Leviton 47000-STR Install Manual

DI-004-47000-01A
FEATURES
• Upgrades the Leviton Residential Intercom System with Door
Strike capability
• Ease of wiring via patch cords into other modules
• Will support up to 4 door strikes with screw terminal connections
• Configurable set time delay
PACKAGE CONTENTS
• Strike Board
INSTALLATION
1. Mount the Door Strike board onto an available spot of the SMC
mounting bracket.
2. Connect wires from door strike and strike power supply to the
correct terminals on the terminal strip. Use terminal SW1 for door
strike in zone 1, SW2 for door strike in zone 2, etc.
3. Adjust the jumper for connected zones to normally open (NO)
or normally close (NC) as desired. "Normally open" refers to the
contacts being open (and no current flowing) when the board is
energized. Conversely, "normally closed" means the contacts are
closed (with current flowing) when the board is energized. The
contacts are rated for 1 Amp at 125VAC/30VDC.
Use the patch cord to connect output of the Intercom Main
4.
Controller board to the input of the Door Strike board.
Use the second patch cord to connect the output/aux of the Door
5.
Strike board to the input of the Intercom Interface board.
NOTE: It is important that the Door Strike module is connected
DIRECTLY to the Intercom Main Controller board.
Set the dip switches according to the table below for the desired
6.
DTMF tone for activation and relay activation time.
NOTE: Chime board must be de-energized prior to changing settings.
NOTE: The LED will blink to indicate normal operation.
NOTE: Refer to Wiring Diagram on back page for wiring configuration.
Keypad # Delay Time
7 5 sec
7 1 sec
7 3 sec
7 0.5 sec
5 5 sec
5 1 sec
5 3 sec
5 0.5 sec
0 5 sec
0 1 sec
0 3 sec
0 0.5 sec
5 sec
*
1 sec
*
3 sec
*
0.5 sec
*
0 = OFF (switch away from board), 1 = ON (switch pushed toward board)
Leviton Residential Intercom System
Door Strike Board
Cat. No. 47000-STR
• 12V Power Supply
Time
Switch 1 Switch 2
0
0
0
0
1
1
1
1
0
0
0
0
1
1
1
1
• 12" Patch Cord (1)
DTMF
Switch 3 Switch 4
0 0
0 0
0 1
0 1
0 0
0 0
0 1
0 1
1 0
1 0
1 1
1 1
1 0
1 0
1 1
1 1
Leviton Intercom
Door Strike Board
K1
K2
K3
K4
U2
U1
1 2 3 4
w w w . l e v i t o n . c o m
• Power module using
power supply provided
or jumper to PSA
0
• This module requires
1
12VDC
0
• Fuse is a 1 Amp 250V
1
type GFE
0
1
0
1
0
1
0
1
0
1
0
1
NO
JP5 SW1
NO
NO
SW2
JP6
NO
NO
SW3
JP7
NC
SW4
NO
JP8
NC
J4
Q2
JK1
C16
+
+
R25
C12
JK2
C13 C14
ZD1
D14
F1
Q8-1
D15
–
+
12VDC
