Model No. WLTL39110
Serial No.
Write the serial number in the
space above for future reference.
Serial
Number
Decal
QUESTIONS?
If you have questions, or if there
are missing parts, we will guaran-
tee complete satisfaction through
direct assistance from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
400 CS
®
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
Patent Pending

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WLTL39110 and is the answer not in the manual?

Questions and answers

Summary of Contents for Weslo WLTL39110

  • Page 1 ® 400 CS Model No. WLTL39110 USER'S MANUAL Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? If you have questions, or if there are missing parts, we will guaran- tee complete satisfaction through direct assistance from our factory.
  • Page 2: Table Of Contents

    120 volts AC and 15 amps. To purchase a surge suppressor, see 6. Keep children under the age of 12 and pets your local WESLO dealer or call 1-800-999- away from the treadmill at all times. 3756 and order part number 146148.
  • Page 3 14. Never start the treadmill while you are stand- (20 kg) to raise, lower, or move the treadmill. ing on the walking belt. Always hold the handrails while using the treadmill. 19. When folding or moving the treadmill, make sure that the storage latch is fully closed. 15.
  • Page 4: Before You Begin

    The model you’re not exercising, the CADENCE 400 CS can be number of the treadmill is WLTL39110. The serial folded up, requiring less than half the floor space of number can be found on a decal attached to the tread- other treadmills.
  • Page 5: Assembly

    ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included allen wrench and your own phillips screwdriver , an adjustable wrench , and wire cutters Note: The underside of the treadmill walking belt is coated with high-performance lubricant.
  • Page 6 3. Refer to the inset drawing. If there is a plastic tie through the Cage Nut (70) in the Right Handrail (88), remove the plastic tie. Feed the Wire Harness (21) in the right Upright (11) up through the bracket on the Right Handrail as shown.
  • Page 7: Operation And Adjustment

    To purchase a surge suppressor, see your local The temporary adapter should be used only until a WESLO dealer or call toll-free 1-800-999-3756 and properly grounded outlet (drawing 1) can be installed order part number 146148. Use only a single-outlet by a qualified electrician.
  • Page 8 CONSOLE DIAGRAM Note: If there is a thin sheet of clear plastic on the face of the console, remove it before operating the console. CAUTION: Before operating the console, read the following precautions. • Do not stand on the walking belt when turn- ing on the power.
  • Page 9 Follow the steps below to operate the console. CALS/FAT CALS/ dis- play—This display shows the approximate Insert the key into the power switch. numbers of calories and fat calories you Inserting the key will have burned. (See FAT not turn on the dis- BURNING on page 14.) plays.
  • Page 10: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, unplug the power cord. CAUTION: You must be able to safely lift 45 pounds (20 kg) in order to raise, lower, or move the treadmill. 1.
  • Page 11 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left thumb, press the storage latch and hold it. Pivot the treadmill until the frame is past the storage latch.
  • Page 12: Trouble-Shooting

    MAINTENANCE AND TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a.
  • Page 13 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge sup- pressor (TVSS). The surge suppressor must have a UL suppressed voltage rating of 400 volts or less and a minimum surge dissipation of 450 joules.
  • Page 14: Conditioning Guidelines

    CONDITIONING GUIDELINES the first few minutes does your body begin to use stored fat calories for energy. If your goal is to burn fat, WARNING: Before beginning adjust the speed and incline of the treadmill until your this or any exercise program, consult your heart rate is near one of the lower two numbers in your physician.
  • Page 15 EXERCISE FREQUENCY tween workouts. After a few months of regular exer- cise, you may complete up to five workouts each week To maintain or improve your condition, complete three if desired. The key to success is to make exercise a workouts each week, with at least one day of rest be- regular and enjoyable part of your everyday life.
  • Page 16 REMOVE THIS EXPLODED DRAWING AND PART LIST FROM THE MANUAL Save this EXPLODED DRAWING and PART LIST for future reference. Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of the User’s Manual.
  • Page 17 PART LIST—Model No. WLTL39110 R0801A Key No. Qty. Description Key No. Qty. Description Left Handrail Power Cord Grommet Key/Clip Circuit Breaker Incline Leg Pivot Bolt Frame Pivot Washer Battery Cover Frame Pivot Bolt Foot Grip (Left) Latch Decal Lift Motor...
  • Page 18 EXPLODED DRAWING—Model No. WLTL39110 R0801A...
  • Page 19: Ordering Replacement Parts

    • The KEY NUMBER and DESCRIPTION of the desired part(s) (see the PART LIST and the EXPLODED DRAWING in the center of this manual). WESLO is a registered trademark of ICON Health & Fitness, Inc. LIMITED WARRANTY ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.
