  • Page 1 US Version AC EV Charger User Manual...
  • Page 3 Contents Abbreviations ....................Section 1—PRECAUTIONS ....................Section 2—STANDARDS COMPLIANCE ....................Section 3— PRODUCT OVERVIEW & INFO ....................Section 4—What's in the Box? ....................Section 5—Installation ....................Section 6—Network Configuration ....................Section 7—LED Indicators ....................Section 8—Fault Handling ....................Section 9—Warranty ....................
  • Page 4 Section 1—PRECAUTIONS 1.1 IMPORTANT SAFETY PRECAUTIONS WARNING- When using electric products, basic precautions should always be followed, including the following. This manual contains important instructions for Models and PULSEQ AC HOME that shall be followed during the installation, operation, and maintenance of the charging station. Read all the instructions before using this product.
  • Page 5 1.2 SAFETY NOTES 1.2.1 Safety signs used The following warning signs, mandatory signs and information signs are used in this manual, on and in the AC EV Charger. CAUTION: Warning of electrical hazards. This sign is intended to alert the user that severe personal injury or substantial property damage can result if the device is not operated as requested.
  • Page 6 1.2.3 Safety Precautions for Maintenance Personnel must always use protective footwear when performing maintenance work. It is recommended that Charger is routinely inspected at least once a week. Do not put inflammable, explosive, or combustible materials, chemicals, combustible steam, or other dangerous goods near the Charger, due to risk of fire.
  • Page 7 PRÉCAUTIONS CONSIGNES DE SÉCURITÉ IMPORTANTES AVERTISSEMENT- Lors de l'utilisation de produits électriques, des précautions de base doivent toujours être suivies, y compris les suivantes. Ce manuel contient des instructions importantes pour les modèles PULSEQ AC HOME qui doivent être suivies pendant l'installation, l'utilisation et la maintenance de l'unité.
  • Page 8 NOTES DE SÉCURITÉ 1.2.1 Signes de sécurité utilisés Les panneaux d'avertissement, panneaux obligatoires et panneaux d'information suivants sont utilisés dans le manuel d'utilisation, sur et dans la station de charge M3P EV: MISE EN GARDE: Avertissement de risques électriques. Ce signe est destiné à alerter l'utilisateur que des blessures graves ou des dommages matériels importants peuvent survenir si l'appareil n'est pas utilisé...
  • Page 9 1.2.3 Précautions de sécurité pour l'entretien Le personnel doit toujours porter des chaussures de protection lors des travaux de maintenance. Il est recommandé que le chargeur fasse l'objet d'un contrôle de sécurité au moins une fois par semaine. Il est interdit de placer des substances dangereuses telles que des matières inflammables, explosives ou inflammables, des produits chimiques, des vapeurs inflammables à...
  • Page 10 Section 2—STANDARDS COMPLIANCE 2.1 Standard(s) for safety Conformes to UL 2594, 2nd, Ed., Issue Date: 2016-12-21 2.2 AC Level 2 Charging According to SAE J 1772, PulseQ AC Home product (the maximum output current is 40 A) was designed for AC Level 2 charging.
  • Page 11 2.4 Charging interface The charging plug of PulseQ AC Home product meets SAE J1772/IEC 62196-2, Type 1. Fig. 2.4.1 Schematic diagram of Type 1 interface PulseQ AC Home provides a Type 1 female plug with charging cable, it only chargs an EV with a Type 1 charging socket (vehicle inlet).
  • Page 12 Section 3— PRODUCT OVERVIEW & INFO 3.1 Shape & Dimensions The shape & dimensions of PulseQ AC Home charger are shown as Fig. 3.1.1 220mm 95mm 310mm Fig. 3.1.1 The shape & dimensions of PulseQ AC Home 3.2 Block diagram The block diagram of PulseQ AC Home charger is shown as Fig.
  • Page 13 It is widely used in various household electric vehicle charging in North America, as well as various chargers, parking lots, community garages and public electric vehicle charging places. 3.3 Specifications 3.3.1 Electrical Specifications Model Number PULSEQ AC HOME Rated Voltage 240V/208V (AC Level 2 Charging), 50/60Hz Rated Current Rated Power...
  • Page 14 3.3.3 Mechanical Parameters Mounting Wall-mounted Net Weight ≤ 7KG（5m cable）、≤ 9KG（7.5m cable） Dimension H×W×D = 310mm × 220mm × 95mm Color & Material Front cover: Gray, PC; Back cover: Black, PC Enclosure rated Type 4 3.3.4 Ambient Conditions Altitude ≤ 2000m Storage temperature -40°F to 167°F (-40°C to 75°C) Operation temperature...
  • Page 15 NOTE Read owners manual before use. Veuillez lire le manuel de l'utilisateur avant utilisation. Ventilation not required. Aucune ventilation requise. The suitability of the use of flexible cord in accordance with CE code, Part I, Rule 4-012, is to be determined by the local inspection authority having jurisdiction.
  • Page 16 Section 4—What's in the Box? AC EV Charger (14-50P input power cable & 5/7.5m charging cable) Charging Dock Wall-mounting Accessories User Manual Quick User Guide Quality Certificate Wall Installation Template M6×63mm Expansion Bolt M5×40mm Expansion Bolt Charging Dock Installation Template IC card User Manual...
  • Page 17 Section 5—Installation 5.1 Pre-Installation Inspection When unpacking, please carefully confirm the following points: ● Whether the accessories are missing according to the packing list. ● Whether there is any damage during transportation. ● Whether the model and specification of the machine's nameplate are consistent with the order requirements. If any damage or missing parts are found, please do not start the installation, and contact us as soon as possible.
  • Page 18 5.3 Tools for Installation Please prepare the following tools before installation Tools’ Name Schematic Picture Main Uses Check the electrical connection and Multimeter measure the voltage Electric Impact Drill fixing holes in the wall drill Wrench Fastening bolt Diagonal plier Cut the cable Wire stripper Peeling cables...
  • Page 19 5.4 Wall Bracket Installation Ensure the homeowner has chosen an installation location that allows the charging cable to reach the car's charging port while still providing slack. Ensure there is a stud available at the desired location for mounting the charging station. (See Fig. 5.4.1) Ensure there is WiFi signal available. Fig.
  • Page 20 Mark the mounting hole on the wall with the installation template. (See Fig. 5.4.4) Fig. 5.4.4 Drill the mounting holes on the wall with a depth of at least 1.97". (See Fig. 5.4.5) Fig. 5.4.5 Hammer the expansion sleeve into the corresponding hole (See Fig. 5.4.6) 1.97"...
  • Page 21 Fix the bracket to the wall with the expansion screws (See Fig. 5.4.7) included in the package. Fig. 5.4.7 5.5 Plug-in Installation For plug-in installation, confirm that the wall bracket has been fixed on the wall. Consult an electrician for any NEMA 14-50 installation questions. Determine the plug type purchased by the homeowner.
  • Page 22 5.6 Hardwire Installation The hardwire installation needs to be done by electricians, and please strictly follow the safety precautions. Remove the four screws on the back cover with a Phillips screwdriver. (See Fig. 5.6.1) Fig. 5.6.1 Remove the three screws with flat-blade screwdriver and take off the cable wire from the terminal block. (See Fig.
  • Page 23 Unscrew the bolts at the bottom of the charging station (See Fig. 5.6.3). You can use a large wrench if needed. Fig. 5.6.3 Take out the cable wire, and remove the magnet ring. (See Fig. 5.6.4) Fig. 5.6.4...
  • Page 24 Unscrew all six screws with the Phillips screwdriver, and take the back cover off. (See Fig. 5.6.5) There is another bolt hidden underneath the UL certification label. Please remove the lable to unscrew the bolt. Fig. 5.6.5 Unscrew the cable clip, and take out the cable from the bottom hole. (See Fig. 5.6.6) Fig.
  • Page 25 Crimp the service wiring with the crimping plier (See Fig.5.6.7) Fig. 5.6.7 Pass through the service wiring from the right bottom hole. (See Fig. 5.6.8) Fig. 5.6.8 Ensure the service wiring can easily reach the connectors on the charging station’s input terminal block. Fully insert the wires into the connectors on the terminal block with the ground wire on the right.
  • Page 26 Before inserting the power input cable, you can deform the service wire with crimping plier. Insert the exposed wires into the corresponding holes, pushing the cables up until the silver conductors are no longer visible. 5.7 Network Cable Installation We strongly recommend that you use a Wi-Fi network when conditions permit. Please refer to Section 6 or the Quick User Guide for details on how to configure your network.
  • Page 27 5.8 Charging Dock Installation Please make sure the space on the wall is at least 2.12" × 2.12" (54mm × 54mm). 54mm 54mm Place the installation template on the wall and mark the mounting hole. (See Fig. 5.8.1) Fig. 5.8.1 Drill the mounting holes on the wall with a depth of at least 1.97".
  • Page 28 Fit the charging plug socket into the charing dock (See Fig. 5.8.3) Fig. 5.8.3 Fix the charging dock on the wall with the expansion screw in the package. (See Fig. 5.8.4) Fig. 5.8.4 Please put the charging plug back to the Charging Dock after each charge.
  • Page 29 Section 6—Network Configuration 6.1 Wi-Fi Configuration To configure the Wi-Fi, please download the PulseQ application from the APP Store or Google Play and install the app to your phone. (See Figure 6.1.1) Fig.6.1.1 Register an account with your email address and login. (See Figure 6.1.2) Open the app and tap the User Center, select Charging Station Management (See Figure 6.1.3) Fig.6.1.2 Fig.6.1.3...
  • Page 30 Tap the cross at the bottom right to add your charging station. (See Figure 6.1.4) Select the Wi-Fi network. (See Figure 6.1.5) Fig.6.1.4 Fig.6.1.5...
  • Page 31 Tap the TOPDON- AC Home to connect the hotspot. (See Figure 6.1.6) Tap the Wi-Fi Setting, enter the Wi-Fi name and password to set up the connection. (See Figure 6.1.7) Fig.6.1.6 Fig.6.1.7...
  • Page 32 Once the above steps have been done, tap Confirm to complete the procedure. (See Figure 6.1.8) Fig.6.1.8...
  • Page 33 6.2 Wired Network Configuration Open the app and tap the User Center, select Charging Station Management. (See Figure 6.2.1) Tap the cross at the bottom right to add your charging station. (See Figure 6.2.2) Fig.6.2.1 Fig.6.2.3...
  • Page 34 Select the Ethernet Setting. (See Figure 6.2.3) Please read the note carefully and tap Next. (See Figure 6.2.4) Fig.6.2.3 Fig.6.2.4...
  • Page 35 Scan the QR code which is attached on the charging station. (See Figure 6.2.5) Scan QR code Fig.6.2.5 ▷ The above steps can only be carried out after the ethernet cable is installed to the charging station.
  • Page 36 Section 7—LED Indicators The LED indicators on the panel are used to indicate the status of the charger and the various combinations of indicators are described below. Icon Indicator Color Indicator Status Connotation Standby status Green Twinkle Ground fault status Connected to an EV Green BLN control...
  • Page 37 Section 8—Fault Handling If All LED are not on, please check： ▷ Whether the power supply and distribution are normal; ▷ Whether the branch breaker is tripped, and close the breaker after troubleshooting; ▷ Whether the connection is correct; if the cable comes off, it should be properly reconnected and tightened.
  • Page 38 Notice: All information in this manual is based on the latest information available at the time of publication and no warranty can be made for its accuracy or completeness. TOPDON reserves the right to make changes at any time without notice.
  • Page 39 Section 10—FCC This device complies with Part 15 of the FCC Rules. Its operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired EN I 29 operation.
