Model No. WCTL39110
Serial No.
Write the serial number in the
space above for future reference.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you have
questions, or if there are missing
parts, please call:
1-888-936-4266
Mon.–Fri. 8h00 until 18h30 EST
(excluding holidays).
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
400 CS
®
USER'S MANUAL
Visit our website at
www.weslo.com
Advertisement
Table of Contents
Related Manuals for Weslo WCTL39110
Summary of Contents for Weslo WCTL39110
- Page 1 400 CS Model No. WCTL39110 Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing...
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN . - Page 3 14. Never start the treadmill while you are stand- ing on the walking belt. Always hold the handrails while using the treadmill. 15. The treadmill is capable of high speeds. Adjust the speed in small increments to avoid sudden jumps in speed. 16.
-
Page 4: Before You Begin
To help us assist you, please note the product model number and serial number before call- ing. The model number is WCTL39110. The serial number can be found on a decal attached to the tread- mill (see the front cover of this manual for the location). -
Page 5: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included allen wrench and your own phillips screwdriver cutters Note: The underside of the treadmill walking belt is coated with high-performance lubricant. - Page 6 3. See drawing 3a. If there is a plastic tie in the Cage Nut (70) in the Right Handrail (88), remove the plastic tie. Pull 15cm (6 in) of the Wires (21) out of the right Upright (11). Route the Wires into the bracket on the Right Handrail and out of the upper end as shown.
-
Page 7: To Plug In The Power Cord
(see drawing 1 at the right). To purchase a surge suppressor, see your local WESLO dealer or call toll-free 1-888-936-4266 and order part number 146148. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge suppressor (TVSS). -
Page 8: Console Diagram
CONSOLE DIAGRAM CAUTION: Before operating the console, read the following precautions. • Do not stand on the walking belt when turn- ing on the power. • Always wear the clip (see the drawing at the lower right) while using the treadmill. When the key is removed from the console, the walking belt will stop. - Page 9 Follow the steps below to operate the console. Insert the key fully into the console. Inserting the key will not turn on the dis- plays. The displays will turn on when the ON/RESET button is pressed or when the walking belt is started. Note: If you just installed batteries, the displays will already be on.
- Page 10 HOW TO SELECT KILOMETRES AND MILES The console can display distance and speed in either kilometres or miles. To change the unit of measurement, first UNPLUG THE POWER CORD. Next, remove the screws attaching the console to the console base. Lift the console a few inches, being careful not to pull on the wires, and turn the console over.
-
Page 11: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, unplug the power cord. Caution: You must be able to safely lift 20 kg (45 lbs) in order to raise, lower, or move the treadmill. 1. -
Page 12: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-888- 936-4266, Monday through Friday 8h00 until 18h30 Eastern Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a. - Page 13 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge sup- pressor (TVSS). The surge suppressor must have a UL suppressed voltage rating of 400 volts or less and a minimum surge dissipation of 450 joules.
-
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for in- dividuals over the age of 35 or individuals with pre-existing health problems. The pulse sensor is not a medical device. Various factors, including the user's move- ment, may affect the accuracy of heart rate readings. -
Page 15: Ordering Replacement Parts
To order replacement parts, call toll-free 1-888-936-4266, Monday through Friday 8h00 until 18h30 Eastern Time (excluding holidays). When ordering parts, please be prepared to give the following information: • The MODEL NUMBER OF THE PRODUCt (WCTL39110) • The NAME OF THE PRODUCT (WESLO •... -
Page 16: Limited Warranty
Electronic Features Magazine Ads Product Design Product Innovation Other Features 8) Did you consider purchasing fitness equipment from another WESLO is a registered trademark of ICON IP, Inc. Part No. 211201 R0704A ® PRODUCT WARRANTY REGISTRATION PHONE: POSTCODE: SERIAL NO. - Page 17 REMOVE THIS EXPLODED DRAWING AND PART LIST FROM THE MANUAL Save this EXPLODED DRAWING and PART LIST for future reference. Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of the User’s Manual.
- Page 18 PART LIST—Model No. WCTL39110 Key No. Qty. Description Left Handrail Key/Clip Incline Leg Pivot Bolt Battery Cover Foot Grip (Left) Lift Motor Rear Roller Speed Potentiometer Speed Control Knob Console Assembly Upright Motor Belt Console Screw Storage Latch Controller Screw 8”...
- Page 19 EXPLODED DRAWING—Model No. WCTL39110 R0704A...
