Please read instructions before operation the blasting system.
Failure to follow these instructions could result in operator injury and damaged to the sand blasting
cabinet.
The sand blast cabinet will produce a powerful flow of abrasive particles.
To avoid personal injury and property damage study this manual thoroughly before assembling,
operating or servicing this sand blast cabinet. This sand blast cabinet is designed for cleaning,
polishing and finishing with dry abrasive ONLY, such as glass bead or plastic granule abrasives.
The finishes can vary from course to fine according to the sizing of the glass bead on delicate parts.
Start out with minimal air pressure to avoid unnecessary excessive abrasion.
Do Notice this sand blasting system is equipped with a 3-prong grounded plug for protection against
shock. When connecting your unit obey all applicable electrical and safety codes. The blasting system
should be only plugged into an adequately grounded 3-prong receptacle. Abrasive media is very
slippery and should be cleaned up immediately to avoid possible operator injury.
