Enclosed is a copy of the Installation and Maintenance Manual for the original product. This
supplement serves as a temporary modifier of that manual for the i Series e product. Please
follow the instructions in the manual except where modified below.
Page 9, Paragraph 1 – The e Series has two additional control cables that plug into the rear center
of the control module tray. One is a six-pin rectangular connector whose cable routes through
the right wall. The other is a five-pin in- line connector whose cable routes down underneath the
control module tray. Both cables must also be disconnected before removing the control module
tray.
Page 12, Label Part Numbers – The label part numbers for i Series E and the associated
explanation are as follows:
Part Number
LBL-31084-00
LBL-31085-00
LBL-31346-00
LBL-31247-00
Standard racks are shipped from the factory in the phase balanced configuration. This
places dimmers 1 and 2 at the top of the rack and the top of the phase A bus, dimmers 3
and 4 one-third of the way down the rack at the top of the phase B bus, and dimmers 5
and 6 two-thirds of the way down the rack at the top of the phase C bus. In this
configuration "phase balanced" labels should be selected. If the rack is full of dimmers
you may want to have them arranged sequentially from top to bottom. The rack is easily
configured for this sequential arrangement and the "sequential" labels should be selected.
Page 13, Table 3 – The dimmer module part numbers for e Series dimmer racks must include an
"E" suffix. Constant module part numbers do not require the "E".
Page 16, Table 4 – The dimmer module part numbers for e Series dimmer racks must include an
"E" suffix.
Page 17, Paragraph 2 – There are no PC Serial control conductors in the e Series. There are,
however, 0 – 10VDC Analog inputs.
i Series e Installation Supplement
LIT-30955-01
i 48e and i 96e Dimmer Rack
Installation and Maintenance Manual Supplement
Rack Type
i96e phase balanced
i96e sequential
i48e phase balanced
i48e sequential
Page 1 of 4
Advertisement
Related Manuals for Leviton i 48e
Summary of Contents for Leviton i 48e
- Page 1 Page 17, Paragraph 2 – There are no PC Serial control conductors in the e Series. There are, however, 0 – 10VDC Analog inputs. i Series e Installation Supplement LIT-30955-01 i 48e and i 96e Dimmer Rack Rack Type i96e phase balanced i96e sequential...
- Page 2 Page 17, Figure 16 – SW1 has been replaced with jumpers JP3 and JP4 immediately under TB3 in the e Series. An additional terminal block TB4 has been added immediately to the left of TB1 for the Analog inputs. Page 17, Last Paragraph – The Network connector is a pair of RJ45 telephone-type connectors. Page 18, Paragraph 3 –...
- Page 3 for “panic” operation in order to facilitate testing. Call Colortran Field Service for further instructions on how to program the “panic” feature. Observe the second “Caution” notice on page 25. Page 27, Paragraph 1 – The part number for the e Series control module is 4-0311E. The same module is used for both 120V and 230V systems.
- Page 4 Luma-Net Control Signal Installation Requirements For i Series e dimmer racks which require the termination of a Luma-Net control run, follow these instructions. Connection The Luma-Net link connects to the backplane of the rack on TB1 as follows: Signal Luma -Net 3 Terminal Rem + Rem -...
