FORENO MUR035 Quick Start Manual

Muro Chrome Shower Mixer
with Diverter
MUR035
9 421027 594272
Congratulations on your purchase of this high quality product from Foreno Tapware.
Please read the following before installation and retain (along with your receipt) for future reference.

TECHNICAL SPECIFICATIONS

Suitable for Mains Pressure only
Minimum Pressure = 150kPa
Maximum operating Pressure = 500kPa
Maximum operating Temperature = 65 deg. Celsius
For domestic use only.

CONFIGURATION

Mains Pressure systems Install as supplied.
Unequal Low systems
Equal Low systems

INSTALLATION

Installation must comply with Section 5.4 of AS/NZS 3500 Standard with regard to Isolating stop cock use. Shower
mixers must be water tested with the outlet open, to prevent damage to cartridge seals; due to back pressure.
• The red (or H) marked port is for the hot supply line which is to the left side (looking on - please refer to the
diagram above).
• Inline filters are recommended, particularly on the cold water supply line, to ensure cartridge longevity.
Failure to install an inline filter may void the warranty.
• Any water seepage ex-the cartridge cavity opening can be stopped by re-tightening the large brass retaining nut.
• Turn on mains supply. Check for leaks.
Plumbers Note: Do not pressure test this mixer under static pressure.
FORENO TAPWARE (NZ) LTD | Freephone: 0508 FORENO | info@foreno.co.nz | 5 Hewlett Street, Port Whangarei 0110 | FORENO.CO.NZ
This product is not suitable for this type of water pressure.
This product is not suitable for this type of water pressure.
45mm
160mm
60-65mm
