Assembly Instructions & User's Manual
for
Members Mark Hastings 9PC Regular Dining Set
Item Number:
Model Number: AAX08800-9SC
Customer Assistance
: 1-800-416-3511
(spare/replacement parts)
or Email: customerservice@agio-usa.com
THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Page 1
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
Advertisement
Table of Contents
Related Manuals for Members Mark Hastings AAX08800-9SC
Summary of Contents for Members Mark Hastings AAX08800-9SC
- Page 1 Assembly Instructions & User's Manual Members Mark Hastings 9PC Regular Dining Set Item Number: Model Number: AAX08800-9SC Customer Assistance : 1-800-416-3511 (spare/replacement parts) or Email: customerservice@agio-usa.com THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
-
Page 2: Table Of Contents
Table of Contents Quality Statement.............3 Important Safety Information..........3 Before Assembly..............3 Package Contents............4 Product Information............5 Swivel Rocker Components..............6 Hardware..............6 Tools................6 Step1.................7 Table Components...............8 Hardware..............8 Tools................8 Step1-Step5............9-11 Care & Use and Storage Instructions.........12 Warranty Information............12 Page 2 Need Assistance? Visit us at: samsclub.com/membersmarkhelp... -
Page 3: Quality Statement
Quality Statement Important Safety Information Please read all instructions carefully before assembling this furniture. For your safety, assembly by two or more adults is strongly recommended. Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item. Hardware may loosen overtime. -
Page 4: Package Contents
Package Contents 1Set / 2Ctn Box 1 of 2： Component Quantity Description Dining Chair Swivel Rocker Furniture Cover Box 2 of 2： Component Description Quantity Dining Table Page 4 Need Assistance? Visit us at: samsclub.com/membersmarkhelp... -
Page 5: Product Information
Product information Weight Factory Description Dimensions Part No. Capacity Assembly Dining Chair 250lb per seat AAX08800 25.5" W *24.25" D *34.5" H A.Foot Cap FC0607 Weight Factory Description Dimensions Part No. Capacity Assembly Swivel Rocker 250lb per seat AAX08801 25.5" W *24.25" D *34.5" H A.Foot Cap FC0175 Factory... -
Page 6: Components
Components CHAIR FRAME SWIVEL BASE & ROCKER Part No.AR20323 ASSEMBLY Qty 1 Part No.AR20324 Qty 1 Hardware (H1) (H2) (H3) 5/16" X 40 MM BOLT Ø8.0 X 2.3 MM SPRING WASHER "U" METAL PLATE PART NO:HW0806 PART NO:HW0003 PART NO:HW0618 Qty: 4 Qty: 4 Qty: 2... -
Page 7: Step1
Step 1 (H1) (H2) (H3) 5/16" X 40 MM BOLT Ø8.0 X 2.3 MM SPRING WASHER U" METAL PLATE Qty: 4 Qty: 4 Qty: 2 (H4) (H6) (H7) 5/16" NUT HEX WRENCH-1 HEX WRENCH-2 Qty: 4 Qty: 1 Qty: 1 CAUTION: 1.Note the horseshoe shape of the rocker plate. -
Page 8: Components
Components TABLE TOP LEG CONNECTOR LEG CONNECTOR Part No. AT73200 BRACKET-1 BRACKET-2 Qty 1 Part No. AT73201 Part No. AT73202 Qty 1 Qty 1 TABLE LEG Part No.AT3203 Qty 4 Hardware (H3) (H1) (H2) 1/4" NUT 1/4" X 20 MM BOLT Ø6.5 X 1.0 MM WASHER PART NO:HW0014 PART NO:HW0802... -
Page 9: Step1-Step5
Step 1 - Step 4 Step 1 (H1) (H2) 1/4" X 20 MM BOLT Ø6.5 X 1.0 MM WASHER Qty: 8 Qty: Hand tighten only 2-3 turns. Step 2 (H2) (H3) Ø6.5 X 1.0 MM WASHER 1/4" NUT Qty: 16 Qty: 16 Hand tighten only 2-3 turns. - Page 10 Step 3 (H5) (H6) HEX BOLT DRIVER HEX WRENCH Qty: 1 Qty: 1 Step 4 CAUTION: Please read the instruction in step 5 carefully before you extend the table top to full size. Page 10 Need Assistance? Visit us at: samsclub.com/membersmarkhelp...
- Page 11 Step 5 How to Extend Table Top Warning: Please make sure the top Step 1 is locked before use Step 2 unlock locked unlocked Step 4 Step 3 lock Retracting Extended Table Top unlock Step 2 Step 1 Step 3 Step 4 lock Page 6...
-
Page 12: Care & Use And Storage Instructions
Care & Use Instructions CARE AND MAINTENANCE FRAMES Cleaning - Use mild soap and warm water. Do not use abrasive materials, cleansers or bleach products. Rinse with clean water and dry thoroughly. Maintenance - Periodically clean and dry thoroughly. Be sure to drain any water accumulated inside the frames. - Page 13 Distributed by Sam's West Inc. 2101 SE Simple Savings Dr. Bentonville, Arkansas 72716-0745 Made in China Page 13 Need Assistance? Visit us at: samsclub.com/membersmarkhelp...
