二、Installation
Notice:
⚫ Make sure to read the instructions to understand product information and
safety precautions before installation;
⚫ The installer must use insulated tools and wear safety equipment during
the installation procedure；
⚫ Construct sun and rain shelters to avoid GroBoost directly exposed to
sunlight and rain.
◆ Installation Process
⚫ Fix the wall-mounted bracket hanging on the wall with screws, drill holes in
the wall after positioning the four screw holes, put the plastic expansion
