- Page 1 Sees AIR COOLED SPLIT COMMERCIAL CONDENSING UNIT INSTALLATION, TECHNICAL, IOM NO: T-CU11-OCT22-0 MAINTENANCE RJ0110030013877 Medium Temperature Scan below QR code to download latest manual from https://drm.daikinmalaysia.com/download.php?fid=156&sid=1&f=DAIKIN_SEES_TM.pdf Website:...
- Page 2 READ BEFORE PROCEEDING! GENERAL SAFETY GUIDELINES This guideline is intended for users to ensure safe installation, operation, and maintenance of DAIKIN SEES condensing units. This guideline is not intended to replace the system expertise available from the system manufacturers. This equipment is a relatively complicated apparatus. During installation, operation, maintenance or service, individuals may be exposed to certain components or conditions including, but not limited to refrigerants, materials under pressure, rotating components, and both high and low voltage.
-
Page 3: Table Of Contents
Figure 9: Wiring Diagram LRMSS0400FXY1; LRMSS0500FXY1; LRMSS0600FXY1....... 18 EXPLODED VIEWS ............2 COMMISSIONING ............. 19 Table 1: Exploded View Indicator ......2 Figure 2: Exploded View LRMYS0180AXY1 ....2 ........... 19 RE STARTUP CHECKS Figure 3: Exploded View LRMYS0250AXY1 ....3 ............. 19 UNNING THE Figure 4: Exploded View LRMSS0400FXY1;... -
Page 4: Product Features
Product Features Daikin condensing unit is a partly completed machinery which need to incorporate with indoors, to provide cooling for refrigerated goods. The unit comprise of single fixed speed compressor and condenser in a fully enclosed powder coated housing. Standard features for all medium model: •... -
Page 5: Exploded Views
PRESSURE SWITCH LOW PANEL FRONT - RIGHT LOW PRESSURE TAPPING VALVE COVER ASSEMBLY PRESSURE SWITCH HIGH COMPRESSOR JACKET FUSE HANDLE FUSE HOLDER FOAM EPS COIL TOP TERMINAL BLOCK BRACKET LIQUID PIPE CONTACTOR Figure 2: Exploded View LRMYS0180AXY1 T-CU11-OCT22-0 Page 2... -
Page 6: Lrmss0500Fxy1; Lrmss0600Fxy1
Exploded View Figure 3: Exploded View LRMYS0250AXY1 Figure 4: Exploded View LRMSS0400FXY1; LRMSS0500FXY1; LRMSS0600FXY1 T-CU11-OCT22-0 Page 3... -
Page 7: Specifications
Connections Liquid Coil Charge Receiver Volume flow Displacement Compressor Liquid Suction Model Limit charge Model /rev) (kg) Qty. Inch Inch LRMYS0180AXY1 KSVB28P14AA 28.2 1.25 3/8" 1/2" 1.62 1874 LRMYS0250AXY1 JSVB39P14AA 38.6 3/8" 5/8" 1.97 2548 LRMSS0400FXY1 3CB067SA0M 66.8 11.8 1/2"... -
Page 8: Outline Drawings
Specifications Outline Drawings Figure 5: Outline Drawing LRMYS0180AXY1; LRMYS0250AXY1 Figure 6: Outline Drawing LRMSS0400FXY1; LRMSS0500FXY1; LRMSS0600FXY1 T-CU11-OCT22-0 Page 5... -
Page 9: Lrmys0250Axy1
1410 1458 1506 1554 1602 1650 1.07 1.48 1.87 2.22 2.56 2.88 3.17 1394 1951 2507 3064 3621 4177 4734 LRMYS0180AXY1 1384 1458 1531 1605 1679 1753 1826 1.01 1.34 1.64 1.91 2.16 2.38 2.59 1293 1777 2261 2746 3230... - Page 10 Continued MODEL 5801 6791 7943 9291 10876 12745 14952 2797 2931 3077 3234 3400 3572 3747 2.07 2.32 2.58 2.87 3.20 3.57 3.99 5301 6214 7270 8507 9965 11692 13739 3033 3178 3335 3503 3679 3862 4048 1.75 1.96 2.18 2.43 2.71 3.03...
-
Page 11: Application Guidelines
Too low superheat during low ambient condition that can condense refrigerant inside suction line. Compressor Rotary Compressor The rotary compressor inside DAIKIN condensing unit is a high-pressure dome compressor, with 2 poles 3phase AC motor. The pressure inside the shell of compressor is a high (discharge) pressure and have high temperature. -
Page 12: Voltage Imbalance
Therefore, the above-mentioned situation should be taken into consideration. Over Pressure Protection All Daikin condensing units are fitted with adjustable auto reset low pressure switch and manual reset cartridge type high pressure switch. Low Pressure Switch The low-pressure safety switch protects the compressor against deep vacuum operation or loss of refrigerant conditions, to avoid internal arcing at the electric terminal and the damage of compressor. -
Page 13: High Pressure Switch
Application Guidelines The low-pressure safety cut out should never be set below the Table 6 settings as shown in the and THE SETTINGS MUST BE ADJUSTED TO SUIT THE APPLICATION BEFORE STARTING THE UNIT. Setting Procedure for Single Pressure Switch: Cut in range: Turning the range adjusting screw (4) clockwise will decrease the cut-in pressure setting and vice versa. -
Page 14: Suction Accumulator
Application Guidelines Figure 7: Piping Diagram for Pump Down System Suction Accumulator An accumulator is required if repeated flooded starts could occur, dilute the oil in the compressor causing inadequate lubrication and bearing wear. A suction accumulator MUST added at suction line near to compressor for: System with charge exceed compressor limit. -
Page 15: Health And Safety
Health and Safety DAIKIN Condensing Unit has to be installed and commissioned by competent personnel, who are familiar with refrigeration systems and components including all controls. To avoid potential injury, use care when working around coil surfaces or sharp edges of metal cabinets. All piping and electrical wiring should be installed in accordance with all applicable standards and local laws. -
Page 16: Installation
Installation Unit location To achieve maximum cooling capacity, the installation location for the condensing unit should be carefully selected. • Install the condensing unit in such a way so that hot air ejected by the condensing unit cannot be drawn in again (short circuit of hot discharge air). -
Page 17: Field Piping
Installation Field Piping Pipe sizing should only be determined by qualified personnel. Correct line sizing will minimize the pressure drop and maintain sufficient gas velocity for proper oil return. All applicable standards must be observed in the installation of refrigerant piping. To ensure satisfactory operation and performance, the following points should be noted: •... -
Page 18: Pressure Testing
Installation Pressure Testing The condensing units are pressure tested in the factory prior to dispatch. All units come with a holding charge of oxygen free nitrogen. Remove the holding charge indication tag which is tied to service valve before installation. Once the pipework installation is complete, it should be pressure tested for leaks prior to evacuation. -
Page 19: System Charging
Installation System Charging Once system evacuation has been completed, the system could be charged with the approved refrigerant. Refrigerant must be charged with liquid on the high-pressure side to the extent possible, with the compressor in OFF condition and service valves must be closed. The service port on the receiver outlet rotolock valve (liquid line) can be used for initial charge. -
Page 20: Electrical
A mains isolator MUST also be fitted to all condensing units unless site conditions or regulations dictate differently. Daikin condensing units require a 400 Volt / 3 Phase / 50Hz supply, both of which must include a Neutral and an Earth. Table 5... -
Page 21: Lrmys0250Axy1
Installation Wiring Diagrams Figure 8: Wiring Diagram LRMYS0180AXY1; LRMYS0250AXY1 INDICATOR C1: FAN CAPACITOR MODEL (uF) F1: FUSE K1M: CONTACTOR M1C: COMPRESSOR LRMYS0180AXY1 3.0 M1F: CONDENSING FAN S1PL: LOW PRESSURE SWITCH LRMYS0250AXY1 3.5 S1PH: HIGH PRESSURE SWITCH TOR1: OVERLOAD RELAY 380-400V/3N~/50Hz - - - -: FIELD WIRING 3.15A... -
Page 22: Commissioning
Commissioning Pre startup checks Before starting the condensing unit, the following checks should be carried out as a minimum: • Check electrical supply is correct and all connections are sound. • All moving parts are free, and guards fitted. • Check all mechanical connections for tightness •... -
Page 23: Service And Maintenance
The oil level should be ½ to ¾ way up the sight glass (where fitted). 8. Warranty • The warranty as provided by Daikin on its 2. Condenser Fan Motor & Blade – Clean and inspect products is subject to correct application, at regular intervals siting, and installation procedures together •... - Page 24 Service and Maintenance Table 10:Tightening Torque Thread/Size (Tightening Torque (Nm)) Model Main Cap Service Cap Suction: M18*1.0mm (25-30 Nm) LRMYS0180AXY1 Liquid: M16*1.0mm (20-25 Nm) Suction: M22*1.5mm (30-35 Nm) LRMYS0250AXY1 Liquid: M16*1.0mm (20-25 Nm) 7/16" - 20UNF (14-16 Nm) LRMSS0400FXY1 Suction: M33*1.5mm (42-47Nm) LRMSS0500FXY1 Liquid: M18*1.0mm (25-30 Nm)
-
Page 25: Check List
Check List BEFORE START-UP No. Description Check Is the unit in good condition with holding gas and without any visible damage? Has the unit been transported in upward position? Is the crankcase oil level between 1/4 and 3/4 of the compressor sight glass (only applicable to scroll compressor)? Is the power supply on site in line with the unit specification? Is air short circuit and/or air blockage avoided? -
Page 26: During Commissioning
Check List DURING COMMISSIONING Description Check Is the suction pressure decreasing and the discharge pressure increasing? Is the compressor rotation correct (no abnormal noise and with compression)? Is the crankcase oil level between 1/4 and 3/4 of the scroll compressor sight glass? (after 3 or 4 hours of operation) Is the discharge temperature within the limits (between 50 °C and 90 °C)? Is the suction superheat within the limits (between 5K and 20K) during normal operation? - Page 27 DAIKIN REFRIGERATION MALAYSIA SDN. BHD. (34543-W) Shah Alam Plant : 11A, Jalan Utas 15/7, Seksyen 15, 40200 Shah Alam, Selangor, Malaysia. Banting Plant : Lot 10, Jalan Perusahaan 8, Kawasan Perusahaan Pekan Banting, 42700 Banting, Selangor, Malaysia. Tel: 603-3187 2911 Fax: 603-3187 8597...
