Page 2
-Triggers from Part 13 to 16 has been added to the modulation sources, instead of MIDI CC 58 to 61. Page 7 Bug fixes: -When syncing LD3/Tiny LD to a MIDI sequencer, and recording the MIDI notes, the sequence would, in most cases, be time shifted one step ahead. This has now been corrected.
Page 3
New Percussion Oscillators 2 new percussion oscillator types have been added to the oscillator section: Cym2: Cymbal2. By combining FM and ring modulation, this can make cymbal sounds that are a bit more aggressive than cymbal 1. Clap: A handclap oscillator. A noise source is shaped by a “clap envelope”. The speed and the amount of the clap envelope can be adjusted, together with the noise PW.
Page 4
The Parameters Only the new parameters are explained here. For a complete description of all parameters, please see the User Manual. Cym2: SelFM: Value -256 to +255. Sets self FM amount of the first square wave oscillator (A modulator) Dtun: Value 0 to 511. Detunes the square waves away from each other. PW: Value 0 to 511.
Page 5
Clap: Tune: Value -64 to +63. When the Clap oscillator is selected, the Tune parameter sets the speed of the clap envelope. NzPw: Value -256 to +255. Sets the intensity of the Clap noise. Dtun: Value 0 to 511. Detunes the noise sound. PW: Value 0 to 511.
Page 6
Edit Knob MIDI CC’s Output On the MOR>COM2 page, it is now possible to turn off the Edit Knobs transmitting MIDI CC’s to MIDI Out. The new parameter is named KnobCC. The default position is “On”.
Page 7
Part 13 to 16 will now output a modulation trigger every time, that they are triggered, which can modulate all parts. This has mainly been made, to make it possible to send 4 different triggers to the LD3 CV outputs, when SpazeBoard2 are installed. On Tiny LD these triggers can only be used for modulation.
Page 8
Written by Flemming Christensen ”Gotharman” 2020 www.gotharman.dk...
