Technical Data and Features
Base station:
Perpetual Calendar Up to Year 2099
Day of week in 8 languages user selectable: English, German, Italian, French, Spanish, Dutch, Danish and Russian
Time in optional 12/24 hour format.
Automatic calibration of network time service
Barometric pressure:
— Air pressure data source network
— Pressure alternatively in hPa/mb or inHg or mmHg
Wind speed and direction:
—Wind speed and direction data source network
—Wind speed alternatively in km/h or Mph
Indoor humidity measurable range: 20%RH to 95%RH
Indoor temperature:
— Temperature measurement ranges:-20°C to 60°C or (-4°F to 140°F)
— Temperature alternatively in °C or °F.
Minimum/maximum display for humidity and temperature
Feels like temperature data source network
The future weather forecast and temperature report function, weather forecast information provided by the network
Connects to Wi-Fi network
Power Supply: 2 x LR6 AA and mains adapter: DC5V 1.2A
Base dimensions :
205 x 130 x 30 mm
Sensor dimensions :
97 x 50 x 32 mm
Wireless Outdoor Sensor:
— Outdoor temperature measurement ranges: -40°C (-4°F) ~ 70°C (158°F)
— Outdoor measurable range: 20%RH to 95%RH
— Data transmission frequency: 433 MHz
—
Maximum Frequency power : <+10dBm
— Wireless range: max. 60 m (open area)
— Batteries: 2 x LR06 (UM-3), 1.5 V (size AA)
— Protection class: IPX4
WIFI Weather Station
SW402
Advertisement
Table of Contents
Related Manuals for La Crosse Technology SW402
Summary of Contents for La Crosse Technology SW402
- Page 1 WIFI Weather Station SW402 Technical Data and Features Base station: Perpetual Calendar Up to Year 2099 Day of week in 8 languages user selectable: English, German, Italian, French, Spanish, Dutch, Danish and Russian Time in optional 12/24 hour format.
- Page 2 WIFI Weather Station SW402 Base station Appearance: Part A-Positive LCD A1: Network Time icon A2: Time A3: Week for today A4: Calendar A5: ALARM icon A6: WIFI icon A7: Indoor Temperature A8: Outdoor Temperature A9: Indoor Humidity A10: Remote wireless channel...
- Page 3 WIFI Weather Station SW402 A21: Week for the next third days A22: Minimum temperature forecast for the next third days A23: Maximum temperature forecasts for the A24: Weather forecast for the next second days next third days A25: Week for the next second days...
-
Page 4: Initial Operation
Initial operation: Open Wireless Outdoor Sensor battery compartment cover , Push the Channel selector switch in the battery compartment of the Wireless Outdoor Sensor, set the correct channel you want ,Insert 2 x AA batteries observing polarity [ “+” and “–“ marks] ... -
Page 5: User Registration
https://play.google.com/store/apps/details?id=com.emax.weahter User registration： Follow in-app instructions to create an account, after registration is completed, enter the mailbox for account activation Account login and register Account registration mailbox account activation Pairing with weather station device Login user account Make sure your phone is connected to a 2.4GHz Wi-Fi network. and that Wifi function is turned (WiFi weather station currently only support 2.4GHz Wi-Fi network during configuration,) Plug in weather station with AC/DC power, Press and hold “Wi-Fi”... - Page 6 Make sure your phone’s location service are turned on and allowed for this App. Make sure that your current location city can be successfully located in the map. Some cities may fail to locate because there is no corresponding success in the app. You can manually move the location or be automatically positioned to a large administrative level city.
- Page 7 Confirm your location Choose W003 Make sure the device Select the device name enter AP mode “Weathertype” Input correct Wi-Fi Bind the device Make sure the device password exit AP mode Note: after the power AC/DC adapter is disconnected, the WIFI connection of the device will be automatically disconnected.
-
Page 8: Manual Time Setting
The base station can connect up to 3 channel wireless sensor registration, the use of multiple wireless sensor, the wireless sensor channel can not choose the same channel at the same time (a total of 1, 2, 3 channel can choose) ... -
Page 9: Setting The Daily Alarms
buttons to set the correct year. Press “ ” button to confirm your setting, the Month display starts to flash. Now use “ ” and “ ” buttons to set the correct month. Press “ ” button to confirm your setting, the Date display starts to flash. Now use “ ”... -
Page 10: Alarm On/Off
Press “ ” button to confirm your setting and to end the setting procedure F.Y.I.: After 20 seconds without pressing any button the clock switches automatically from setting mode to Normal clock mode. Alarm ON/OFF The alarm shift switch is pushed in the “ ” position, LCD display the “ ”... -
Page 11: Low Battery
Three times to return to the current temperature and humidity levels. To reset the maximum and minimum temperature and humidity, press and hold down the “MEM” button about 2 seconds. This will reset all minimum and maximum data recorded to the current displayed values. Note: ... - Page 12 sunny Mostly sunny Partly cloudy Mostly cloudy Cloudy Patchy Rain Mostly Rain Showers Heavy Rain Thunder Rain Rain and Hail Hail Snow and Hail Patchy Snow Mostly Snow Snow shower Heavy Snow Rain and Snow Foggy or Haze windy ABOUT AC/DC POWER SUPPLY Do not use the device: -if the power supply or the power cable is damaged, -in the event of a malfunction,...
-
Page 13: Liability Disclaimer
amplifiers) that produce heat. Do not store this product in a place where the temperature exceeds the following range: - 10 to 70 ° C. Do not use this product in a location where the temperature exceeds the following range: 0 to 40 ° C, as this may damage it or shorten its life. Do not place the power supply near water or a source of moisture, such as a bathtub, kitchen sink, swimming pool, in a wet basement, or other damp locations. -
Page 14: La Crosse Technology
•No part of this manual may be reproduced without written authorization of the manufacturer. RED DIRECTIVE 2014/53/EU Summary of the Declaration of Conformity: We hereby declare that this wireless transmission device does comply with the essential requirements of RED Directive 2014/53/EU. LA CROSSE TECHNOLOGY 6 A RUE DU COMMERCE 67118 GEISPOLSHEIM FRANCE...
