3 ACCESSORIES

3.1 Accessories supplied with the unit

Installation Fittings
Name
Installation and owner's
manual(this book)
Technical data manual
Y-shape filter
Wired controller
Drian hose
Energy label
Network matching
wires
Protect Angle

3.2 Accessories avaliable from supplier

Thermistor for buffer tank temp.(Tbt)
Connection wiring of Tbt sensor
Thermistor for Zone 2 flow temp.(Tw2)
Thermistor for Tbt,Tw2 can be shared. If necessary, you can
purchase other thermistors and connection wiring from the
supplier.
The position of barycenter for different units can be seen in the picture below.
A
C
Quantity
Shape
1
1
1
1
1
1
1
1

4 BEFORE INSTALLATION

Before installation
Be sure to confirm the model name and the serial number
of the unit.
Transport
Due to relatively large dimensions and heavy weight, the
unit should only be hoised by lifting tools with slings, please
refer to the following picture.
Protect Angle
To avoid injury, do not touch the air inlet or aluminum fins
of the unit.
Do not use the grips in the fan grills to avoid damage.
The unit is top heavy! Prevent the unit from falling due to
improper inclination during handling.
B
Model
1 phase 5/7/9kW
1 phase 12/14/16kW
3 phase 12/14/16kW
06
Foam
Protect Angle
The hook and
barycenter of the
unit should be on
a line in vertical
direction to
prevent improper
inclination
CAUTION
A
(unit:mm)
A A B C
350 355 285
540 390 255
500 400 275
