XC1 0 0
Note Dispenser
User Guide
Th ank y ou fo r choo s i ng TOP VME .

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XC100 and is the answer not in the manual?

Questions and answers

Related Manuals for Top XC100

Summary of Contents for Top XC100

  • Page 1 XC1 0 0 Note Dispenser User Guide Th ank y ou fo r choo s i ng TOP VME .

  • Page 3: Table Of Contents

    C o n t e n t s 1. Introduction ....................1 1-1. Overview ....................1 1-2. Features ....................1 1-3. Precautions ...................1 2. Specifications ....................2 2-1. General ....................2 2-2. Electronic ....................2 2-3. Machine ....................2 3. Packing List ....................2 4. Dimension .....................3 5. Installation ....................4 5-1.
  • Page 4 C o n t e n t s 5-6-3. Clear Accumulated Number And Fault Message ..15 5-6-4. Inhibit Bill Dispenser press ..........15 5-6-5. Clear Error Record ...............15 5-6-6. Check The Status Of The Banknote ......16 5-6-7. Get Error Message Record ..........16 5-6-8.

  • Page 7: Introduction

    Note Dispenser 1. Introduction 1-1. Overview XC100 Bill Dispenser is a machine that counts the number of banknotes, easy to set the amount of banknotes for accurate output. Correct the function of paper thickness, can be applied to all banknote currencies, make it easier for you to count.

  • Page 8: Specifications

    220 x 150 x 200 mm Dimension Bill Dimension 100~170 mm / <80 mm Box Capacity Approx. 700 bills Display Four digital display 3. Packing List Main XC100 Note Display Installation guide Harness Accessories two Keys DIP Switch Setting Guide...

  • Page 9: Dimension

    Note Dispenser 4. Dimension Unit : mm [ inch ] 232.10 9.138 199.25 7.844 223.05 8.781 203.85 8.026 244.60 9.630...

  • Page 10: Installation

    XC100 5. Installation 5-1. Harness Application Interface Voltage Usage Harness NO. Page Data RS232 WEL-R7U06 Communication Power & Data 24V DC WEL-N0002-1 Communication 24V DC Power 2WIR-DA-0054-A0 Reserve Power & Data Communication DIP SWITCH RS232 / Update program port NOTE : Update program port Please refer to the G-BOX Operation manual for a guide step by step how to download or update using the G-Box programmer.
  • Page 11 Note Dispenser WEL-R7U06 PIN NO COLOR PIN DEFINE PIN1 BLUE PIN NO PIN DEFINE PIN2 PIN6 WHITE PIN3 PIN7 BLACK PIN5 PIN8 PURPLE...
  • Page 12 XC100 WEL-N0002-1 6 5 4 3 2 1 PIN NO COLOR PIN DEFINE PIN1 BLACK VEND- PIN2 BROWN VEND+ PIN3 INHIBIT- PIN4 ORANGE INHIBIT+ PIN5 YELLOW PIN6 GREEN +24V DC...
  • Page 13 Note Dispenser 2WIR-DA-0054-A0 6 5 4 3 2 1 PIN NO COLOR PIN DEFINE PIN NO COLOR PIN DEFINE PIN6 +24V DC PIN1 +24V DC PIN5 BLACK PIN2 BLACK...
  • Page 14 XC100 +3.3V VEND+ 47KR Credit in 1 Credit I/P Credit O/P VEND- 100R +12V Credit +3.3V VEND+ 10KR Credit in2+ Credit I/P Meter O/P VEND- 470R Credit in2-...
  • Page 15 Note Dispenser RS232 INTERFACE DEFINE Power's pins PIN1 PIN2 PIN3 PIN4 PIN5 PIN6 VEND- VEND+ +24V RS232 PINS PIN1 PIN2 PIN3 PIN4 PIN5 PIN6 PIN7 PIN8 PULSE INTERFACE DEFINE Power's pins define PIN1 PIN2 PIN3 PIN4 PIN5 PIN6 CREDIT CREDIT VEND- VEND+ +24V IN2-...

  • Page 16: Button Application

    XC100 5-2. Button Application S1 Button function : a. Give Bills b. The number of withdrawals per time is controlled by DIP SW1 and DIP SW2. ( Refer-DIP SWITCH SETTING) S2 Button Function : Long press for 3 seconds, automatic correction.DIP SW10 Control correction mode.

  • Page 17: Password Release & Setting Method

    Note Dispenser 5-3. Password Release & Setting Method Machine password is six digits, Before using the button, must first remove the password. Default setting 123434 Password release： In order S1-S2-S3-S4-S3-S4. Release success, RS232 display“- - - -“，PULSE display ”_ _ _ _ ”. No button within 10 seconds, need to press the password again.

  • Page 18: Prepare Before Starting To Issue Notes

    XC100 5-4-2. Prepare before starting to issue notes ( Automatic correction ) Our company has corrected the firmware, No need to do white card calibration again to change the currency value, DIP SW adjusted to appropriate. If you re-program the program, please do White Card Calibration or Learning calibration first.
  • Page 19 Note Dispenser General Operation Software operation Description Set the communication position between PC and ID_1 machine ID 10 Reserved Port Set COM PORT Baud Set BOW Start Protocol Start communication End Protocol Interrupt communication DIP Switch Display firmware version and Dip switch One instruction to set the number of banknotes at a Out Bill 1~100 time...

  • Page 20: Protocol

    XC100 5-6. Protocol RS232 Specification Baud Rate 9600 Parity Check None Data Length Stop Bit a. Bill Dispenser Received instructions from the PC, will return the status to the PC within 50 milliseconds b. Normal status : ACK 0x06 c. Fault status : NCK 0x0a (Check code failure, Data value failure ) d.

  • Page 21: Clear Accumulated Number And Fault Message

    Note Dispenser 5-6-3. Clear Accumulated Number And Fault Message Host to Bill dispenser ' I ' → Response : ACK BYTE0 BYTE1 BYTE2 BYTE3 BYTE4 BYTE5 BYTE6 BYTE7 BYTE8 BYTE9 ID_10 ID_1 ' I ' ' 0 ' ' 0 ' ' 0 ' ' 1 ' BYTE7: ' 1 ' Clear accumulation / Cash is dispensed...

  • Page 22: Check The Status Of The Banknote

    XC100 5-6-6. Check The Status Of The Banknote Host to Bill dispenser ' S ' BYTE0 BYTE1 BYTE2 BYTE3 BYTE4 BYTE5 BYTE6 BYTE7 BYTE8 BYTE9 ID_10 ID_1 ' S ' ' 0 ' ' 0 ' ' 0 ' ' 0 '...

  • Page 23: Bill Dispenser Total Number Of Banknotes

    Note Dispenser 5-6-9. Bill Dispenser Total Number Of Banknotes Host to Dispenser ' T ' BYTE0 BYTE1 BYTE2 BYTE3 BYTE4 BYTE5 BYTE6 BYTE7 BYTE8 BYTE9 ID_10 ID_1 ' T ' ' 0 ' ' 0 ' ' 0 ' ' 0 ' Dispenser to Host ' y ' BYTE0 BYTE1 BYTE2 BYTE3 BYTE4 BYTE5 BYTE6 BYTE7 BYTE8 BYTE9 hundred...

  • Page 24: Get Dip Switch Position

    XC100 5-6-11. Get DIP SWITCH position Host to Dispenser ' D ' BYTE0 BYTE1 BYTE2 BYTE3 BYTE4 BYTE5 BYTE6 BYTE7 BYTE8 BYTE9 ID_10 ID_1 ' D ' ' 0 ' ' 0 ' ' 0 ' ' 0 ' Dispenser to Host ' d '...

  • Page 25: Dip Sw Setting

    Note Dispenser 5-6-13. DIP SW Setting RS232 INTERFACE DEFINE - DIP SW Function Speed slow Speed fast *1 pcs 5pcs 10pcs 20pcs OFF OFF *ID_1 ID_1 ID_1 ID_1 OFF OFF ID_1 ID_1 ID_1 OFF OFF ID_1 OFF OFF OFF ** White Card Calibration Learning white Card PULSE INTERFACE DEFINE - DIP SW...

  • Page 26: Banknote Output Restriction Function

    XC100 6. Banknote Output Restriction Function When the inventory quantity is lower than or equal to the minimum inventory limit, the device will perform an error action (declaring that there is no banknote). Setting operation: (1) Enter setting mode Press and hold the S4 button first, and then press the S3 button for 3 seconds to enter the banknote discharge limit setting mode.
  • Page 27 Note Dispenser (4) Release the error status When the banknote output limit is triggered, the method of clearing is to clear the current number of banknotes issued, and just long press S4 to clear it. Actual screen： Trigger mechanism : H5 indicates that the number of banknotes in stock is at least 5 * 100 = 500, and L5 indicates that the minimum number of banknotes in stock is 5 * 10 = 50.

  • Page 28: Maintenance

    XC100 7. Maintenance 7-1. Clean inside and add lubricant 1.Clean with a soft brush draw out port and the junction of the banknote and the roller (A), prevent the sensor from being blocked by dust. 2.Regularly press the billboard and the rail (B) add oil and keep it dry.

  • Page 29: Matters For Cleaning The Inner Rollers

    Note Dispenser 7-2. Matters for cleaning the inner rollers 1. Remove the screws (marked with 4 in the box) and pull apart the wire. (A) 2. Remove the screws on the lower sheet metal (two hexagonal frames are marked). (A) 3.

  • Page 30: Troubleshooting

    Adjust wheel set clearance screw, ( two bills or too old ). turn clockwise SENSOR or motor error, Motor error please inform TOP. Left IR electric eye start error, please Left IR electric eye start error. inform TOP. Right IR electric eye start error, Right IR electric eye start error.
  • Page 31 Taiwan Top Vending Machine Electronics Co., Ltd. NO.11, Anzhong St., Luzhu Dist., Taoyuan City338, Taiwan, (R.O.C.) Phone : +886-3-3115969．Fax : +886-3-3115970 E-mail : sales@topvme.com.tw Website : www.topvme.com NO. 4007-XC10000001...
  • Page 32 Top Vending Machine Electronics Co., Ltd. w w w .topv me .co m...
