VeriFone P200 Instruction Manual

Electrical
Separate Power Sources
Please ensure you review the power output of any device you connect to the P200 and P200 Plus.
NOTE: P200 and P200 Plus are intended to be provided with a listed power supply module, which evaluated as a Limited Power Source or PS2 or equivalent and having an output rating as
follows:
For P200: 5-12V DC, minimum 500mA, Tma 40°C. For P200 Plus: 7-12V DC, minimum 1.0A, Tma 40°C.
Location – Electrical Considerations
WARNING! This device contains sensitive electronic components that can be permanently damaged if exposed to excessive shock, electrical interference or vibration.
AVERTISSEMENT! Cet appareil contient des composants électroniques sensibles qui peuvent être endommagés de façon permanente si elle est exposée à des chocs excessifs, des
interférences électriques ou des vibrations.
CAUTION: Due to the risk of electric shock or damage to the terminal, do not use this equipment near a water source, for example near a bathtub, washbowl, kitchen sink. or a laundry
tub, in a wet basement or near a swimming pool. Likewise, avoid using this product during thunderstorms causing power cuts. Avoid placing the terminal near electrical
devices or other units that may cause large voltage fluctuations or electrical interference, such as air conditioners, neon signs, high frequency safety devices, or electrical
equipment.
ATTENTION: Du fait d'un risque d'électrocution ou d'une détérioration du terminal, ne pas utiliser cet équipement près d'une source d'eau, par exemple près d'une baignoire, d'un
lavabo, d'un évier de cuisine ou d'un bac de lavage, dans un sous-sol humide ou à proximité d'une piscine. De même, éviter d'utiliser ce produit lors des orages
provoquant des coupures électriques. Éviter de placer le terminal à proximité d'appareils électriques ou autres unités pouvant entraîner des fluctuations de tension
importantes ou des interférences électriques, tels que les climatiseurs, enseignes au néon, dispositifs de sécurité à haute fréquence ou équipements électriques.
Equipment
Location – Environmental Considerations
Do not plug the power pack into an outdoor outlet or operate the terminal outdoors. It is not waterproof or dustproof and is for indoor use only. Any damage to the unit from exposure to rain or
dust may void your warranty. Do not use the terminal where there is high heat, dust, humidity, moisture, or caustic chemicals or oils. Keep the terminal away from direct sunlight and anything that
radiates heat, such as a stove or a motor.
WARNING! Your POS terminal contains sensitive electronic components that can be permanently damaged if exposed to excessive shock or vibration. To minimize the risk of damage
to your terminal, avoid dropping your terminal and operating it in high-shock and high-vibration environments. Do not store the terminal where prolonged exposure to
extreme temperature can occur, because it can cause permanent damage. Do not expose the terminal to water. Contact with water can cause this unit to malfunction.
AVERTISSEMENT! Votre terminal de point de vente contient des composants électroniques sensibles, susceptibles de subir des dommages définitifs en cas d'exposition à des chocs ou à des
vibrations excessives. Pour minimiser le risque de dommages pour votre terminal, éviter de le faire tomber ou de l'exposer à des environnements pouvant provoquer des
chocs et des vibrations excessives. Ne pas stocker le terminal dans des lieux susceptibles d'entraîner une exposition prolongée à des températures extrêmes, du fait des
dommages définitifs que cette situation peut provoquer. Ne pas exposer le terminal à l'eau. Un contact avec de l'eau peut provoquer un dysfonctionnement de l'unité.
Coin Cell Instruction
Dispose of the battery in accordance with all national, state, and local laws and regulations as regionally required. Some batteries may be recycled and may be accepted for disposal at local
recycling centers.
CAUTION: There is risk of explosion if the battery is replaced by an incorrect type.
ATTENTION: Il existe un risque d'explosion si la batterie est remplacée par un modèle incompatible.
• Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas.
• A battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas.
• Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion.
Notice for WLAN
For CE WLAN: 5150-5350 MHz
This device is restricted for indoor use only when operating in the 5150 to 5350 MHz frequency range.
AT BE BG
FI FR DE
LT LU MT
SI ES SE
TR
For UK WLAN: 5150-5350 MHz
This device is restricted for indoor usage in UK when operating in the 5150 to 5350 MHz frequency range.
For ISED:
(i) The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems.
(ii) Where applicable, antenna type(s), antenna models(s), and worst-case tilt angle(s) necessary to remain compliant with the e.i.r.p. elevation mask requirement set forth in section 6.2.2.3 shall
be clearly indicated.
Avertissement:
(i) Les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l'intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de
satellites mobiles utilisant les mêmes canaux.
(ii) Lorsqu'il y a lieu, les types d'antennes (s'il y en a plusieurs), les numéros de modèle de l'antenne et les pires angles d'inclinaison nécessaires pour rester conforme à l'exigence de la p.i.r.e.
applicable au masque d'élévation, énoncée à la section 6.2.2.3, doivent être clairement indiqués.
Repairs
Do not, under any circumstances, attempt any service, adjustments, or repairs on this equipment. Instead, contact your local Verifone distributor or service provider for assistance. Failure to
comply may void the product warranty.
P200 and P200 Plus Certifications and Regulations
Verifone Part Number: DOC430-001-EN-D, Revision D02
© 2022 Verifone, Inc. All rights reserved.
HR CY CZ DK EE
EL HU IE IT LV
NL PL PT RO SK
UK(NI) IS LI NO CH
*DOC430-001-EN-D*
Verifone, Inc.
P200 and P200 Plus Certifications and Regulations
1-800-Verifone
www.verifone.com
FCC/ISED Compliance
The following device has been tested and certified as compliant with the regulations and guidelines detailed below:
Manufacturer: Verifone, Inc.
Brand: Verifone
Model: P200 and P200 Plus
Part 15 of FCC and ISED Rules
This device complies with the limits for a Class B digital device as specified in Part 15 of FCC and Innovation, Science and Economic Development Canada license-exempt RSS
standard(s) Rules which provide reasonable protection against harmful interference in a residential installation.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d'Innovation, Science and Economic Development Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée
aux deux conditions suivantes:
(1) Cet appareil ne doit pas provoquer d'interférences nuisibles.
(2) Cet appareil doit accepter toutes les interférences reçues, y compris les interférences susceptibles de provoquer un fonctionnement indésirable.
This equipment generates, uses and can radiate radio frequency energy. If not installed and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation. In the unlikely event that there is interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. Use of a shielded interface cable is required to comply
with the Class B limits of Part 15 of FCC Rules.
Cet appareil et son antenne ne doivent pas être situés ou fonctionner en conjonction avec une autre antenne ou un autre émetteur, exception faites des radios intégrées qui ont été
testées.
Any changes or modifications to this equipment not expressly approved by Verifone could void the user's authority to operate this equipment.
NOTE: The Country Code Selection feature is disabled for products marketed in USA/Canada.
La fonction de sélection de l'indicatif du pays est désactivée pour les produits commercialisés aux États-Unis et au USA/Canada.
Per FCC/ISED regulation, all Wi-Fi products marketed in USA/Canada must be fixed to USA/Canada operational channels only.
This Class B digital apparatus complies with CAN ICES-003(B).
Cet appareil numérique de la classe B est conforme à la norme NMB-003(B) du Canada.
RF Exposure
USA
The product complies with the FCC portable RF exposure limit set forth for an uncontrolled environment and is safe for intended operation as described in this manual. The further RF
exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available. The SAR limit
set by the FCC is 1.6W/kg for body worn SAR and 4W/kg for extremity SAR. This device has been tested and meets the FCC RF exposure guidelines be positioned a minimum of 0cm
from the body.
This device complies with SAR for general population/uncontrolled exposure limits in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement methods and
procedures specified in IEEE 1528-2013.
CE
This device complies with the Radio Equipment Directive (2014/53/EU) issued by the Commission of the European Community. A minimum separation distance of 0cm must be
maintained between the user's body and the device, including the antenna during body-worn operation to comply with the RF exposure requirements in Europe. To comply with RF
exposure requirements in Europe, third-party belt-clips, holsters or similar accessories used by this device should not contain any metallic components. The use of accessories that do
not satisfy these requirements may not comply with RF exposure requirements and should be avoided.
UK
This device complies with the Radio Equipment Regulations 2017 SI 2017/1206 issued by the British Standards Institution. A minimum separation distance of 0cm must be maintained
between the user's body and the device, including the antenna during body-worn operation to comply with the RF exposure requirements in UK. To comply with RF exposure
requirements in UK, third-party belt-clips, holsters or similar accessories used by this device should not contain any metallic components. The use of accessories that do not satisfy these
requirements may not comply with RF exposure requirements, and should be avoided.
ISED
The product complies with the Canada portable RF exposure limit set forth for an uncontrolled environment and is safe for intended operation as described in this manual. The further RF
exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available.
Le produit est conforme aux limites d'exposition pour les appareils portables RF pour les Etats-Unis et le Canada établies pour un environnement non contrôlé. Le produit est sûr pour un
fonctionnement tel que décrit dans ce manuel. La réduction aux expositions RF peut être augmentée si l'appareil peut être conservé aussi loin que possible du corps de l'utilisateur ou
que le dispositif est réglé sur la puissance de sortie la plus faible si une telle fonction est disponible.
Brazil Warning Statement
This equipment is not subject to protection from harmful interference and may not cause interference with duly authorized systems.
Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar interferência em sistemas devidamente autorizados.
Notice for Operating Frequency and Output Power
Feature
NFC: -13.56 MHz (dB µA/m at 10m)
2.4G WLAN (b/g/n): 2400-2483.5 MHz (EIRP dBm)
5G WLAN (a/n): 5150-5250/5250-5350/5470-5725 MHz (EIRP dBm)
WLAN (BT-EDR/LE): 2400-2483.5 MHz (EIRP dBm)
Recycling: DO NOT DISCARD!
UNIT MUST BE RECYCLED OR DISPOSED OF PROPERLY.
For proper disposal instructions go to http://recycle.verifone.com/
continued on rear cover
Recyclage: NE PAS JETER!
L'unité doit être recyclée ou mise au rebut dans les endroits prévus à cet effet.
Pour connaître les procédures de mise au rebut, consultez le site http://recycle.verifone.com/
suite au verso
P200 P200 Plus
- 11.44
NA <20
NA
<20
NA <12
Please retain this sheet for future reference.
À conserver pour référence ultérieure.
