- Page 1 Installation and Operating Guide MDS D IMMER ABINETS WITH ONTROL ® Software revision 1.01 and above...
-
Page 2: Table Of Contents
Programming Buttons ... 8 LED Indicators ... 9 Navigation Buttons... 9 Fluorescent Dimming ... 9 0-10 VDC Controlled Ballasts ... 9 Two-Wire Fluorescent Ballasts ... 10 Other Ballasts... 10 Leviton MDS Dimmer Cabinets with Luma-Net Control NSTALLATION Installation and Operating Guide... - Page 3 Dimmer Types ... 13 Changing a Module Type... 14 Assigning Luma-Net and/or DMX512 Channels ... 15 Assigning Numbers Automatically... 15 Assigning Individual Channels... 16 Specifications ... 17 ARRANTY NFORMATION Warranty... 18 Leviton MDS Dimmer Cabinets with Luma-Net Control Installation and Operating Guide ROGRAMMING...
-
Page 4: Overview
The cabinet is designed for side or bottom feed. Top feed cabinets are available on request. Leviton MDS Dimmer Cabinets with Luma-Net Control Installation and Operating Guide Page 1 of 18... -
Page 5: Freestanding
• Main feed wiring • Load wiring • Remote control wiring • Configuration of each module with the type of load connected and any ballast control wiring Leviton MDS Dimmer Cabinets with Luma-Net Control Installation and Operating Guide Page 2 of 18... -
Page 6: Modules
Make sure that any dimmer ballasts are correctly wired Verify the main feed wiring Verify the load wiring Verify the remote control wiring Verify the configuration of each module Leviton MDS Dimmer Cabinets with Luma-Net Control Installation and Operating Guide Page 3 of 18... -
Page 7: Initial Setup And Installation
Surface-mounted units include a 1-in. flange top and bottom across the full width of the dimmer cabinet with prepunched mounting holes. Attach the cabinet to the wall as necessary, keeping in mind the weight to be supported. Leviton recommends that cabinet mounting hardware reaches through the wall and attaches to the wall studs. -
Page 8: Control Wiring
Check with the manufacturer of these transformers for suitability before connecting them to dimmers in this system. It is generally recommended that a transformer with an Leviton MDS Dimmer Cabinets with Luma-Net Control Installation and Operating Guide Page 5 of 18... -
Page 9: Turn On
If the dimmer modules are driving the wrong load circuits, damage can occur to certain types of dimmer ballasts. Some ballasts are adversely affected if the dimmed and switched connections are reversed. Leviton MDS Dimmer Cabinets with Luma-Net Control Installation and Operating Guide Page 6 of 18... -
Page 10: Digital Control Panel
Luma-Net® III The most common input is Luma-Net III, a Leviton protocol, that sends serial digital data over a twisted pair of communication (data) wires. With this system, controls can be located up to 2000 ft from the dimming cabinet. The two data wires terminate on REM+ and REM- of the Luma-Net Terminal Block. -
Page 11: Readouts And Indicators
Many parameters can be modified using the LCD screen and a password (setup code), however these modifications should be made by a qualified factory technician. Some of these options are covered in Configuration and Programming. Leviton MDS Dimmer Cabinets with Luma-Net Control PHASE LOSS FULL BRIGHT LUMANET... -
Page 12: Led Indicators
The maximum number of ballasts that can be controlled on any one circuit is 24. This limitation is determined by the amount of control current that the circuit board can handle. Leviton MDS Dimmer Cabinets with Luma-Net Control Installation and Operating Guide , UP... -
Page 13: Two-Wire Fluorescent Ballasts
A minimum light level must be set for the Lutron ballasts, depending on the particular ballast being used. Operating the ballasts below that minimum level can result in damage to the ballast and lamps. Leviton MDS Dimmer Cabinets with Luma-Net Control Installation and Operating Guide Page 10 of 18... -
Page 14: Configuration And Programming
(Digital Main Control Module), enabling the dimmers in this system to dim and control virtually any incandescent or fluorescent lighting load. It is possible to use three different types of control input signals to this control card. Leviton prepares complete and detailed submittal drawings for each dimming system order, and requires approval of these prints for each job before it is released to production. -
Page 15: Three More Module Configurations
Press the SELECT button. The LCD display shows how the first half of the first dual dimmer is programmed. Leviton MDS Dimmer Cabinets with Luma-Net Control button located under the LCD display. button a second time. The LCD display shows MENU MODULE STATUS. -
Page 16: Dimmer Types
The ballast requires only two power wires for control; a dimmed line and a neutral. Leviton MDS Dimmer Cabinets with Luma-Net Control Module number Portion of dimmer set to this percent brightness... -
Page 17: Changing A Module Type
Press the Select/Save button to access that channel of the module, or press the UP module. Leviton MDS Dimmer Cabinets with Luma-Net Control button, you can step through each of the nine button until Menu Setup appears on the LCD display. -
Page 18: Assigning Luma-Net And/Or Dmx512 Channels
DOWN address. Press the Select/Save button. The flashing moves from the description to the number. Leviton MDS Dimmer Cabinets with Luma-Net Control or DOWN buttons to scan through the functions. or DOWN buttons to select a dimmer type button to move on to another channel, button until the LCD display shows Menu Setup. -
Page 19: Assigning Individual Channels
Press the Select/Save button to store the new address. The flashing returns to the description. Push the Cancel/Clear button five times to return to the top level menu. Leviton MDS Dimmer Cabinets with Luma-Net Control and DOWN button until the LCD display shows Menu Setup. -
Page 20: Specifications
Operating efficiency Completely wired and tested as a system before shipment UL and cUL Listed Leviton MDS Dimmer Cabinets with Luma-Net Control Installation and Operating Guide Virtually unlimited; you continue to add more cabinet sections 50" high x 11" deep; width as required 90”... -
Page 21: Warranty Information
Leviton is not responsible for removing or replacing equipment on the job site, and will not honor charges for such work. Leviton will not be responsible for any loss of use time or subsequent damages should any of the equipment fail during the warranty period, but agrees only to repair or replace defective equipment returned to its plant in Tualatin, Oregon.
