Page 2 Welcome Airbag Warning Labels Welcome to your new Aston Martin Vantage. This Owner’s Handbook has been designed to explain the Warning: Extreme Hazard: NEVER use a rearward facing vehicle’s operation and to make the control of its systems easy to child restraint on a seat protected by an ACTIVE AIRBAG in understand and operate.
Page 3 Component Location Vehicle Battery Disposal All directions for locating components are described as viewed It is the responsibility of the vehicle owner when disposing of from the driver’s seat, i.e. the fuel filler flap shown on this automotive batteries to do it in an environmentally correct diagram will be described as ‘located at the rear right side of the manner.
Page 4 Vehicle Identification Event Data Recorder (EDR) The Vehicle Identification Number (VIN) is shown in the left side This vehicle is equipped with an event data recorder (EDR). bottom corner of the windscreen. The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle's systems performed.
Page 5 National Highway Traffic Safety Administration known to the State of California to cause cancer, and birth (NHTSA) in addition to notifying Aston Martin Lagonda of North defects or other reproductive harm. In addition, certain America Inc., 9920 Irvine Center Drive, Irvine, CA 92618, USA.
Page 6 Driving Safety • Always wear your seat belt. • Never drive under the influence of alcohol or drugs. • Always obey all speed and traffic laws and regulations. Never drive faster than the posted speed limit or than conditions allow. •...
Page 7 The Aston Martin Heritage Trust is an educational charity dedicated to the preservation, promotion and enhancement of over 100 years of history of Aston Martin. Its world class collection comprising the automotive museum, substantial archive and collection of historical artefacts is housed in the magnificently restored Grade II* listed barn in Oxfordshire which it shares with the Owners' Club.
Page 8 Aston Martin Owners' Club (AMOC) An invitation to join the Aston Martin Owners' Club The sporting spirit of the 1930s exists today in one of the world’s most exclusive car clubs. Enthusiasts in nearly 60 countries are united by an interest in iconic cars with an enviable pedigree.
Page 9 Produced by the Technical Publications Department Aston Martin Lagonda Limited Banbury Road Gaydon Warwick CV35 0DB England Telephone: +44 (0)1926 644300 Issue 1: March 2019 Part Number: LY63-19A321-HA...
Page 10 Vehicle Settings..............10 Aston Martin Dealer for further information Maintenance and Technical Data ......... 11 Copyright Aston Martin Lagonda Limited, 2018. All Rights Service ................... A Reserved. This publication is provided with your vehicle for your Aston Martin Warranty ............B personal, private and non-commercial use.
Page 11 Quick Start Vehicle Key ................. 1.2 Driving Position..............1.3 Vehicle Controls ..............1.6 Infotainment ..............1.11...
Page 12: Vehicle Key
Vehicle Key Global Close What Do The Buttons On The Key Do? (Refer to ’Vehicle Key’, page 2.2) Press and hold to unlock all vehicle doors and open all windows. Press and hold to lock all doors and close all windows. Keyless Entry To unlock the vehicle with Keyless-Go active, fully push the front edge of the door handle.
Page 13: Driving Position
Driving Position How Do I Adjust The Seat? [1] BOLSTER/LUMBAR ADJUSTMENT SELECTOR SWITCH (OPTIONAL): Press the switch up to select lumbar adjustment. (Refer to ’Seat Adjustment’, page 3.2) Press down to select bolster adjustment. [2] BOLSTER/LUMBAR ADJUSTMENT: Use the directional pad to adjust the position of the lumbar or bolster support.
Page 14 What Do The Door Switches Do? [A] DOOR MIRROR SELECTOR: Press to select left or right door mirror (Refer to ’Exterior Mirrors’, page 3.7). [B] DOOR MIRROR ADJUSTMENT: Use the direction pad to adjust the mirror position. [C] WINDOW SWITCH: Press or pull to operate the driver or passenger windows (Refer to ’Electric Windows’, page 3.5).
Page 15 How Do I Adjust The Steering Column? How Do I Use The Memory Positions? (Refer to ’Setting a Memory Position’, page 3.9) (Refer to ’How Do I Use The Memory Positions?’, page 1.5) Push the lever down or up to adjust the steering column angle. Setting a Position Pull the lever towards you to bring the steering wheel closer and Adjust the seat, steering column and the door rear view mirrors...
Page 16: Vehicle Controls
Vehicle Controls What Do The Lower Switches Do? [1] HAZARD WARNING SWITCH: Press to set the hazard warning lamps on or off. [2] PARK DISTANCE CONTROL: Press to set the Park Distance Control (PDC) sensors to on or off. [3] REVERSE CAMERA: Operates the camera system. [4] RADIO: Open the radio menu.
Page 17 What Does The Control Dial Do? [1] CONTROL DIAL: Use to navigate through menus in the infotainment system. Press Control Dial (shown with optional Touch Pad) down to confirm a selection (referred to as ENTER throughout this handbook). [2] TOUCH PAD: Touch sensitive pad which can be used to navigate menus in the infotainment system.
Page 18 What Are The Steering Wheel Controls? [1] ADAPTIVE DAMPING: Press to cycle adaptive damping modes (Refer to ’Adaptive Switches Damping’, page 5.16). [2] START VOICE CONTROL: Press to start voice control (Refer to ’Voice Control’, page 4.16). [3] MENU HOME: Press to open the instrument cluster menu (Refer to ’Instrument Cluster Menu’, page 4.13).
Page 19 [6] CALL: Transmission Paddles Press to answer an incoming call (Refer to ’Calls’, page Pull back on either paddle to enter Touchtronic mode (Refer to 7.5). ’Touchtronic Controls’, page 5.7). [7] MENU BACK: Press to take the instrument cluster menu back one level. [8] HORN: Push to sound the vehicle horn.
Page 20 What Do The Stalks Control? Wiper Controls Indicators and Headlamp Beam Rotate the wipe speed selector (A) to select a wipe speed. [1] : Windscreen wipers OFF Main Beam [2] : Intermittent wipe (low rain sensor sensitivity) Push the stalk for main beam headlamps. Pull the stalk back to [3] : Intermittent wipe (high rain sensor sensitivity) the initial position to return to dipped beam headlamps.
Page 21: Infotainment
Infotainment How Do I Turn On The Exterior Lamps? How Do I Activate The Vehicle Bluetooth? Bluetooth® must be activate on both the vehicle and the mobile device to be used. Before a Bluetooth® device can be used with the vehicle Bluetooth®, the vehicle's Bluetooth®...
Page 22 Bluetooth® devices in its range. Select Aston Martin Vantage from the device list. If Aston Martin Vantage does not show, check that Bluetooth is active in the infotainment system and search again. Follow the instructions shown on the phone and the infotainment display to pair the phone.
Page 23 How Do I Pair A Bluetooth Audio Device How Do I Change The Media Source? (Refer to ’Bluetooth Connection’, page 8.14) Press or select Media from the main menu with to show the Bluetooth® audio must be paired to the vehicle available media sources.
Page 24 What Can I Listen To? Portable Media Audio Radio Press on the centre stack or select Media from the main (Refer to ’Radio’, page 8.4) menu to open the media Now Playing screen. The Now Playing screen shows track information such as album Press on the centre stack or select Radio from the main art, artist and album name on the left side of the screen along...
Page 25 What Can I Watch? How Do I Set A Navigation Destination? Portable Media Video (Refer to ’Destination’, page 9.9) Video files from portable media can also be supported with the Press or Select Nav to open the Navigation screen. infotainment system. In the Now Playing screen, highlight the Select Destination from the lower information bar and select view window area and press ENTER.
Page 26 1.16 Quick Start...
Page 27: Table Of Contents
Vehicle Security Vehicle Key ................. 2.2 Unlocking and Opening ............2.5 Emergency Access and Start..........2.9 Anti-Theft Systems............. 2.11 Garage Door Opener ............2.13...
Page 28: Vehicle Key
If a vehicle key is lost, contact your Aston Martin Dealer. If the vehicle key is not in the vehicle, the message 'Key Not Found' will be displayed in the instrument cluster when trying to start the vehicle.
Page 29 Global Close Vehicle Key Battery Battery Power Conservation You must be within 2m of the vehicle to operate Global Close. Keyless Go can be deactivated to conserve battery power in the vehicle key. Press and hold to unlock all vehicle doors and open all To deactivate Keyless Go, double tap windows.
Page 30 Keyless Go Zones 2. Push down on the battery to tilt the battery (B) and allow access. The Keyless Go function for vehicle locking and ignition will operate when a vehicle key is inside the vehicle cabin or in one of the below reception zones: 3.
Page 31: Unlocking And Opening
Unlocking and Opening Unlocking From Outside the Vehicle Using Keyless Entry To unlock the vehicle with Keyless-Go active, fully push at point Using The Vehicle Key (A) and grab the emerging door release. The front edge of the Stand within 5 m of the vehicle, point the vehicle key towards the door handle will press a switch and search for the vehicle key vehicle and press .
Page 32 Locking From Outside the Vehicle Unlocking From Inside the Vehicle Using The Vehicle Key Both doors can be locked and unlocked by using the master Close all the vehicle doors. Stand within 5 m of the vehicle, point unlock (1) and lock (2) switches located on the centre stack.
Page 33 Easy Entry/Exit Automatic Relocking If the vehicle is unlocked but a door is not opened within 40 The Easy Entry/Exit function could cause an occupant to seconds, the vehicle will automatically lock and arm again. become trapped and/or cause injury. Keep clear of the Automatic Locking Feature steering wheel when the Easy Entry/Exit function is used.
Page 34 Tailgate Opening the Tailgate Inside the Vehicle Press and hold the tailgate release button (B). The tailgate catch Opening The Tailgate Outside the Vehicle will then release. Press and hold (A) on the vehicle key to enable the release catch and lift the Tailgate. Closing the Tailgate If the vehicle is locked when is pressed, the doors will...
Page 35: Emergency Access And Start
ON). gain access to the vehicle. Caution: If the vehicle has lost power, the door may If the emergency key is lost, contact your Aston Martin require extra effort to open due to the window not dropping Dealer. down. If this does happen, gently press against the top of the window whilst opening the door.
Page 36 Emergency Engine Start 3. Open the armrest cover. If the keyless start system fails to start the vehicle, the engine can be started with the emergency start system. To start the engine: 1. Lift the battery cover (A). 2. Press the cap release button (B) and remove the key end cap (C).
Page 37: Anti-Theft Systems
• Interior movement and tilt (tow-away) sensor. When the security system is armed, any attempt to forcibly open If the keyless ignition system fails, contact your Aston Martin a door, the trunk lid or the hood will result in full alarm operation.
Page 38 Alarm Interior Motion Sensor When the alarm has started a siren will be heard for a 25 seconds When the vehicle is locked and armed, the interior motion sensor cycle (ten cycles maximum) and the direction indicators flash will sense movement inside the vehicle. If movement is detected it will start the alarm.
Page 39: Garage Door Opener
(Difficulties may be experienced trying to reach the toll-free number by some providers in certain countries.) Alternatively, contact your Aston Martin Dealer. Warning: Do not use the transceiver with any garage door opening system that lacks the safety stop and reverse feature as required by safety standards.
Page 40 Programming FCC Warning: This device complies with FCC rules part 15 and Industry Canada RSS-210. Operation is subject to the Step 1 erases all programming and is only necessary if following two conditions: (1) This device may not cause programming HomeLink for the first time or when erasing all harmful interference, and (2) This device must accept any existing programming.
Page 41 1. Press and hold the two outer HomeLink buttons, until the 3. Simultaneously push the remote control button and the HomeLink LED (A) begins to flash after 20 seconds. desired button (1, 2 or 3). All three buttons are now cleared. The HomeLink system is 4.
Page 42 Operation Rolling Code Synchronisation To check if the garage door opener (or other device) has a rolling The vehicle should be within the operating range of the gate or code feature: garage door opener and the ignition should be ON. •...
Page 43 Reprogramming To synchronize for a rolling code: 1. Locate the training or programming button on the motor To program a HomeLink button to a new device: head unit for the garage door opener . Refer to the 1. Press and hold the desired HomeLink button (1, 2, or 3) for operating instructions of the garage door opener.
Page 44 2.18 Vehicle Security...
Page 45 Before Driving Checks Before Driving ............3.2 Seat Adjustment ..............3.2 Electric Windows ..............3.5 Mirrors ................3.6 Steering Column ..............3.8 Memory Functions .............. 3.8 Occupant Restraint System..........3.10 Child Safety............... 3.17 Child Seat Installation ............3.22 Cabin Storage..............3.25 Accessory Sockets..............
Page 46: Checks Before Driving
Checks Before Driving Seat Adjustment Inspect your vehicle to make sure that everything is according to Warning: Do not attempt to adjust the drivers seat whilst the information and specifications in this Owner’s Guide. driving. Outside the Vehicle: The seats can be adjusted when the vehicle is at ignition position "I"...
Page 47 Seat Controls [1] LUMBAR/BOLSTER ADJUSTMENT SELECTOR SWITCH: Press the switch up to select lumbar adjustment. Press down to The ignition must be ON before the lumbar and bolster select bolster adjustment support can be operated. [2] LUMBAR/BOLSTER ADJUSTMENT: Use the directional pad to adjust the position of the lumbar or bolster support [3] SEAT POSITION ADJUST: Seat forward/backward and height adjust.
Page 48 Seat Back Release Head Restraints The driver and passenger seats include non-adjustable head Caution: Make sure that the headrest for the seat does not restraints, which limit the rearward travel of the head in a rear hit the sun visor. The seat can cause damage to the sun visor impact and may reduce whip lash injuries.
Page 49: Electric Windows
Electric Windows Press or pull past resistance on the window switch to perform a Warning: Misuse of the window switches, especially by one-touch movement down or up. children, can result in injury due to entrapment in the window closure. Drivers must advise all passengers of the Pull the window switch back to raise the window.
Page 50: Mirrors
Mirrors Interior Mirrors Door Sealing Warning: Make sure that all passengers are clear when the window mechanism is operating. To minimize wind noise and to make sure that the window seal is watertight, a door sealing system is used to provide a tight fit of the door glass to the seals around the top of the door opening.
Page 51 Exterior Mirrors Heated Mirrors When the heated rear window is ON the heaters in the door To adjust the exterior mirrors press the mirror switch (A) left or mirrors will operate for 6.5 minutes. right to select a side to adjust. Move the direction pad (B) up, down, left or right to adjust the selected mirror.
Page 52: Steering Column
Steering Column Memory Functions Adjustment (Optional) Warning: Make sure that there is nothing in the Warning: Do not adjust the steering wheel whilst driving. movement path of the seat or the steering column during The steering column can be adjusted with the ignition set to adjustment that could cause obstruction.
Page 53 Setting a Memory Position Driver's Seat Warning: Do not attempt to adjust the seat whilst driving. Adjust the seat, steering column and the door rear view mirrors to the desired position. Push the memory button (M), then press the required memory channel (1, 2 or 3) to save the positions. A chime is heard and a message will show in the message centre to confirm.
Page 54: Occupant Restraint System
Occupant Restraint System The system provides protection to the driver and all passengers in All of these systems are controlled by the Occupant Restraint a variety of impact conditions. Controller (ORC). In a collision the ORC will analyse information from various sensors, such as crash and seat occupancy The system consists of: conditions.
Page 55 Do not put an adult seat belt If either of these conditions occur, even intermittently, have the around two children. restraint system serviced at your Aston Martin Dealer immediately. Unless serviced, the system may not operate Warning: When installed, the seat belt webbing must not contact any sharp edges which could abrade or cut the correctly in the event of a collision.
Page 56 Make sure that belt webbing is not twisted, looped, frayed or obstructed in any way. If in doubt about condition or operation of seat belt installation, have it checked by your Aston Martin Dealer. 3.12 Before Driving...
Page 57 Pre-tensioner and Load Limiting Seat Belt Fastening Seat belts are equipped with dual pre-tensioners and load When parked on an incline, the seat belt may lock as it is limiting systems. withdrawn. This is not a fault. If the mechanism locks, release the In most moderate frontal or near frontal accidents, the front belt tension and then pull the belt very gently to avoid operation airbag and all pre-tensioner systems will deploy simultaneously.
Page 58 Pull out the seat belt, drawing the buckle over the shoulder and Pull upwards on the diagonal belt to make sure that the latching across the chest. is secure and to remove all slack from the belt. Check that the lap belt is installed snugly, low down across the hips, and that there are no twists.
Page 59 Airbags Seat Belt Unfastening Push the button on the buckle. While holding the seat belt The purpose of the airbags is to provide additional protection for buckle, allow the belt to slowly retract to its stored position. the driver and passenger in the event of a serious impact (front or side impacts).
Page 60 The side airbags (D) located in the front seats and the curtain Airbag Deployment airbag (E), located in the roof trim, only deploy according to Warning: The use of accessory seat covers may prevent which side has been impacted in a serious side collision. the deployment of the seat side airbags and increase the risk of injury in an accident.
Page 61: Child Safety
Child Safety Airbags inflate rapidly and with considerable force; there is Aston Martin strongly recommends that a child, regardless of therefore a risk of death or serious injury such as fractures, facial age, should always be restrained when travelling in a vehicle.
Page 62 Warning Labels Your vehicle has the following devices for the installation of child restraints: Warning: Extreme Hazard: NEVER use a rearward facing • Passenger seat with Occupant Classification System (OCS) child restraint on a seat protected by an ACTIVE AIRBAG in (Refer to ’Occupant Classification System’, page 3.19)and top front of it.
Page 63 Occupant Classification System If the front passenger seat is occupied by an adult, the PASS The Occupant Classification System (OCS) is part of Occupant AIRBAG status symbol will be set to (A). restraints Control (ORC) System and operates in addition to the The passenger airbag will be set to off if: restraints system.
Page 64 OCS to incorrectly classify a seat occupant. Wait for the material, must be inspected by an Aston Martin Dealer. The seat to dry completely before use. Make sure that there are system must also be checked for corrected functionality.
Page 65 Seating Position Warning: Incorrect installation of a child seat may cause the passenger sensing system to leave the front airbag set to Warning: Always sit upright against the seat backrest and on. Always make sure that child seats are correctly installed with both feet on the floor.
Page 66: Child Seat Installation
Do not attempt to repair or service the system. Take the vehicle between the child seat and the tether anchor point. immediately to the nearest Aston Martin Dealer. A tether is a strap that connects the top of a child seat to a tether anchor point on the vehicle to reduce excessive movement of the child seat in the event of a collision.
Page 67 Child Seat Installation ALR Operation Gently pull out the seat belt until fully extended. The ALR system Warning: Always follow the child seat manufacturer’s will only engage at the maximum extension point of the seat belt. instructions for correct installation. Not following the child Thread the belt tongue through the child seat as per the child seat seat manufacturer’s instructions when installing the child manufacturer instructions.
Page 68 Passenger Seat Installation Top Tether To install a child seat to the passenger seat using the seat belt, use The tether anchor point for the passenger seat is located at the the procedure that follows: rear base of the passenger seat. Move the seat forward to access the tether anchor point.
Page 69: Cabin Storage
Cabin Storage Door Pockets Armrest Storage Box Both front doors have door pockets. The armrest storage box gives access to the media interface panel (SD card port and two USB ports), a 12V accessory power socket Do not use the door pocket to store items that could easily and the emergency ignition switch.
Page 70 Luggage Space Parcel Shelf The parcel shelf can be removed to increase the available height Trunk Divider in the luggage compartment. to remove the parcel shelf: The trunk divider can be raised or lowered to create a partition • Pull the parcel shelf down off the locating lugs. or increase load capacity.
Page 71: Accessory Sockets
Accessory Sockets Ashtray and Cigar Lighter Warning: Only connect accessories which are designed for use in a motor vehicle with a 12V electrical system. The (Optional) electrical system could become damaged if there is more Warning: The cigar lighter will be very hot when in use. than 10A used from the accessory socket.
Page 72 3.28 Before Driving...
Page 73 Controls Instrument Display .............. 4.2 Centre Stack Controls ............4.5 Steering Wheel Controls ............ 4.11 Instrument Cluster Menu ........... 4.13 Voice Control ..............4.16 Wiper Controls..............4.17 Lighting Controls ............... 4.17...
Page 74: Instrument Display
The left instrument display is used to provide warnings and park brake. A warning message will also show in the right important information for the running of the vehicle. instrument cluster window. Contact your Aston Martin Dealer as soon as possible. [2] PARK:...
Page 75 This symbol shows there is a fault with the EPAS system. Consult systems test and then turn off. If this symbol stays on or comes on your Aston Martin Dealer as soon as possible. while driving there is a fault in the ABS control circuits. Continue...
Page 76 Instrument Cluster Overview [4] INSTRUMENT CLUSTER MENU: Shows an auxiliary screen for a number of vehicle functions (Refer to ’Instrument Cluster Menu’, page 4.13). Warning messages will also appear in the right side of the instrument cluster. [5] CLOCK: Shows the time. [6] DRIVE MODE SETTING: Shows which drive mode the vehicle is in (Refer to ’Drive Modes’, page 5.10).
Page 77: Centre Stack Controls
Centre Stack Controls [1] HAZARD WARNING SWITCH: Press to set the hazard warning lamps on or off. [2] PARK DISTANCE CONTROL: Press to set the Park Distance Control (PDC) sensors to on or off. [3] REVERSE CAMERA: Operates the camera system. [4] RADIO: Open the radio menu.
Page 78 Control Dial [1] CONTROL DIAL: Use to navigate through menus in the infotainment system. Press Control Dial (with optional Touch Pad) down to confirm a selection (referred to as ENTER throughout this handbook). [2] TOUCH PAD: (Touch Pad only) Touch sensitive pad which can be used to navigate menus in the infotainment system.
Page 79 Touch Pad Menu Navigation The touch pad can be used to mirror the functions of the control (Touch Pad only) dial to navigate menu systems. For example, where an instruction Touch Pad ON/OFF in this handbook states to scroll left with the CONTROL DIAL, To activate the TOUCH PAD navigate to the Vehicle Settings you can swipe left on the TOUCH PAD.
Page 80 Quick Access Menu Use two fingers and swipe down on the TOUCH PAD surface or press the QUICK ACCESS button again to close the Quick Access To open the Quick Access menu for audio and telephone, use menu. two fingers and swipe upwards on the TOUCH PAD surface or press the QUICK ACCESS button.
Page 81 Rotary Controls Image Pan The touch pad can also be used to operate rotation controls such To pan an image such as the map, press the TOUCH PAD as equalizer settings or 3D map rotation. Use two fingers to touch surface, until the crosshair is shown and swipe in the direction the TOUCH PAD and rotate either clockwise or counter- you which to pan.
Page 82 Handwriting Recognition Character Suggestion Where text needs to be entered, such as writing a text message, To select between character suggestion, turn the CONTROL DIAL characters can be 'written' using the TOUCH PAD. To begin and press ENTER on the highlighted option. handwriting recognition, press ENTER on the TOUCH PAD.
Page 83: Steering Wheel Controls
Steering Wheel Controls Character Delete To delete a character, swipe to the left on the TOUCH PAD. Add Space To add a space character, swipe to the right on the TOUCH PAD. Read Out handwriting Recognition ON/OFF The handwriting recognition system can also be set to read characters out as they are written.
Page 84 [1] ADAPTIVE DAMPING: [7] MENU BACK: Press to cycle adaptive damping modes (Refer to ’Adaptive Press to go back one level in the instrument cluster menu. Damping’, page 5.16). [8] HORN: [2] START VOICE CONTROL: Push to sound the vehicle horn. Press to start voice control (Refer to ’Voice Control’, page [9] END VOICE CONTROL: 4.16).
Page 85: Instrument Cluster Menu
Instrument Cluster Menu Use the button (A) to open the menu home screen. Scroll through the available options with the menu scroll wheel (B) and select an item by pressing the scroll wheel button (referred to in this handbook as the OK button). Press the to go back a menu level.
Page 86 Trip Navi The trip menu will show journey information about the vehicle. Shows the next turn if a route has been set. If no route has been From the trip menu select: set, shows direction of travel. • From Start: Distance travelled, journey time, average fuel consumption and average speed are shown from when the ignition was turned ON.
Page 87 Media Settings Shows the selected media track. The settings menu changes settings related to the instrument vehicle and driver functions. Select from: Change Track • Assistance: Press to open the media track list. Use the scroll wheel to select • Blind Spot Assist a track.
Page 88: Voice Control
Voice Control Individualisation Individualisation is a function that can help refine the Voice Control system to your own voice. To begin individualisation, navigate to Vehicle on the main menu and select System Settings on the lower information bar. Select Voice Control and select Individualisation.
Page 89: Wiper Controls
Wiper Controls Lighting Controls Exterior lamps Master Lamp Switch Turn the dial to the required light setting or press the fog lamp button. Rotate the wipe speed selector (A) to select a wipe speed. [1] : Windscreen wipers OFF [2] : Intermittent wipe (low rain sensor sensitivity) [3] : Intermittent wipe (high rain sensor sensitivity) [4] : Continuous wipe (slow) [1] : Left side park lamp...
Page 90 Automatic Headlamp Mode Stalk Controls If ambient light fades, headlamps, side marker, rear and registration plate lamps will switch ON automatically. If ambient light then increases, headlamps, side marker, rear and registration plate lamps will automatically switch OFF. Automatic lamps are market specific. The automatic headlamp function features an internal timer that starts when the lamps are turned on.
Page 91 Interior Lamps Hazard lamps The hazard warning lamps will continue to operate if the Instrument Illumination ignition is switched off. During the daylight hours the level of instrument brightness defaults to maximum brightness. During the twilight and night Press the hazard warning lamp button (A) to set the hazard time hours, a twilight sensor located at the top of the windscreen warning lamps to on.
Page 92 Reading Lamps Two reading lamps (A) are located in the front header trim. To operate the lamps (on or off) use the reading lamp switch for either side (B). Unless set to off or on they will continue to operate up to six minutes after the ignition is set to off.
Page 93 Driving Driving Techniques ............. 5.2 How To Start The Engine............. 5.4 Transmission Controls............5.5 Cruise Control ..............5.8 Drive Modes ..............5.10 Blind Spot Assist ..............5.12 Adaptive Damping ............5.16 Brakes ................5.17 Electronic Stability Program (ESP)........5.23 Tire Pressure Monitoring System (TPMS)......5.26 Eco Driving Features............
Page 94: Driving Techniques
To make sure that you have a safe and enjoyable Performance driving courses are available to enable you to fully entry into this new phase of Aston Martin motoring, please take understand the control functions of your vehicle and also the time to safely acquire the necessary new driving skills.
Page 95 Wet Conditions Driving Through Deep Water When driving in wet conditions, water can build up under your If in any doubt whether to drive through deep water, always take tires so that they ride on a layer of water. This is called the side of caution to avoid potentially costly damage to the aquaplaning or hydroplaning.
Page 96: How To Start The Engine
How To Start The Engine Warning: The engine can be started by any person in the Caution: Make sure the park brake is applied and the vehicle if the brake pedal is pressed down. Care should be transmission is in PARK (P). taken that the vehicle is not left unattended with the key To start the engine, fully press the brake pedal down and press present and occupants such as young children inside.
Page 97: Transmission Controls
Transmission Controls Touchtronic Mode The automatic transmission has two main driver modes. Automatic Mode In Touchtronic mode, forward gears and Neutral are selected by using the paddles located behind the steering wheel. Reverse and In Automatic mode, gearshifts are made using the Park, Reverse, Park are selected by using the PRND buttons.
Page 98 PRND Buttons [1] P (PARK): Press and release to select Park when the vehicle is stationary. The transmission will mechanically lock. Caution: Always make sure that the park brake is ON. This will help to make sure the vehicle will not roll. It is not possible to select Park above 2 km/h.
Page 99 Touchtronic Controls Pull back on either the upshift (+) or downshift (-) paddle to enter Touchtronic mode. As the vehicle speed increases and decreases, Forward gearshifts are selected by pulling back and releasing the make upshifts and downshifts by pulling and releasing the upshift gearshift paddles mounted on the steering column.
Page 100: Cruise Control
Cruise Control Operation Warning: Only use cruise control if road and traffic conditions are appropriate for maintaining a steady speed Cruise control can be used to maintain a selected vehicle speed for a prolonged period. without having to use the accelerator. Cruise control only operates at speeds above 18mph.
Page 101 Setting A Speed Deactivating Cruise Control Lightly push the cruise control lever up to increase speed, or Push the cruise control lever away from you to deactivate cruise down to decrease speed in 1 mph increments. A hard press in control.
Page 102: Drive Modes
Drive Modes Vehicle driving characteristics, such as gear changes and throttle The selected mode will be shown in the right instrument cluster response, can be changed by selecting different drive modes. window (B). Three drive modes are available. Press the S button (A) to cycle Drive modes operate independently of Electronic Stability between: Program (ESP) and Adaptive Damping System (ADS) modes.
Page 103 Sport Mode Sport+ Mode Sport mode provides a default sport setting, best suited to Sport+ mode uses a more aggressive transmission casual and motorway driving. calibration. The transmission is set to use a base transmission The transmission now uses a more aggressive calibration calibration when in Drive to suit a touring style of driving.
Page 104: Blind Spot Assist
Blind Spot Assist Track Mode Warning: Blind Spot Assist is for visual aid only and does not replace the need for driver awareness. It is the driver's Track mode further increases transmission and engine responsibility to be aware of their surroundings and make response.
Page 105 Operation Conditions If a vehicle is detected at speeds above approximately 30 km/h (18 mph) and enters the monitoring range directly next to your For the Blind Spot Assist system to operate the below conditions vehicle, the warning lamp in the exterior mirror will illuminate must be met: amber.
Page 106 Blind Spot Warnings System Limitations The BSA system can be limited in its operation in the below Stage One Warning situations: When the BSA system detects a vehicle in the driver's blind spot • The sensors are dirty or obstructed such as snow or mud on area, an amber LED triangle (A) will be shown in the top outer the bumpers.
Page 107 • A vehicle is detected in the blind spot area. message will also show in the instrument cluster. Contact your • The indicator is used to signal movement into that lane. Aston Martin Dealer. FCC - Radio Frequency Devices When this happens, the below actions will take place.
Page 108: Adaptive Damping
Adaptive Damping Canada The Adaptive Damping System (ADS) uses sensors to continuously monitor vehicle body movement and driver inputs, This device complies with Industry Canada license-exempt RSS such as steering, braking and throttle input. The system then standard(s). Operation is subject to the following two conditions: adjusts the suspension damping characteristics to suit the (1) this device must not cause interference, and (2) this device conditions.
Page 109: Brakes
Brake action may be delayed and increased braking pressure may be required. Warning: Aston Martin recommend that the brake fluid is replaced after the vehicle is used for high performance driving such as a track day. Failure to do so may result in Sport greatly reduced brake performance.
Page 110 Contact conditions. However, an inherent characteristic of this braking your Aston Martin Dealer. system is some brake noise. Certain combinations of speed, Carbon ceramic brake systems combine low weight with high...
Page 111 In the event of an ABS fault, have the braking and ABS systems • The brake booster system has a fault and braking performance checked immediately by an Aston Martin Dealer. may be affected. ABS and Electronic Stability Program (ESP) Warnings •...
Page 112 ABS compared to locked wheels on slushy snow, gravel, sand or certain heavily corrugated or ridged warning sections of road surfaces. If any braking system malfunctions, have the braking and ABS systems checked immediately by your Aston Martin Dealer. 5.20 Driving...
Page 113 Warning: If the brake system warning symbol is ON or condition the pads may result in greatly reduced brake flashing, do not rely on the park brake to hold the vehicle performance. Contact your Aston Martin Dealer for further stationary. Contact your Aston Martin Dealer. information.
Page 114 Park Brake Operation While Moving The park brake operates on the rear wheels of the vehicle. Warning: Repeated use of the park brake to slow the Caution: Secure parking of the vehicle is dependent on vehicle, or driving the vehicle with the park brake applied being on a hard and stable surface.
Page 115: Electronic Stability Program (Esp)
(TCS). Active Yaw Control (AYC) is also modified to allow a higher Aston Martin Dealer. There is a sensor in the steering system level of yaw. ABS is set to stage two. When the ESP is set to track, which detects steering angle.
Page 116 Two-Stage Anti-lock Braking System (ABS) To change ESP mode To change the ESP modes the engine ignition must be on with the The Anti-lock Braking System (ABS) will change its operation depending on ESP mode. transmission in gear. Press and hold the ESP switch (A) for 4 Stage One seconds to change from ON to Track mode.
Page 117 Electronic Differential (E-Diff) Stage Two When ESP is set to Track or OFF, the ABS is tuned to allow more This vehicle features an Electronic Rear Differential (E-Diff), experienced drivers to drive closer to the limits of the vehicle's which works with the ESP system to adjust and control how the ability and enjoy its natural balance in a track environment.
Page 118: Tire Pressure Monitoring System (Tpms)
Tire Pressure Monitoring System (TPMS) Traction Control System (TCS) As an added safety feature, your vehicle has been equipped with a tire pressure monitoring system (TPMS) that illuminates a low The Traction Control System (TCS) is a function of ESP and is used to prevent excessive wheel spin at standing starts, or during tire pressure telltale when one or more of your tires is...
Page 119 Tire Pressure Display Tire Pressure Indicator The TPMS display is shown in the right window of the instrument If an under-inflated tire is detected by the system, the TPMS cluster. Use the right scroll wheel on the steering wheel to symbol is solidly illuminated.
Page 120 TPMS Reset TPMS Malfunction Warning The TPMS malfunction indicator is combined with the low tire All warning messages are erased and warning lamps go out pressure telltale. When the system detects a malfunction, the when the TPMS is reset. The TPMS will use the new tire pressure telltale will flash for approximately one minute and then remain values as reference values.
Page 121: Eco Driving Features
Eco Driving Features Stop/Start Engine Stop Conditions With Stop/Start active, the engine will switch off when the vehicle The Stop/Start function switches the engine off when the vehicle is completely stopped, the transmission is in either D (Drive) or N comes to a stop to reduce fuel consumption and emissions.
Page 122: Park Assist Systems
Park Assist Systems Engine Start Conditions Warning: The park assist systems are for aid only. It is the The engine will automatically start again when: driver's responsibility to be aware of their surroundings when parking or reversing. • The engine has been switched off for 3 minutes. •...
Page 123 Activation Operation PDC will activate automatically at ignition on and when D Caution: In heavy rain or similar adverse conditions, the (Drive), R (Reverse) or N (Neutral) is selected. The sensors PDC sensors may not always be able to accurately measure activated depend on which gear is selected.
Page 124 Active Park Assist (Optional) Active Park Assist measures the road on both sides of the vehicle to locate a parking space the vehicle will fit in. The active park system will also provide vehicle steering to assist parking in spaces. Important Safety Information Active Park Assist is only an aid.
Page 125 Parking Space Detection Caution: Parking spaces that are partially occupied may be measured incorrectly. Examples of partially occupied parking Active Park Assist operates at speeds of up to approximately spaces can be trailer draw bars, over grown parking spaces or 22 mph (35 km/h).
Page 126 Active Park Assist does not assist with parking in right angle space Parking with Active Park Assist When a parking space has been found and is shown in the • two parking spaces are located directly next to each other instrument cluster, stop the vehicle and select R (Reverse).
Page 127 360° Camera System Activation Caution: The camera system can show a distorted or To activate the 360° camera, press the button or select 360° incorrect view of obstacles or not at all. Obstacles will not be cameras from the Vehicle Settings menu. The camera will show shown under, or in very close proximity to, the front or rear the split screen with either the front or rear view, depending on bumpers.
Page 128 View Selection 180° View To select the different views, push up on the CONTROL DIAL to When the camera shows the front or rear view, select 180° view. the view selection bar. The split-screen views that can be shown This will replace the split-screen view and show a much wider are: angle for the front or rear.
Page 129 Top View with Park Distance Control (Front and Rear views) Top View with Corner Views To aid with parking the vehicle, a dynamic overlay screen will be The corner view cameras show both sides of the vehicle from the shown over the camera image. The overlay screen adjusts with door mirrors.
Page 130 5.38 Driving...
Page 131 Climate Control Climate Controls ..............6.2 Climate Menu ..............6.5 Defrost and Demist ............. 6.8 Air Distribution Vents ............6.8 Climate Control Operating Tips ........... 6.9...
Page 132: Climate Controls
Climate Controls Centre Stack Climate Controls [1] AIR DISTRIBUTION: Press the rocker switch up or down to change airflow modes. [2] TEMPERATURE: Rotate the dial to increase or decrease the temperature. [3] AIR CIRCULATION: Warning: Re-circulated air can cause the interior glass to mist up in cold or rainy weather.
Page 133 [5] A/C: [10] SEAT HEATING/COOLING (OPTIONAL): When in manual mode press and release to set the air Warning: Do not press the seat heater switch repeatedly. conditioning ON or OFF. This can cause the seat to become very hot and can cause [6] AIRFLOW SPEED: burn injuries to persons with limited sensitivity to temperature changes.
Page 134 Infotainment Climate Controls Automatic Climate Control The temperature is maintained at a set level in automatic mode. The climate system will automatically control the temperature, airflow and the air distribution according to the interior and exterior conditions. To set a temperature for automatic operation: •...
Page 135: Climate Menu
Climate Menu Manual Climate Control The climate control system can also be operated within the infotainment system. Use the CONTROL DIAL or the applicable Manually set the temperature, airflow speed and air distribution: rocker switch or dial to adjust each function. Warning: Re-circulated air can cause the interior glass to Climate Mode mist up in cold or rainy weather.
Page 136 Temperature Air Distribution Rotate the CONTROL DIAL to set the temperature. Rotate the CONTROL DIAL to choose an air distribution mode. Climate Control...
Page 137 Airflow Climate Options Rotate the CONTROL DIAL to choose an airflow speed from [1] SYNC.: between 1 and 7 or AUTO. Select to synchronize the left and right climate zones. Only one setting dial will be shown when climate conditions are being set. If SYNC is set to OFF, push the CONTROL DIAL left or right to select which zone to adjust.
Page 138: Defrost And Demist
Defrost and Demist Air Distribution Vents To adjust the air vents, use the vent knob (A). Push up or down Caution: To defrost or demist the windscreen on vehicle to adjust the blades inside the vent. Push left or right to adjust the start up in extreme cold weather conditions, operate the angle of the vent unit.
Page 139: Climate Control Operating Tips
If the climate control system is low on refrigerant or and the air inlet below the windscreen to improve the system has a malfunction, consult your Aston Martin Dealer. efficiency. • Mist may come out from the vents when using the air conditioning.
Page 140 6.10 Climate Control...
Page 141 Hands-Free Phone Hands-Free Controls ............7.2 Device Management ............7.2 Phone Features ..............7.5...
Page 142 Hands-Free Controls Device Management Bluetooth® technology is a standard for short-range wireless data transmissions up to approximately 10 metres. Bluetooth can be used to connect your mobile device to the vehicle infotainment system. This system can then be used to operate the hands-free phone system, Bluetooth audio streaming and internet access.
Page 143 Bluetooth® devices in its range. Select Aston Martin Vantage from the device list. If Aston Martin Vantage does not show, check that Bluetooth® is active in the infotainment system and search again. Follow the instructions shown on the phone and the infotainment display to pair the phone.
Page 144 You cannot change the active device during a call. Press ENTER to confirm. It is recommended that the device Aston Martin Vantage is also removed from the Bluetooth® connected devices on your mobile device.
Page 145 Phone Features Contact Lists Calls Make a Call The contact list displays all available contacts for your phone contacts which have a phone number. A call can be made in several ways: • Choose a contact from the Contacts list. To access the contact list press on the centre stack or •...
Page 146 Multiple Call Handling Second Incoming Call (Network Provider Dependant) If there is an incoming call during an active call, press Add a Call answer the new call and put the original call on hold. To make a second call during a call, select the 2ND CALL icon To reject the call press , or select Reject Call and press and select a contact.
Page 147 Messages [1] BACK: Return to phone menu. The connected mobile phone must support Message Access [2] SETTINGS: Profile (MAP) to be able to access text and email messages. This may have to confirmed separately for some devices when paired Opens the message settings to set automatic message downloads. to the vehicle.
Page 148 Message Entry [1] TEXT TEMPLATES: Opens a list of common phrases to be entered into a message. [2] RETURN: Starts a new line of text. [3] CASE: Switch between upper and lower case characters. [4] NON-ALPHABETICAL CHARACTERS: Show numbers and miscellaneous characters. [5] LANGUAGE: Select to open the languages list.
Page 149 Media Systems Audio Specification ............. 8.2 Multimedia Controls............8.4 Radio .................. 8.4 Satellite Radio ..............8.5 Media ................. 8.9 Media Menu ..............8.11 Media Register ..............8.14 Bluetooth Audio ..............8.14 Sound ................8.15...
Page 150: Audio Specification
Audio Specification Radio • Satellite Radio. • AM and FM radio. Audio Inputs • 2 x USB ports in centre storage tray. • SD Card reader in centre storage tray. • Bluetooth® Wireless technology. Media Systems...
Page 151 Aston Martin Standard Audio Aston Martin Premium Audio Power Output Power Output 4 Channel Audio system. 10 Channel 640W Audio System. Speakers Speakers [1] TWEETERS: [1] TWEETERS: Two 25 mm / 1 inch tweeters. Two 25 mm / 1 inch tweeters.
Page 152: Multimedia Controls
Multimedia Controls Radio Press on the centre stack or select Radio from the main menu to open the Radio screen. The display area will show the currently selected radio station and available radio stations. [1] RADIO: Open the Radio screen (Refer to ’Radio’, page 8.4). Opens the radio source list if media screen is already open.
Page 153: Satellite Radio
Satellite Radio Radio Stations Satellite or radio modes can be temporarily interrupted or unavailable for a number of reasons such as: Selecting a station from the display screen • Tunnels. The display screen shows available stations that can be played. •...
Page 154 Selecting a channel Options Channel Browse Tag This Track The display screen shows available channels that can be played. Select to store the track and music artist currently being played Push the CONTROL DIAL with the centre display highlighted to Stored tracks can then be later purchased in the iTunes®...
Page 155 To Set a Sports Alert Service Select Options from the lower information bar and select Alert The provider's customer service centre is available by phone at any time to answer any general questions or questions on the for Artist, Track & Sports Event. versions available.
Page 156 Presets Band The centre display can be set to show stored preset stations Select between SiriusXM®, HD Radio FM and HD Radio AM. instead of available stations. Information To set preset view ON or OFF, select Presets from the lower Select whether to show the available channels list or information information bar and select Station Preset View.
Page 157: Media
Media Media Sources Press on the centre stack or select Media from the main Press MEDIA or select Media from the main menu with to show menu to open the media Now Playing screen. the available media sources. Rotate the CONTROL DIAL and Now Playing screen layout will depend on the media device press ENTER to select a media source.
Page 158 Media Formats and File Systems File Systems USB and SD Memory Card Media Formats • FAT16 Audio • FAT32 • .MP3 • exFAT • .WMA • NTFS • AAC formats • .aac • .mp4 • .m4a • .m4b It is recommended to use tracks of at least 128 kbit/s bit rate and 44 kHz sampling rate to prevent a loss of sound quality.
Page 159: Media Menu
Media Menu Options On the lower bar of the Media screen there will be several options: Media Options • Options • Play/Pause • Search • Devices • Sound • Play similar tracks • Play mode • Direct track entry • Skip to time •...
Page 160 Play Similar Tracks Save Files to Media Register Play tracks that are of the same genre. Save the current file or files to vehicles internal hard drive. Play Mode Manage Media Register Select from Normal Track Sequence, Random Track List or Opens the Media Register options menu.
Page 161 Search Devices Search for a media file from a list of the below information fields: • Current tracklist • Folder • Select by cover • Keyword Search • Artists • Albums • Tracks • Genres • Year • Composers • Videos •...
Page 162: Media Register
Media Register Bluetooth Audio Bluetooth Connection The media register can be used to store music, picture and video files directly on the vehicle's hard drive. Bluetooth® audio must be paired to the vehicle Storage capacity for the media register is approximately 10.8 independently from the Bluetooth®...
Page 163: Sound
Sound Options The Sound menu screen can be accessed from either the Radio or Media screens. • Bluetooth Audio Devices • Equalizer • Play mode • Balance/Fader • Volume • Sound Field Bluetooth Audio Devices Equalizer Opens menu to manage Bluetooth® devices. Adjust the Treble, Mid-tones and Bass frequencies between -10 Play Mode and 10...
Page 164 8.16 Media Systems...
Page 165 Satellite Navigation Safety Information ............... 9.2 Navigation Controls ............. 9.2 Navigation Menu..............9.3 Options................9.4 Traffic ................. 9.6 Route .................. 9.7 Position ................9.8 Destination ................. 9.9 Navigation Menu............... 9.13...
Page 166: Satellite Navigation
Safety Information Navigation Controls Warning: Failure to avoid the following potentially hazardous situations could result in an accident or collision resulting in death or serious injury. Warning: Always use your best judgement, and operate the vehicle in a safe manner. Do not become distracted by the navigation system while driving, and always be fully aware of all driving conditions.
Page 167: Navigation Menu
Navigation Menu Audio Controls From the navigation menu select from the following options: • OPTIONS (Refer to ’Route Settings’, page 9.4) Use the left scroll wheel on the steering (B) or the volume dial (C) • TRAFFIC to adjust the volume for navigation announcement. Press and (Refer to ’Traffic’, page 9.6) hold the scroll wheel button during a navigation announcement •...
Page 168: Options
Options Route Settings Avoid Options Select from the following options: Choose from the following route settings: • Avoid Area • Fast Route Select Avoid New Area and choose from: Finds a route with the shortest journey time. • Using Map •...
Page 169 Map Orientation Map Content Select to change the orientation of the display map. Select from: Choose from the following map content options: • North Up • POI Symbols on Map Map is displayed so that north is always up. • Standard Symbols: •...
Page 170: Traffic
Traffic Personal POIs Traffic Reports from FM RDS-TMC An RDS-TMC radio station transmits traffic reports in addition to Load any saved personal points of interest from an SD Memory the radio programme. your vehicle can receive these reports and Card. make adjustments to the route guidance.
Page 171: Route
Route Read Out All Message On Route Destination Information Select to read out traffic reports along the route. If there are no Shows the destination and any intermediate destinations along traffic reports this option will not be available. with expected arrival time, distance and journey time. To cancel the report being read, select Cancel Read-Aloud Select a destination to view details.
Page 172: Position
Position Detour Save Manually add an area to avoid on the route. Save the current position to the From previous destination list. Saved destination will have a symbol next to the location name. Select Beginning and press ENTER. Rotate the CONTROL DIAL POI Symbol Guide to move through the route and press ENTER to set the beginning detour area.
Page 173: Destination
Destination 3D Map Rotation Cancel Route Guidance View the area around the vehicle in a 3D perspective. Rotate the Select to cancel current route guidance. CONTROL DIAL to change the direction of view or push the Address Entry CONTROL DIAL to move the map cursor in that direction. Select to open the address entry screen Where Am I? Shows the current position.
Page 174 Keyword Search Once you have entered one of the above items of information you can filter your search further by adding more information to Keyword search can be used to find a location without having the above or entering one of the following: to enter the full name.
Page 175 From Previous Destinations Addresses Shows a list of both exact and approximate addresses that match Search from a list of previously entered addresses. Scroll through your search terms. Exact matches are shown at the top of the list the list of available locations and press ENTER to select a in alphabetical order.
Page 176 From POI Using Map Select to choose a location based on a point of interest. Find a destination using the map display. Move the cursor by pushing the CONTROL DIAL in the chosen direction. Rotate the Near Destination CONTROL DIAL clockwise to zoom out and counter-clockwise to (Only available while route guidance is active) zoom in.
Page 177: Navigation Menu
Navigation Menu From Memory Card From the navigation display press the NAV button, or push the joystick up, to access the main vehicle menu and navigate to Nav Load a saved route from a SD memory card. to open the navigation menu. This function is only available if a SD Memory card with route In the navigation menu you will be shown the options that follow: data is inserted into the SD card slot.
Page 178 9.14 Satellite Navigation...
Page 179 Vehicle Settings Vehicle Settings ..............10.2 Time Settings..............10.2 System Settings..............10.3...
Page 180 Vehicle Settings Time Settings Acoustic Lock Feedback Automatic Time Settings Set audible lock note ON or OFF. Select to set automatic time settings to ON or OFF. Auto-Fold Mirror Time Zone Set if mirrors are folded when vehicle is locked to ON or OFF. Select the required local time zone.
Page 181 System Settings Favorite Functions Language When Favorite Functions is selected the below menu options are Select the language for the vehicle infotainment system from one available. Rotate the joystick to select: of the below languages: • Navigation • Arabic • Radio •...
Page 182 Voice Control 360° Camera • Help Window Select to choose between activation by R Gear or Object • Start New Individualisation Detection. • Delete Individualisation Touchpad • Individualisation ON Select to set Activate Touchpad or Read Out Handwriting Text Reader Speed Recognition to ON or OFF.
Page 183 Maintenance and Technical Data Introduction ..............11.2 Servicing Precautions............11.3 Fault Conditions ..............11.5 Vehicle Lifting ..............11.6 Owner Maintenance Checks ..........11.7 Hood Release..............11.8 Fluid Checks and Capacities ..........11.9 Washers and Wipers ............11.13 Chassis Systems ............... 11.15 Wheels and Tires.............
Page 184: Maintenance And Technical Data
Aston Martin Dealer. If you think that this vehicle is not functioning correctly, please return it to an Aston Martin Dealer to be checked professionally. The electronic fuel injection system requires specialist equipment and test facilities to set up and maintain so that the vehicle gives...
Page 185: Servicing Precautions
The cooling fan may operate even though the or cause increased pollution. If it is evident to Aston Martin engine is not operating. that use of products other than those which are...
Page 186 Dangerous Substances Warning: Do not breathe exhaust fumes. Exhaust fumes contain carbon monoxide. Carbon monoxide is a dangerous Warning: Dangerous substances should be kept out of gas, which is colourless and odourless and can cause reach of children. unconsciousness and may be fatal. Never start or leave the Warning: Many liquids and other substances used in engine running in an enclosed, unventilated area.
Page 187: Fault Conditions
3rd or 6th gear depending on the vehicle speed at the disposal of waste oil and toxic fluids. the time of the fault. Contact your Aston Martin Dealer. Protect The Environment In certain circumstances forward drive will be restricted to a Warning: It is illegal to pollute drains, water courses, or fixed gear.
Page 188: Vehicle Lifting
Vehicle Lifting If this vehicle is to be raised using a vehicle jack make sure that Warning: Make sure that no persons are in the vehicle the following jacking points are used. before the vehicle is lifted. Warning: Make sure that the park brake is applied and that the vehicle transmission is in P (Park).
Page 189: Owner Maintenance Checks
Owner Maintenance Checks Engine Oil Level In the interests of safety and reliability, it is advisable to carry out the following checks at the intervals suggested (more frequently if Caution: It is important to check the engine oil level your vehicle is heavily used or operating in adverse conditions), regularly.
Page 190: Hood Release
Hood Release To open the hood, pull the lever (A) located under the instrument panel to release the hood latch. The hood will rise but stay secured by the hood secondary catch. To close the hood lower the hood until it starts to fall under its own weight.
Page 191: Fluid Checks And Capacities
Warning: Engine components may be hot and could cause The charge-cooler system is maintenance free and should severe burns. only require checking by your Aston Martin Dealer during regular vehicle services. Engine Oil Level Warning: Engine oil or components may be hot and could cause severe burns.
Page 192 Engine Oil Level Check: Engine Oil Level Sensing • The vehicle should be on level ground. Caution: The electronic engine oil level sensing system • Check the engine oil level every fourth fuel tank fill or weekly does not replace the need for the owner to regularly check - which ever is the sooner.
Page 193 Engine Coolant Level Brake Fluid Level Warning: Do not remove the filler cap until the coolant Warning: Do not drive the vehicle if the brake fluid level system has cooled. Scalding can be caused by escaping steam is below the minimum mark. or coolant.
Page 194 A fully synthetic 0W-40 oil meeting the specifications detailed below can be used. No other viscosity grades or specifications are acceptable. Authority Standard Engine Coolant Contact your Aston Martin Dealer for information on engine ILSAC coolant. Brake Fluid DOT 4 11.12...
Page 195: Washers And Wipers
If in doubt, and top up as required. In winter, to prevent the windscreen consult your Aston Martin Dealer. wash fluid freezing, increase the fluid concentration (refer to the manufacturers recommendations on the windscreen wash fluid HFC134A / HFO1234YF container).
Page 196 Wiper Blade Replacement Local or state regulations may restrict the use of volatile organic compounds (VOCs), which are commonly used as To remove a wiper blade, lift the wiper arm and press at point (B) antifreeze agents in windscreen washer fluid. A windscreen to release the wiper blade.
Page 197: Chassis Systems
14.1 inches 11.8 m. Calipers Six Piston Four Piston Optional (38.75 ft). Total Toe Front Rear Refer to your Aston Martin Dealer for the correct data. Rotor Construction Ventilated Carbon Ventilated Carbon Suspension Ceramic Ceramic Diameter 410 mm 360 mm Front 16.1 inches...
Page 198: Wheels And Tires
Wheels and Tires Chassis Features Wheel and Tire Information • Three user selectable adaptive damping settings; Front Rear • Sport. • Sport+. Wheel Size 9J x 20 11J x 20 • Track. Tire Size 255/40 R20 (Y) 295/35 R20 (Y) •...
Page 199 Wheel Bolt Torque Tires Tires of the correct type, manufacturer and dimensions, with Caution: You must use an applicable plastic-sleeved correct cold inflation pressures are an integral part of every socket to remove, install, and tighten the wheel bolts. This vehicle’s design.
Page 200 New Tires Stones or other objects which have become lodged in the tire When new tires are required consult your Aston Martin Dealer treads should be carefully removed. for advice if the rear tires are also worn. Each wheel and tire unit...
Page 201 Because of the high performance potential of this vehicle, particularly during the first 80 km (50 mph) or so of driving. Fast Aston Martin strongly recommend replacement of any damaged cornering, hard braking, and harsh acceleration should also be or worn tire.
Page 202 Warning: Do not stand directly beside the tire while the Only use Aston Martin approved winter tires - contact your Aston compressor is pumping. Watch the side wall of the tire. If Martin dealer for more information.
Page 203 Aston Martin Dealer. and repair of tires that have been treated with any form of • If the nearest Aston Martin Dealer is over 200 km (125 miles) temporary mobility aid. Consult a tire specialist for advice. away, contact your Aston Martin Dealer.
Page 204: Department Of Transportation
US Department of Transportation Uniform Tire Quality Grades Temperature The following information relates to the tire grading system Warning: The temperature grade for this tire is developed by the National Highway Traffic Safety established for a tire that is properly inflated and not Administration, which grades tires by tread wear, traction and overloaded.
Page 205 Tire Sidewall Information Information on ‘P’ Type Tires Both US and Canada Federal regulations require tire The tire size, load index and speed rating for your vehicle may manufacturers to place standardized information on the sidewall be different from this example. of all tires.
Page 206 [6] TIRE IDENTIFICATION NUMBER (TIN): (Also known as [8] H: The tire’s speed rating. The speed rating denotes the ‘DOT Code’) The Tire Identification Number (TIN) begins with speed at which a tire is designed to be driven for extended the letters ‘DOT’...
Page 207 Vehicle Loading [9] TIRE TYPE: • M+S or M/S Warning: Overloading the vehicle can negatively affect Mud and Snow the handling and stopping performance of the vehicle tires. • AT Correctly loading this vehicle will provide maximum return of All Terrain vehicle design performance.
Page 208 Labels for US vehicles Labels for Canadian Vehicles The illustrations shown are examples and may not accurately describe the labels on this vehicle. 11.26 Maintenance and Technical Data...
Page 209 If any after Payload: Make sure that the payload (cargo + passengers) does market or Aston Martin Dealer installed equipment has been not exceed this limit. installed on the vehicle, the weight of the equipment must be subtracted from the payload listed on the Tire Label in order to Tire sizes: The size of tires to be used on this vehicle.
Page 210 Determining the Correct Load Limit Maximum Permissible Inflation Pressure 1. Locate the statement ‘The combined weight of occupants The maximum permissible inflation pressure is the tire and cargo should never exceed XXX kg or XXX lb’ on the manufacturer’s maximum permissible pressure and / or the vehicle’s tire label.
Page 211 Safety Practices Tire Terminology Tire Label: A label showing the OE (Original Equipment) tire Warning: If your vehicle is stuck in snow, mud, sand, etc, sizes, recommended inflation pressure and the maximum weight do not rapidly spin the tires; spinning the tires can tear the the vehicle can carry.
Page 212: Electrical Systems
Electrical Systems Fuses Cold Inflation Pressure: The tire pressure when the vehicle has been stationary and out of direct sun light for an hour or more The electrical systems are protected by fuses. If any lamps, and prior to the vehicle being driven for 1 mile (1.6km). accessories, or controls do not function, inspect the applicable Recommended Inflation Pressure: The cold inflation pressure fuse.
Page 213 Front Fuses 11.31 Maintenance and Technical Data...
Page 214 Engine Primary Fuse Box (A) IP Fuse Box (B) 150A Electronic Power Assisted Steering (EPAS) Control Dial Touch Pad 100A Cooling Fan Instrument Cluster Fan 150A Right Side Engine Fuse Box HVAC Module ABS Module Instrument Cluster 100A Right Side Engine Fuse Box OBD Socket 100A Right Side Powerhold Fuse Box...
Page 215 Right Powerhold Fuse Box (C) Left Powerhold Fuse Box (D) ABS Module Engine Control Module Wake up Tire Pressure Monitoring System (TPMS) Tire Pressure Monitoring System (TPMS) Daytime Running Lights Differential Cooling Pump Engine Supply Coolant water pump B Engine Supply Cooling Fan Sound Regulator Coolant water pump A...
Page 216 Right Side Engine Fuse Box (E) ECM Keep Awake Right Side Powerhold Supply ABS Module Starter Motor Left Side Wiper Motor Right Side Wiper Motor Relay Tracker ABS Module Horn 11.34 Maintenance and Technical Data...
Page 217 Rear Fuses 11.35 Maintenance and Technical Data...
Page 218 Rear Primary Fuse Box (F) Rear Primary Fuse Box (G) IP Fuse box (B) Supply IP Fuse box (B) Supply IP Fuse box (B) Supply Fuse Box (I) Supply Fuse Box (J) Supply Fuse Box (I) Supply Fuse Box (J) Supply Fuse Box (I) Supply Fuse Box (J) Supply Fuse Box (I) Supply...
Page 219 Fuse Box (H) Fuse Box (I) Left Side Seat Module Microwave Sensors Camera Module 7.5A Ignition/accessory Relay Control Left Side Seat Lumbar Adjust Left Side Seat Module Keyless Go Module Multimedia Box Charger Port Tuner Box Right Side Seat Module Right Side Seat Lumbar Adjust Tailgate Latch Body Controller...
Page 220 7.5A Occupant Restraint Controller (ORC) The vehicle battery is maintenance free and should only require checking by your Aston Martin Dealer during regular vehicle Seat Comfort Functions services. To access the vehicle battery remove the trim panel, located in the right rear environment.
Page 221 In this case the vehicle battery must be replaced. allow the positive terminal of the battery to contact parts of Contact your Aston Martin Dealer. teh vehicle body. This can create a spark or a short circuit which can ignite gases created when the battery is charged.
Page 222 Caution: Do not attempt to start the vehicle with a battery conditioner connected to the mains supply. The Aston Martin battery conditioner is suitable for use on all types of 12 volt AGM and lead acid batteries. If this vehicle is not going to be used for a period of time, and mains power is available, use a battery conditioner to maintain the battery charge level.
Page 223 Internal Lamps All internal lamps are LEDs and are not repairable. If an LED lamp fails contact your Aston Martin Dealer. If driving the vehicle to recharge the battery, a journey distance of approximately 30 miles or 48 km will be sufficient to recharge the battery.
Page 224: Vehicle Care
Don't use a strong jet, as this can rub grit over the Aston Martin are able to supply a range of products to clean and paint and scratch it. protect your vehicle. Contact your Aston Martin Dealer for 3.
Page 225 Paint Work Ceramic Brake Discs Modern water based paints are much safer and more (Optional) environmentally friendly than solvent based paints. Water based To avoid possible damage to the ceramic brake discs, when paints are however more susceptible to contamination and washing the road wheels with products or materials other than a marking by corrosive substances.
Page 226 In (Optional) order to avoid damage to the satin paint work, make sure that the The Aston Martin new car warranty covers defects in cleaning and care points below are followed: materials or workmanship of the paint work. The warranty 1.
Page 227 Make sure that the vehicle is Consult your Aston Martin Dealer for instructions on the removal well ventilated and follow the manufacturer’s printed of more difficult stains such as oil, grease or ballpoint ink.
Page 228: Powertrain Specifications
Powertrain Specifications 4.0L V8 Engine Firing Order 1 - 5 - 4 - 2 - 6 - 3 - 7 - 8 All alloy 32 valve twin turbocharged V8 engine featuring: Fuel delivery • Independent quad-variable camshaft timing • 3 driver selectable powertrain calibrations Multi-point sequential fuel injection •...
Page 229 Transmission Gear Ratios Touchtronic IV Automatic Transmission 4.714 Rear mounted ZF 8HP70 eight-speed automatic gearbox with 3.143 'Shift by Wire' gear shift and Stop/Start ignition support. 2.106 Front mounted transmission radiator with transmission mounted 1.667 heat exchanger and pump. 1.285 Drive line 1.000 Cast aluminium torque tube with carbon fibre drive shaft.
Page 230: Performance
Performance Dimensions Interior Dimensions Maximum Power 375 kW | 503 Bhp at 6000 rpm Maximum Engine Speed 7000 rpm Front Maximum Torque 685 Nm | 505 Lb.ft at 2000 rpm Effective Headroom 920 mm Maximum Speed 195 mph | 314 km/h 36 Inches (Where Permitted) Effective Leg-room...
Page 231 External Dimensions All dimensions shown in mm. 11.49 Maintenance and Technical Data...
Page 232: Vehicle Recovery
Caution: If there is a transmission fault, this vehicle must be transported. If the park brake was applied and the vehicle has lost power, the park brake will not release. Call Aston Martin Assistance or your local Aston Martin Dealer. Your vehicle should always be recovered on a vehicle...
Page 233 Caution: Apart from vehicle recovery, this vehicle must If the vehicle still will not start, contact your Aston Martin not be driven if the vehicle battery is incapable of starting the Dealer.
Page 234 4. Identify the positive (2) and negative (3) jump start points 6. Connect the negative cable (5) between the negative shown. terminal of the donor battery and the suspension earth (-) nut (5). 5. Connect the positive cable (4) between the positive terminal of the donor battery and the positive (+) jump point (2) on 7.
Page 235: Fuel
2. The second fuel level warning will also show a warning charge the battery. symbol in the right instrument cluster window and replaces Contact your Aston Martin Dealer to have the battery the Range value. The vehicle is now down to half of its checked or replaced.
Page 236 Fuel Filling Fuel Filler Bowl To stop water gathering in the fuel filler bowl and flowing into the The fuel tank filler neck has a restricted opening which will fuel tank, the fuel filler bowl has a pipe to let the water drain from only accept the fuel supply nozzle of unleaded fuel pumps.
Page 237 Fuel Filler Flap Emergency Release • Pull the emergency release (ER) tab to unlock the fuel cap. To manually unlock the fuel filler flap: Caution: The emergency release cable only unlocks the fuel flap. It does not open the fuel flap. Do not pull too hard •...
Page 238 11.56 Maintenance and Technical Data...
Page 239 Service Aston Martin Facilities ............A.2 Vehicle Provenance.............A.3 Pre-delivery Inspection ............A.5 Servicing ................A.8 Service Record ..............A.12 Replacement of Airbag Units ..........A.33 Replacement of Seat Belt Pre-tensioners ......A.33 Brake Rotor Check ............A.34 Field Service Actions ............A.37 Service Action Recalls............A.38...
Page 240: Aston Martin Facilities
Aston Martin franchise can occur. Neither meet the owner’s requirements, but the availability of certain Aston Martin nor any listed Importer or Dealer shall in any parts may be affected by differences in vehicle and component circumstances be held liable for any inaccuracy, or the specifications.
Page 241: Vehicle Provenance
Vehicle Provenance Aston Martin Authorized Body Repairers Model: A full list of Aston Martin Authorized Body Repairers worldwide Vehicle Identification Number: can be found at: As on the VIN plate www.astonmartin.com All Aston Martin Approved Body Repair centres have been assessed and audited to Aston Martin Body Repair Centre standards in either Category A or B.
Page 242 First Owner Fourth Owner Selling Dealer Selling Dealer Delivery Date Delivery Date Second Owner Fifth Owner Selling Dealer Selling Dealer Delivery Date Delivery Date Third Owner Sixth Owner Selling Dealer Selling Dealer Delivery Date Delivery Date Service...
Page 243: Pre-Delivery Inspection
• Throttle pedal operation Aston Martin Limited. • Park brake operation The list below applies to all Aston Martin vehicles. Your Aston • Steering column adjustment and lock operation Martin may or may not have all or some of the functionality listed.
Page 244 Electrical Checks • Seat belt warning system • Security system and vehicle key • Battery condition • Interior lamps • Gear selection • All seat functions • Heated rear window • Door window mechanisms • Windscreen washers • Door and luggage compartment lamps •...
Page 245 Road Test Hand-over Preparation • Engine • Check function of locks and vehicle keys • Transmission • Clean bodywork and road wheel arch liners. • Gear shift operation • Clean off all transit labels • Steering • Valet vehicle • Brakes •...
Page 246: Servicing
The following service schedules are recommended for this which ever occurs first. vehicle. The schedules may be modified if necessary. Please consult your Aston Martin Dealer for details of any service • 10,000 miles, 16,000 km or 12 months schedule updates.
Page 247 16,000 km / 32,000 km / Item 10,000 miles / 20,000 miles / 12 months 24 months Pre Maintenance Work Install the vehicle protection kit. Check the Diagnostic Trouble Codes (DTCs). Under Body Examine the condition, operation and attachment of the engine, transmission mounting system and check for leaks.
Page 248 16,000 km / 32,000 km / Item 10,000 miles / 20,000 miles / 12 months 24 months Upper Body Replace the engine oil. Replace the engine oil filter. 30,000 mls/48,000 km Replace the air filter. Replace the pollen filter (optional). Examine the condition, operation and attachment of the accessory drive belt.
Page 249 16,000 km / 32,000 km / Item 10,000 miles / 20,000 miles / 12 months 24 months General Examine the condition, operation and attachment of all the occupant restraint systems. Examine the condition, operation and attachment of all the door locks, latches, hinges, hood catches. Lubricate if necessary.
Page 250: Service Record
Service Record The following service records cover the regular services at 10,000 miles, 16,000 km or 12 months intervals, which ever occurs first. Make sure that at each service the appropriate entry is stamped and signed as completed. Vehicle Model: _______________________________ Registration Number: _______________________________...
Page 251 10,000 Miles/16,000 km/1st Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 252 20,000 Miles/32,000 km/2nd Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 253 30,000 Miles/48,000 km/3rd Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 254 40,000 Miles/64,000 km/4th Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 255 50,000 Miles/80,000 km/5th Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 256 60,000 Miles/96,000/6th Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No Anti Corrosion Inspection:...
Page 257 70,000 Miles/112,000 km/7th Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 258 80,000 Miles/128,000 km/8th Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 259 90,000 Miles/144,000 km/9th Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 260 100,000 Miles/160,000 km/10th Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 261 110,000 Miles/176,000 km/11th Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 262 120,000 Miles/192,000 km/12th Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 263 130,000 Miles/208,000 km/13th Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 264 140,000 Miles/224,000 km/14th Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 265 150,000 Miles/240,000 km/15th Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 266 160,000 Miles/256,000 km/16th Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 267 170,000 Miles/272,000 km/17th Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 268 180,000 Miles/288,000 km/18th Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 269 190,000 Miles/304,000 km/19th Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 270 200,000 Miles/320,000 km/20 Year Authorized Dealer Stamp Odometer: Technician Name: Service Advisor Name: Date: Service Advisor Signature: Next Service Due: Additional Service Information Service Details Service Actions Checked: Yes / No Air Filter Changed: Yes / No Pollen Filter Changed: Yes / No Spark Plugs Changed: Yes / No...
Page 271: Replacement Of Airbag Units
Replacement of Airbag Units Replacement of Seat Belt Pre-tensioners Aston Martin recommend that all airbag units are replaced every Aston Martin recommend that all seat belt pre-tensioners units 10 years from the date of manufacture. To make sure this is are replaced every 10 years from the date of manufacture.
Page 272: Brake Rotor Check
Brake Rotor Check At each brake pad change (per axle), the ceramic brake rotors are Brake Pads Changed - Brake Rotors Checked required to be cleaned, dried and weighed. Record the date of each brake pad change and rotor weight. Rotor Weight (Front Axle): Rotor Weight (Rear Axle): Odometer:...
Page 273 Brake Pads Changed - Brake Rotors Checked Brake Pads Changed - Brake Rotors Checked Rotor Weight (Front Axle): Rotor Weight (Front Axle): Rotor Weight (Rear Axle): Rotor Weight (Rear Axle): Odometer: Odometer: Signature: Date: Signature: Date: Brake Pads Changed - Brake Rotors Checked Brake Pads Changed - Brake Rotors Checked Rotor Weight (Front Axle): Rotor Weight (Front Axle):...
Page 274 Brake Pads Changed - Brake Rotors Checked Brake Pads Changed - Brake Rotors Checked Rotor Weight (Front Axle): Rotor Weight (Front Axle): Rotor Weight (Rear Axle): Rotor Weight (Rear Axle): Odometer: Odometer: Signature: Date: Signature: Date: Brake Pads Changed - Brake Rotors Checked Brake Pads Changed - Brake Rotors Checked Rotor Weight (Front Axle): Rotor Weight (Front Axle):...
Page 275: Field Service Actions
Field Service Actions Action No. Date Dealer Action No. Date Dealer A.37 Service...
Page 276: Service Action Recalls
Service Action Recalls Action No. Date Dealer Recall No. Date Dealer A.38 Service...
Page 277 12 What Replacement Parts should I use ......B.19 13 Preserve Your Emissions Warranty ........B.20 14 Customer Satisfaction ...........B.20 15 The Better Business Bureau (BBB) Auto Line Program ...B.21 16 State Warranty Enforcement Laws ........B.23 17 Aston Martin Extended Service Contract .......B.23 Owner And Vehicle Details ..........B.24...
Page 278: Aston Martin Warranty
'Serviced Countries' means either: (a) any country in the Region Warwick, from which your Aston Martin vehicle was purchased, where CV35 0DB, there is an Aston Martin authorized dealer or repairer; or (b) any England country agreed in writing with Aston Martin. Aston Martin Warranty...
Page 279 The warranties provided herein are for the benefit of the original A summary of all Aston Martin warranties applicable to this purchaser and any subsequent owner during the relevant vehicle (together the Warranties) are as follows: Warranty Period (defined below). The warranties cover Aston a) New Vehicle Limited Warranty Martin vehicles that are built for and supplied to the Region.
Page 280 Emissions Performance Warranty: Three years or 50,000 miles of 1.4 Reservation of Rights vehicle use. Aston Martin and its Dealers reserve the right to provide post- Warranty repairs, conduct recalls, or extend the Warranty coverage period for certain vehicles or vehicle populations, at Aston Martin’s sole discretion.
Page 281: New Vehicle Limited Warranty
Warranty. No person, including Aston Martin shall not be liable for any damages caused by delay Aston Martin employees or Dealers, can modify or waive any part in delivery or furnishing of any products and /or services.
Page 282: New Vehicle Limited Warranty Statement
4 What is not Covered under the Warranties 3.1 Warranty Maintenance 4.1 Excluded Categories of Vehicle Aston Martin warrants that during the Warranty period, if an The following categories of vehicle are excluded from the Aston Martin vehicle is correctly operated and maintained by the provisions of the Warranties: user in accordance with the Maintenance chapter of the Owner’s...
Page 283 • Cuts, burns, punctures or tears • Use of contaminated or incorrect fuel or fluids or application • Windshield stress cracks of unauthorized chemicals by the customer. • Rodent damage • Incorrect polishing of paint surface. Aston Martin Warranty...
Page 284 The Warranties do not cover: maintenance of the vehicle, or using the wrong fuel, oil, • The installation or use of a non-Aston Martin part (other than lubricants, or fluids is not covered under the Warranties. Refer to a certified emissions part) or any part (Aston Martin or non- the Specifications chapter of the Owner’s Guide for correct fluid...
Page 285 The period of warranty cover for any item may not exceed the • Use of a fuel not approved or recommended by Aston Martin time and distance limitation of the vehicle warranty. in the Owner's Guide is considered misfuelling, and that any damage resulting from misfuelling is not covered by the vehicle warranty.
Page 286: Customer Satisfaction Campaigns
• Wiper blades policy adjustments, your Aston Martin Dealer will advise you of • All light bulbs the extent to which Aston Martin will pay either for parts, or for Xenon headlamp light bulbs and instrumentation light bulbs labor, or both.
Page 287: Anti-Perforation Corrosion Warranty
Corrosion Warranty. Should any part of the bodywork of the Aston Martin provides coverage under the Emissions Defect Aston Martin vehicle be perforated the panel(s) affected by the Warranty (including labor and diagnosis) for repairs of emissions perforation will be repaired or replaced. The term ‘perforation’...
Page 288: Emissions Performance Warranty
8 Emissions Performance Warranty 8.1 Federal Requirements During the Warranty coverage period, Aston Martin warrants that: If your vehicle is registered in a State where the State or Local • Your vehicle or engine is designed, built and equipped to...
Page 289 8.2 What is Covered Under the Emissions Performance Warranty, Aston Martin will repair, replace, or adjust (with no charge for labor, diagnosis, or If the following parts contain an emissions- related defect (an parts) any emissions control device or system, if you meet all of ‘Emissions Related Part’) they will be covered by both the...
Page 290 Warranties. For more details about the specific parts covered by • Pulsed Secondary Air Injection Valve / Secondary Air Injection the Emissions Defect Warranty, contact Aston Martin or Aston Pump and Associated Parts Martin Lagonda of North America Inc. (Refer to ’1.1 Warranty •...
Page 291: California Emissions Warranties
Also included may be hoses, belts, connectors, System Defects Warranty. and other emissions-related assemblies. Where a warrantable condition exists, Aston Martin will repair your vehicle at no cost to you including diagnosis, parts, and labor. Other States adopting California emissions and warranty regulations: Passenger car &...
Page 292 • Camshaft Position Sensor exceed 30 days. • Carbon Canister • Catalytic Converter Aston Martin may deny warranty coverage if your vehicle or a • Charge Air Cooler part has failed due to abuse, neglect, improper maintenance, or • Controls for Deceleration unapproved modifications.
Page 293 • Pulsed Secondary Air Injection Valve / Secondary Air Injection Pump and Associated Parts • Throttle Body Assembly • Volume Air Flow Sensor. Some items and equipment in this list may not be installed to this vehicle and therefore may not be applicable. B.17 Aston Martin Warranty...
Page 294: How Do I Get Service Under The Emissions Warranties
Warranties To get service under your Emissions Warranties, take your vehicle to any Aston Martin Dealer as soon as possible after it has failed Aston Martin strives to make sure that services are available to an EPA - approved test or a California Smog Check inspection.
Page 295: What Replacement Parts Should I Use
Martin parts of equivalent specification. Aston Martin shall only reimburse you if the repairs are If you decide to use non-Aston Martin parts, make sure that they conducted by a Third Party within 30 days from the time you first...
Page 296: Preserve Your Emissions Warranty
13 Preserve Your Emissions Warranty 14 Customer Satisfaction If you do not maintain your vehicle correctly, Aston Martin may If you are not satisfied with any Warranty repairs performed by have the right to deny you coverage under any of its Emissions an authorized Aston Martin Dealer and feel that you have a Warranties.
Page 297: The Better Business Bureau (Bbb) Auto Line Program
BBB Auto Line Program. to Aston Martin may be monitored and / or recorded. The BBB Auto Line Program consists of two parts – mediation and b) If your dispute is in the State of California, contact the arbitration.
Page 298 You are not bound by the decision, but should you choose to You are required to resort to BBB AUTO LINE before exercising accept the BBB Auto Line decision, Aston Martin shall abide by rights or seeking remedies under the Federal Magnuson-Moss the accepted decision as well and will comply with the decision Warranty Act, 15 U.S.C.
Page 299: State Warranty Enforcement Laws
This excluded, and shall be left to the sole discretion of Aston Martin.). will give us the opportunity to make any necessary repairs before b) Aston Martin Emergency Assistance roadside support.
Page 300: Owner And Vehicle Details
If the vehicle is sold, the benefits of any un-expired portion of the Post Code: warranties can be transferred to the new owner. The new owner should complete a ‘tear off’ sheet (next page) and send the new details to: Aston Martin Warranty Department Aston Martin Lagonda Limited Banbury Road Gaydon Warwick...
Page 301 Owner Warranty Transfer (1) VIN No.: VIN No.: Odometer: Odometer: Date of Purchase: Date of Purchase: Name: Name: Address: Address: Post Code: Post Code: Telephone No.: Telephone No.: Email Address: Email Address: Signature: Signature: Date: Date: B.25 Aston Martin Warranty...
Page 302 B.26 Aston Martin Warranty...
Page 303 Owner Warranty Transfer (3) VIN No.: VIN No.: Odometer: Odometer: Date of Purchase: Date of Purchase: Name: Name: Address: Address: Post Code: Post Code: Telephone No.: Telephone No.: Email Address: Email Address: Signature: Signature: Date: Date: B.27 Aston Martin Warranty...
Page 304 B.28 Aston Martin Warranty...
Page 305 Owner Warranty Transfer (5) VIN No.: VIN No.: Odometer: Odometer: Date of Purchase: Date of Purchase: Name: Name: Address: Address: Post Code: Post Code: Telephone No.: Telephone No.: Email Address: Email Address: Signature: Signature: Date: Date: B.29 Aston Martin Warranty...
Page 306 B.30 Aston Martin Warranty...
Page 307 Aston Martin Assistance Aston Martin Roadside Assistance ........C.2 How Does the Plan Work............C.3 Further Information .............C.3...
Page 308 Aston Martin Roadside Assistance In the event of a breakdown caused by a defect covered under The term of the Aston Martin Roadside Assistance scheme runs the New Vehicle Limited Warranty, the Aston Martin Roadside concurrent with the Aston Martin New Vehicle Limited Assistance scheme will provide the Aston Martin owner with Warranty.
Page 309 Martin Roadside Assistance scheme. The terms of the scheme the drivers side door pillar. may be changed without notice. If your Aston Martin vehicle suffers a breakdown whilst driving, call the toll-free number: 1- 888 - 59ASTON (1-888-592-7866). It is available 24 hours a day.
Page 310 Aston Martin Assistance...
Page 311 ............... 2.12 Automatic Climate Control ............6.4 Motion Sensor ............... 2.12 Manual Climate Control ............6.5 Tow Away Protection ............2.12 Climate Controls ................6.2 Aston Martin Facilities ..............A.2 Infotainment ................6.4 Audio Switches ..................6.2 Specification ................8.2 Cruise Control ................5.8 Automatic Transmission Fault Conditions ..............
Page 312 Fluid Capacities Lamps ................11.13 ..................11.41 Fluid Specifications Lighting ..............11.12 ..................4.17 Fluids and Capacities Exterior ..............11.9 ................... 4.17 Fuel Interior ....................11.53 ..................4.19 Fuses Locking and Opening ..................11.30 Outside ..................2.6 Garage Door Opener ..............2.13 Operation Maintenance ................2.16 Programming Vehicle Lifting ................2.14 ................
Page 313 Traffic Servicing ..................9.6 ..................A.8 Navigation Menu Servicing Precautions ............... 9.13 ..............11.3 Settings System ..................10.3 Occupant Restraint System ............3.10 Time ..................10.2 Vehicle ..................10.2 Airbags ..................3.15 Specifications Seat Belts ................3.11 4.0L V8 Engine ..............11.46 Owner Maintenance Checks ...........
Page 314 Unlocking and Opening .............2.5 Inside ..................2.6 Outside ..................2.5 Tailgate ..................2.8 Vehicle Identification ..............E.4 Vehicle Key ...................2.2 Vehicle Provenance ..............A.3 Vehicle Recovery ..............11.50 Voice Control ................4.16 Washers and Wipers ...............11.13 Wiper Controls ................4.17 Alphabetical Index...

This manual is also suitable for:

Vantage 2021

Aston Martin VANTAGE Manual

Quick Start

Vehicle Security

Before Driving

Controls

Driving

Climate Control

Media Systems

Satellite Navigation

Maintenance and Technical Data

Service

Aston Martin Warranty

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aston Martin VANTAGE

Summary of Contents for Aston Martin VANTAGE

This manual is also suitable for:

Table of Contents
