2. Press the Seating function selector keys A and B or move
the joystick left or right several times until the desired
seating function lights up. Refer to Understanding
Displayed Symbols and Meanings, page 22.
3. Deflect the joystick to the front or rear to activate the
actuator.
The distance you deflect the joystick determines the
dynamics of the movement.
If you deflect the joystick only a little, the actuator
moves slowly.
If you deflect the joystick as far as you can, the
actuator moves faster.

Understanding Displayed Symbols and Meanings

Not every wheelchair has all options.
Powered seat tilt
Powered recline
Elevating seat
Left or center-mount powered elevating legrest
Right powered elevating legrest
Both powered elevating legrests
None
Unspecified

6.12.3 Speed Reduction and Seating Function Inhibits

The mentioned speed reduction and seating function
inhibits do not apply to all Invacare wheelchair models.
60126083-B

Speed Reduction

If the elevating seat is adjusted above a certain point, the drive
electronics considerably reduce the speed of the wheelchair. If
speed reduction is activated, drive mode can be used only to
carry out movements in reduced speed and not for regular
driving. To drive normally, adjust the elevating seat until the
speed reduction is deactivated again.
Speed reduction is shown in the status display. If the elevating
seat is raised above a certain point, the elevating seat symbol
and the drive symbol pulse. These two symbols continue
pulsing while driving to show the speed reduction until speed
reduction is deactivated.

6.13 Charging the Batteries

WARNING!
Risk of Injury or Damage
Using the wrong battery charger may cause
explosion and destruction of batteries. To
avoid injury or damage:
-Only use the battery charger supplied with your
mobility device or a charger that has been approved
by Invacare.
WARNING!
Risk of Injury or Damage
Explosive gases can be generated while charging. To
avoid flammable gas buildup and injury or damage
due to explosion:
-During charging, keep the wheelchair and battery
charger away from sources of ignition, such as
flames and sparks.
-Charge the wheelchair in a space at least twice the
volume of the wheelchair.
WARNING!
Risk of Injury, Damage or Death
Improper routing of the charger cord(s) may cause a
tripping, entanglement or strangulation hazard that
may result in injury, damage or death.
-Ensure all charger cord(s) are routed and
secured properly.
-Close supervision and attention is needed when
charging the wheelchair near children, pets or
people with physical/mental disabilities.
WARNING!
Risk of Injury or Damage
Using a damaged extension cord may cause fire and
electric shock. To avoid injury or damage:
-Only use an extension cord if it is absolutely
necessary. If you must use one, make sure it is in
good condition.
