940 nm Fiber Isolator
3.1.
Polarization Independent Optical Path Schematic
Isolator
Housing
Input
Fiber
Collimating
Lens
Birefringent
Beam Displacer
Page 4
Light Polarization
Faraday
Rotator
Light Polarization
Chapter 3: Description
Half-Wave
Plate
Birefringent
Beam Displacer
Forward Mode
Reverse Mode
Output
Fiber
Collimating
Lens
TTN152257-D02
