On the bench

Secure the unit to the surface using the dyno bolt connection

Turn the unit ON

•
If wire-break triggering has been selected, then the unit will not arm itself
until the wire-break cable is connected in a shorted condition. It will flash
rapidly RED until a shorted cable is connected
•
Walk away
•
Unit will set itself after 2 minutes
•
An alternate Blue
•
A Blue only flash will indicate it is waiting for a wire-break trigger.

After the shot

•
The unit will reset itself after recording the data. If the trigger was a wire-break then the unit
resets to Threshold triggering.
•
If at any period a Bluetooth connection is made the unit will connect to the application.
•
The data just recorded can be downloaded if required.
•
The unit can have its operating parameters changed at any point using the Bluetooth
connection

Switch off the unit

Press on/off button until it is illuminated with a solid
and RED flash will indicate it is waiting for a level trigger.
