in Figure 5.1, the pairing light ④of the host flashes quickly, they are
pairing;
⚫ STEP3
The GroBoost LED3 light does not flash, the host (ShineLanBox) pairing
light ④ is off, the device light ③ flashes, and the pairing is successful;
Note:
The flash number of times of the ShineLanBox device light③ means the
number of devices connected to ShineLanBox.
四、Device parameters
The equipment specifications are shown in Table 4-1
category Item
Dimension (W/H/D)
Weigh
User manual
Power Supply
Working current
Power consumption
Maximum load power
General
Operating Temperature
Figure 3-6
Parameter
288mm *227mm *101mm
3.5kg
Chinese and English
230Vac/3*230Vac 50Hz
25MA
5W
3.6kW/10.8kW (Single channel
adjustable)
-25℃ ～ +60℃
21
