Summary of Contents for Weslo Cadence Sl 20

Page 1 CUSTOMER HOT LINE: 1-800-999-3756 Mon.ÐFri., 6 a.m.Ð6 p.m. MST CAUTION Visit our website at Read all precautions and instruc- www.weslo.com tions in this manual before using this equipment. Save this manual new products, prizes, for future reference. fitness tips, and much more!
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN .
Page 3 14. Never start the treadmill while you are stand- 19. Do not change the incline of the treadmill by ing on the walking belt. Always hold the placing objects under the treadmill. handrails while using the treadmill. 20. When folding or moving the treadmill, make 15.
Page 4: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the WESLO ¨ CADENCE SL20 please call our Customer Service Department toll-free treadmill. The CADENCE SL20 treadmill combines ad- at 1-800-999-3756, Monday through Friday, 6 a.m. vanced technology with innovative design to let you until 6 p.m.
Page 5: Assembly
ASSEMBLY Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Refer to the drawings below to identify the small parts used in assembly. Assembly requires the included allen wrench and your own phillips screw- driver , two adjustable wrenches...
Page 6 3. Cut the plastic tie holding the cage nut in the upper end of the Left Handrail (2). Position the Left Handrail (2) on the left Upright (14). The lower end of the Left Handrail should be on the outside of the Extension Leg (41) as shown.
Page 7: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT electric shock. This product is equipped with a cord having an equipment-grounding conductor and a Your treadmill features a walking belt coated with grounding plug. Plug the power cord into a surge PERFORMANT LUBE , a high-performance lubricant.
Page 8 DIAGRAM OF THE CONSOLE Speed Control Monitor Display Clip Pulse Sensor Incline Control CAUTION: Before operating the ¥ Adjust the speed in small increments. console, read the following precautions. ¥ The training zones marked around the speed ¥ Do not stand on the walking belt when turning control are general guidelines only.
Page 9 Reset the console and start the walking belt. Measure your pulse, if desired. Turn the speed To measure your Pulse Sensor control to the RESET pulse, stand on position. Note: Each the foot rails and time the walking belt place your is stopped, the thumb on the speed control must...
Page 10: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Unplug the power cord. Caution: You must be able to safely lift 45 pounds (20 kg) in order to raise, lower, or move the treadmill. 1. Hold the treadmill with your hands in the locations shown at the right.
Page 11 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left thumb, press the storage latch and hold it. Pivot the treadmill until the frame and foot rail are past the storage latch.
Page 12: Maintenance And Trouble-Shooting
MAINTENANCE AND TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a.
Page 13 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a UL-listed surge protector, rated at 15 amps, with a 14-gauge cord of five feet or less in length. b. If the walking belt is overtightened, treadmill perfor- 2ÓÐ3Ó...
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES Fat Burning WARNING: Before beginning this To burn fat effectively, you must exercise at a relatively or any exercise program, consult your physi- low intensity level for a sustained period of time. During cian. This is especially important for individu- the first few minutes of exercise, your body uses easily als over the age of 35 or individuals with pre- accessible...
Page 15 Exercise Frequency tween workouts. After a few months, you may com- plete up to five workouts each week if desired. The key To maintain or improve your condition, complete three to success is to make exercise a regular and enjoyable workouts each week, with at least one day of rest be- part of your everyday life.
Page 16 PART LISTÑModel No. WLTL33091 R0100A Key No. Qty. Description Key No. Qty. Description Key/Clip Cable Tie Clamp Left Handrail Motor Belly Pan Cage Nut Screw Incline Control 8Ó Wire Tie Rear Isolator Screw Right Handrail Console Base Incline Wire Harness Speed Control Knob 3 1/2Ó...
Page 17 EXPLODED DRAWINGÑModel No. WLTL33091 R0100A...
Page 18: Ordering Replacement Parts
ING in the center of this manual). If possible, place the treadmill near your telephone for easy reference when calling. WESLO is a registered trademark of ICON Health & Fitness, Inc. LIMITED WARRANTY ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.
