
  • Page 196 RSA2024-WAT-EU Illustrated Parts List WST1044 – REAR TUCKING ARM ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. WET0201 ROLLER CORE WET0202 COLLAR UF1250 BHCS M6-1 x 16 UF2214 ROUND KEY UPH4849 ROTORY AIR CYLINDER UF6340 SS FW M5 UF7021 SS LW M5 UF7011 SS BHCS M5-0.8 X 12mm WET0231...

  • Page 197: Wst1045 - Front Tucking Arm Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.15.8 WST1045 – FRONT TUCKING ARM ASSEMBLY 9-130...
  • Page 198 RSA2024-WAT-EU Illustrated Parts List WST1045 – FRONT TUCKING ARM ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. WET0201 ROLLER CORE WET0202 COLLAR UF1250 BHCS M6-1 x 16 UPH4917 ROTARY AIR CYLINDER UF7011 SS BHCS M5-0.8 X 12mm UF7021 SS LW M5 UF6340 SS FW M5 WET0232 BRACKET...

  • Page 199: Wst1042 - Pneumatic Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.15.9 WST1042 – PNEUMATIC ASSEMBLY 9-132...
  • Page 200 RSA2024-WAT-EU Illustrated Parts List WST1042 – PNEUMATIC ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UPH1504 COUPLING PLUG UPH4903 FLAT MUFFLER G1/8 WET0208 MANIFOLD UF3710 FW M4 UF3749 SS LW M4 UF4308 SHCS M4-0.7 x 25mm WET0209 VALVE UPM8001 PLUG, G/18 WET0228 PLATE UPH4905 M5 x 4mm ELBOW FITTING...

  • Page 201: Wst1039 - Tape Shoe Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.15.10 WST1039 – TAPE SHOE ASSEMBLY 9-134...
  • Page 202 RSA2024-WAT-EU Illustrated Parts List WST1039 – TAPE SHOE ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. WET0225 SHAFT, 90L WET0191 HEX ADAPTER WET0161 SLEEVE TUBE UPH4613 KNIFE ARM BUMPER 6"TH UF6340 SS FW M5 UF7011 SS BHCS M5-0.8 X 12mm WST1050 MAIN ASS'Y WET0177 SHAFT, dia 10, 100L UF7021...

  • Page 203: Uam0536 - Column Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.16 UAM0536 – COLUMN ASSEMBLY 9-136...
  • Page 204 RSA2024-WAT-EU Illustrated Parts List UAM0536 – COLUMN ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UAM0529 COLUMN BRIDGE MOUNT CART ASSEMBLY UPM4960 COLUMN CAP UF5400 FHCS M5-0.8X12 UPM6216 FLEXIBLE COUPLING M18 UPM6343 AIR CYLINDER PNEUMATIC COUPLER, SMC UPM6344 AIR CYLINDER PNEUMATIC COUPLER, SMC UPM6345 AIR CYLINDER PNEUMATIC COUPLER, SMC UPM6342...

  • Page 205: Uam0529 - Column Bridge Mount Cart Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.16.1 UAM0529 – COLUMN BRIDGE MOUNT CART ASSEMBLY 9-138...
  • Page 206 RSA2024-WAT-EU Illustrated Parts List UAM0529 – COLUMN BRIDGE MOUNT CART ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UF9154 SHCS M5-0.8 X 12 UF6302 RETAINING RING 6MM SHAFT UPM5801 ROLLER WHEEL UPM6351 COLUMN CART ROLLER HUB UF5927 M5 CW UPM6353 COLUMN BRIDGE MOUNT CART WELDMENT UPM6352 COLUMN CART ROLLER HUB UPM6357...

  • Page 207: Uam0503 - Electrical Box

    Illustrated Parts List RSA2024-WAT-EU 9.17 UAM0503 – ELECTRICAL BOX 9-140...
  • Page 208 RSA2024-WAT-EU Illustrated Parts List UAM0503 – ELECTRICAL BOX ITEM PART NUMBER DESCRIPTION QTY. UF0099 SHCS M8-1.25×30L UF3640 LW M8 UF0113 M8 FW UPM6177 HMI, SCREEN UPM6174 ELEC. CAB. MOUNT BAR UPM6173 ELECTRICAL CABNET UPM6175 ELEC. CAB. COVER UF1827 M5 FW UF7021 LW M5 UF7003...
  • Page 209 Illustrated Parts List RSA2024-WAT-EU UF3749 LW M4 UF3710 M4 FW UF0063 LOCK-NUT UPM6185 TRANSFORMER UPM6186 FILTER UPM4912 POWER SUPPLY 240W UPM6187 SAFETY MODULE UPM6249 RAIL, 160L ELECTROMAGNETIC CONTACTOR UPM6189 (AC110V) UPM4914 MOTOR OVERLOAD RELAYS 9-142...
  • Page 210 RSA2024-WAT-EU Illustrated Parts List THIS PAGE INTENTIONALLY LEFT BLANK 9-143...

  • Page 211: Uam0025 - Clutch Mechanism

    Illustrated Parts List RSA2024-WAT-EU 9.18 UAM0025 – CLUTCH MECHANISM 9-144...
  • Page 212 RSA2024-WAT-EU Illustrated Parts List UAM0025 – CLUTCH MECHANISM ITEM PART NUMBER DESCRIPTION QTY. UPM2485 ADJUSTMENT RING UF6363 LW M6 UF6414 SS BHCS M6-1 x 16mm UPM5908 CM PIVOT ARM UPM5904 CM RIGHT MOUNT BRACKET UF3637 HNR M6-1.0 UF4236 SHCS M6-1 X 30mm UAM0034 PINCH ROLLER ASSEM UPM5999...

  • Page 213: Wst1048 - Rsa Wat Bottom T.h. Main Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.19 WST1048 – RSA WAT BOTTOM T.H. MAIN ASSEMBLY 9-146...
  • Page 214 RSA2024-WAT-EU Illustrated Parts List WST1048 – RSA WAT BOTTOM T.H. MAIN ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UF4514 SS M4-0.7 x 10 FHCS WEWT0176 SHAFT, dia 6, 90L WET0179 SPACER, dia 10, 12L WET0175 STOP BEARING UF3725 SHCS M4-0.7 x 6mm UF7010 SS BHCS M5 - 0.8 x 8 mm WET0168...

  • Page 215: Wst1049 - Rsa Wat Bottom T.h. Hinge Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.20 WST1049 – RSA WAT BOTTOM T.H. HINGE ASSEMBLY 9-148...
  • Page 216 RSA2024-WAT-EU Illustrated Parts List WST1049 – RSA WAT BOTTOM T.H. HINGE ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UF4514 SS M4-0.7 x 10 FHCS WET0174 INSIDE BRACKET MIRROR WET0178 SHAFT, dia 6, 81L WET0180 SPACER, dia 10, 10L WET0181 SPACER, dia 10, 6L UF3725 SHCS M4-0.7 x 6mm WET0173...

  • Page 217: Wst1050 - Rsa Wat Top T.h. Main Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.21 WST1050 – RSA WAT TOP T.H. MAIN ASSEMBLY 9-150...
  • Page 218 RSA2024-WAT-EU Illustrated Parts List WST1035 - COVER WITH HANDLE ITEM PART NUMBER DESCRIPTION QTY. UF7024 FHCS M5-0.8 x 8 mm UF0890EV M4-0.7 x 10 FHCS WEWT0176 SHAFT, dia 6, 90L WET0179 SPACER, dia 10, 12L WET0223 MAIN BRACKET WET0175 STOP BEARING UPM4936 RUBBER RING WET0235...

  • Page 219: Wst1051 - Rsa Wat Top T.h. Hinge Assembly

    Illustrated Parts List RSA2024-WAT-EU 9.22 WST1051 – RSA WAT TOP T.H. HINGE ASSEMBLY 9-152...
  • Page 220 RSA2024-WAT-EU Illustrated Parts List WST1051 – RSA WAT TOP T.H. HINGE ASSEMBLY ITEM PART NUMBER DESCRIPTION QTY. UF0890EV M4-0.7 x 10 FHCS WET0178 SHAFT, dia 6, 81L WET0180 SPACER, dia 10, 10L WET0236 TEFLON GUIDE A WET0226 INSIDE BRACKET WET0181 SPACER, dia 10, 6L WET0227 INSIDE BRACKET MIRROR...

Table of Contents
