X C1 00
Note Dispenser
User Guide
Th ank y ou fo r choo s i ng TOP VME .

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XC100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Top XC100

  • Page 1 X C1 00 Note Dispenser User Guide Th ank y ou fo r choo s i ng TOP VME .

  • Page 3: Table Of Contents

    C o n t e n t s 1. Introduction ………………………………………………………………………………………………………1 1-1. Overview ………………………………………………………………………………………………………… 1 1-2. Features ………………………………………………………………………………………………………… 1 1-3. Precautions …………………………………………………………………………………………………… 1 2. Specifications ………………………………………………………………………………………………… 2 2-1. General ………………………………………………………………………………………………………… 2 2-2. Electronic ……………………………………………………………………………………………………… 2 2-3. Machine ………………………………………………………………………………………………………… 2 3. Packing List …………………………………………………………………………………………………… 2 4.
  • Page 4 C o n t e n t s 5-6-5. Clear Error Record …………………………………………………………………………………… 16 5-6-6. Check The Status Of The Banknote ………………………………………………………… 16 5-6-7. Get Error Message Record ……………………………………………………………………… 17 5-6-8. Check Out The Billing Item ……………………………………………………………………… 17 5-6-9. Bill Dispenser Total Number Of Banknotes ……………………………………………… 17 5-6-10.

  • Page 5: Introduction

    Note Dispenser 1. Introduction 1-1. Overview XC100 Bill Dispenser is a machine that counts the number of banknotes, easy to set the amount of banknotes for accurate output. Correct the function of paper thickness, can be applied to all banknote currencies, make it easier for you to count.

  • Page 6: Specifications

    220 x 150 x 200 mm Dimension Bill Dimension 100~170 mm / <80 mm Box Capacity Approx. 700 bills Display Four digital display 3. Packing List Main XC100 Note Display Installation guide Harness Accessories two Keys DIP Switch Setting Guide...

  • Page 7: Dimension

    Note Dispenser 4. Dimension Unit : mm [ inch ] 232.10 9.138 199.25 7.844 223.05 8.781 203.85 8.026 244.60 9.630...

  • Page 8: Installation

    XC100 5. Installation 5-1. Harness Application Interface Voltage Usage Harness NO. Page RS232 Data Communication WEL-R7U06 Power & Data 24V DC WEL-N0002-1 Communication 24V DC Power 2WIR-DA-0054-A0 Reserve Power & Data Communication DIP SWITCH RS232 / Update program port NOTE : Update program port Please refer to the G-BOX Operation manual for a guide step by step how to download or update using the G-Box programmer.
  • Page 9 Note Dispenser WEL-R7U06 PIN NO COLOR PIN DEFINE PIN1 BLUE PIN NO PIN DEFINE PIN2 PIN6 WHITE PIN3 PIN7 BLACK PIN5 PIN8 PURPLE...
  • Page 10 XC100 WEL-N0002-1 6 5 4 3 2 1 PIN NO COLOR PIN DEFINE PIN1 BLACK VEND- PIN2 BROWN VEND+ PIN3 INHIBIT- PIN4 ORANGE INHIBIT+ PIN5 YELLOW PIN6 GREEN +24V DC...
  • Page 11 Note Dispenser 2WIR-DA-0054-A0 6 5 4 3 2 1 PIN NO COLOR PIN DEFINE PIN NO COLOR PIN DEFINE PIN6 +24V DC PIN1 +24V DC PIN5 BLACK PIN2 BLACK...
  • Page 12 XC100 +3.3V VEND+ 47KR Credit in 1 Credit I/P Credit O/P VEND- 100R +12V Credit +3.3V VEND+ 10KR Credit in2+ Credit I/P Meter O/P VEND- 470R Credit in2-...
  • Page 13 Note Dispenser RS232 INTERFACE DEFINE Power's pins BK BN RD OG YE GR PIN1 PIN2 PIN3 PIN4 PIN5 PIN6 VEND- VEND+ +24V RS232 PINS PIN1 PIN2 PIN3 PIN4 PIN5 PIN6 PIN7 PIN8 PULSE INTERFACE DEFINE Power's pins define BK BN RD OG YE GR PIN1 PIN2 PIN3...

  • Page 14: Button Application

    XC100 5-2. Button Application S1 Button function : a. Give Bills b. The number of withdrawals per time is controlled by DIP SW1 and DIP SW2. ( Refer-DIP SWITCH SETTING) S2 Button Function : Long press for 3 seconds, automatic correction.DIP SW10 Control correction mode.

  • Page 15: Password Release & Setting Method

    Note Dispenser 5-3. Password Release & Setting Method Machine password is six digits, Before using the button, must first remove the password. Default setting 123434 Password release： In order S1-S2-S3-S4-S3-S4. Release success, RS232 display“- - - -“， PULSE display ”_ _ _ _ ”. No button within 10 seconds, need to press the password again.

  • Page 16: Prepare Before Starting To Issue Notes ( Automatic Correction )

    XC100 5-4-2. Prepare before starting to issue notes ( Automatic correction ) Our company has corrected the firmware, No need to do white card calibration again to change the currency value, DIP SW adjusted to appropriate. If you re-program the program, please do White Card Calibration or Learning calibration first.
  • Page 17 Note Dispenser General Operation Software operation Description ID_1 Set the communication position between PC and machine ID 10 Reserved Port Set COM PORT Baud Set BOW Start Protocol Start communication End Protocol Interrupt communication DIP Switch Display firmware version and Dip switch Out Bill 1~100 One instruction to set the number of banknotes at a time One order for issuing a banknote at a time, the number of...

  • Page 18: Protocol

    XC100 AUTO TEST Automatic Detection Bill Dispenser Mark Description MOTOR SPEED Motor speed L_IR Left sensor value R_IR Right sensor value Grating DISPLAY monitor COUNTER counter -The middle black part is RS232 communication display. 5-6. Protocol RS232 Specification Baud Rate...

  • Page 19: Cash Out Instruction

    Note Dispenser 6. CS : Check code (The last 2 codes from the sum of BYTE0 to BYTE7) 7. ETX : End code (0x03) 5-6-2. Cash out Instruction Host to Bill dispenser 'B' → Response : ACK BYTE0 BYTE1 BYTE2 BYTE3 BYTE4 BYTE5...

  • Page 20: Clear Error Record

    XC100 5-6-5. Clear Error Record Host to Bill dispenser ' U ' → Response : ACK BYTE0 BYTE1 BYTE2 BYTE3 BYTE4 BYTE5 BYTE6 BYTE7 BYTE8 BYTE9 ID_10 ID_1 ' U ' ' 0 ' ' 0 ' ' 0 ' ' 0 ' 5-6-6.

  • Page 21: Get Error Message Record

    Note Dispenser 5-6-7. Get Error Message Record Host to dispenser ' R ' BYTE0 BYTE1 BYTE2 BYTE3 BYTE4 BYTE5 BYTE6 BYTE7 BYTE8 BYTE9 ID_10 ID_1 ' R ' ' 0 ' ' 0 ' ' 0 ' ' 0 ' Dispenser to Host ' r ' BYTE0 BYTE1...

  • Page 22: Get Button Password

    XC100 5-6-10. Get Button Password Host to Dispenser ' P ' BYTE0 BYTE1 BYTE2 BYTE3 BYTE4 BYTE5 BYTE6 BYTE7 BYTE8 BYTE9 ID_10 ID_1 ' P ' ' 0 ' ' 0 ' ' 0 ' ' 0 ' Dispenser to Host ' p '...

  • Page 23: Get Dip Switch Position

    Note Dispenser 5-6-11. Get DIP SWITCH position Host to Dispenser ' D ' BYTE0 BYTE1 BYTE2 BYTE3 BYTE4 BYTE5 BYTE6 BYTE7 BYTE8 BYTE9 ID_10 ID_1 ' D ' ' 0 ' ' 0 ' ' 0 ' ' 0 ' Dispenser to Host ' d ' BYTE0 BYTE1...

  • Page 24: Dip Sw Setting

    XC100 5-6-13. DIP SW Setting RS232 INTERFACE DEFINE - DIP SW Function Speed slow Speed fast *1 pcs 5pcs 10pcs 20pcs *ID_1 ID_1 ID_1 ID_1 ID_1 ID_1 ID_1 ID_1 ** White Card Calibration Learning white Card PULSE INTERFACE DEFINE - DIP SW...

  • Page 25: Banknote Output Restriction Function

    Note Dispenser 6. Banknote Output Restriction Function When the inventory quantity is lower than or equal to the minimum inventory limit, the device will perform an error action (declaring that there is no banknote). Setting operation: (1) Enter setting mode Press and hold the S4 button first, and then press the S3 button for 3 seconds to enter the banknote discharge limit setting mode.
  • Page 26 XC100 (4) Release the error status When the banknote output limit is triggered, the method of clearing is to clear the current number of banknotes issued, and just long press S4 to clear it. Actual screen： Trigger mechanism : H5 indicates that the number of banknotes in stock is at least 5 * 100 = 500, and L5 indicates that the minimum number of banknotes in stock is 5 * 10 = 50.

  • Page 27: Maintenance

    Note Dispenser 7. Maintenance 7-1. Clean inside and add lubricant 1. Clean with a soft brush draw out port and the junction of the banknote and the roller (A), prevent the sensor from being blocked by dust. 2. Regularly press the billboard and the rail (B) add oil and keep it dry.

  • Page 28: Matters For Cleaning The Inner Rollers

    XC100 7-2. Matters for cleaning the inner rollers 1. Remove the screws (marked with 4 in the box) and pull apart the wire. (A) 2. Remove the screws on the lower sheet metal (two hexagonal frames are marked). (A) 3. Use an air gun or a soft brush to remove dust and paper dust from the roller.

  • Page 29: Troubleshooting

    Adjust wheel set clearance screw, turn ( two bills or too old ). clockwise SENSOR or motor error, Motor error please inform TOP. Left IR electric eye start error, please Left IR electric eye start error. inform TOP. Right IR electric eye start error, please Right IR electric eye start error.
  • Page 31 Taiwan Top Vending Machine Electronics Co., Ltd. NO.11, Anzhong St., Luzhu Dist., Taoyuan City338, Taiwan, (R.O.C.) Phone : +886-3-3115969．Fax : +886-3-3115970 E-mail : sales@topvme.com.tw Website : www.topvme.com NO. 4007-XC10000001...
  • Page 32 Top Vending Machine Electronics Co., Ltd. w w w .topv me .co m...
