Order
Code
number
12
START DATE
AUTO RESTART
13.1
COOL/HEAT MODE
POWER INPUT
14.1
LIMITATION
15.1
M1M2
15.2
SMART GRID
15.3
T1T2
15.4
Tbt
15.5
P_X PORT
16.1
PER_START
16.2
TIME_ADJUST
16.3
ADDRESS RESET
17.1
HMI SET
17.2
HMI ADDRESS FOR BMS
17.3
STOP BIT
18.1
t_DELAY PUMP
t1_ANTILOCK PUMP
18.2
18.3
t2_ANTILOCK PUMP RUN The pump anti-lock running time.
18.4
t1_ANTILOCK SV
t2_ANTILOCK SV RUN
18.5
18.6
Ta_adj.
18.7
F-PIPE LENGTH
18.8
PUMP_I SILENT OUTPUT The pump_I max output limitation.
The setting range of the above parameters can be queried by scanning the QR code below.The QR code also includes:
1) FOR SERVICEMAN (The password to enter FOR SERVICEMAN is 234)
2) MODBUS MAPPING TABLE
3) CHANGE RECORD OF QR CODE
State
The start date of floor drying up
Enable or disable the auto restart cooling/heating
mode. 0=NON,1=YES
The type of power input limitation
Define the function of the M1M2 switch:0= REMOTE
ON/OFF,1= TBH ON/OFF,2= AHS ON/OFF
Enable or disable the SMART GRID:0=NON,1=YES
Control options of Port T1T2:0=NON,1=RT/Ta_PCB
Enable or disable the Tbt:0=NON,1=YES
Select the function of P_X PORT:0=DEFORST,1=ALARM
Start-up percentage of multiple units
Adjustment time of loading and unloading units
Reset the address code of the unit
Choose the HMI: 0=MASTER
Set the HMI address code for BMS
Upper computer stop bit:1=STOP BIT1,2=STOP BIT2
The time that the compressor has run before starting
the pump.
The pump anti-lock interval time
The valve anti-lock interval time.
The valve anti-lock running time.
The corrected value of Ta inside wired controller.
Select the total length of the liquid pipe(F-PIPE
LENGTH):0=F-PIPE LENGTH<10m,1=F-PIPE
LENGTH>=10m
43
Default
Unit
The present
d/m/y
date
1
/
/
0
0
/
0
/
0
/
0
/
0
/
10
%
5
min
FF
/
0
/
1
/
1
/
2
min
24
h
60
s
24
h
30
s
-2
°C
0
/
100
%
