PLM 10000Q
PLM 10000Q Powered Loudspeaker Management system
The PLM 10000Q seamlessly integrates networked digital signal
distribution, drive processing, power amplification, and load verifi-
cation plus performance monitoring in a single hardware unit and
unified software controller. This new approach, designated Powered
Lab.gruppen Technology
•
2700 W per channel @ 2.7 ohms**
2350 W per channel @ 4 ohms**
•
•
2U chassis weighing only 13 kg (29 lbs)
•
Class TD
output stage
®
Regulated Switch Mode Power Supply (R.SMPS
•
•
Copper-finned Intercooler
devices
Full suite of protection and fault monitoring features
•
•
Comprehensive loudspeaker preset database
•
LoadLibrary
load "fingerprint" (identity and characteristics) data
™
Comprehensive LoadSmart
•
continuous loudspeaker performance monitoring
•
Dante
low-latency digital network included as standard
™
Dolby Lake Processor Technology
•
Raised Cosine Equalization
•
Linear phase and classical crossovers
LimiterMax
– peak and RMS limiters
•
™
•
Iso-Float
ground isolation
™
•
Super Module capability
)
™
with transverse-mounted output
®
load verification and SpeakerSafe
™
PLM
Series: Powered Loudspeaker Management
™
Loudspeaker Management (PLM), is a joint development of Dolby
Lake
and Lab.gruppen. As a cohesive system, the PLM 10000Q
®
affords significant advantages when compared to conventional
approaches utilizing separate components.
Fully compatible with Dolby Lake Processor, Lake Contour
•
and Lake Mesa Quad EQ
•
Primary and secondary network connections (for daisy chaining or
system redundancy)
•
Digitally controlled "amplifier gain" adjustable in 0.1 dB steps from
22 to 44 dB
Digital output attenuation in 0.25 dB steps from -inf to 0 dB
•
•
Binding post or Neutrik
output connectors
Digitally implemented, zero-overshoot Inter-Sample Voltage Peak
•
Limiting (ISVPL
) adjustable in 0.1 V steps from 18 to 150 V
™
•
Power Average Limiter (PAL)
™
High-brightness front-panel LCD display
•
•
Moisture resistant silicone touchpad for front-panel display mode
selection and menu navigation
** More power available when driven asymmetrically.
•
Parallel operation of the SmaartLive
analysis system
Analog and AES digital inputs with loop-thru outputs
•
•
Auto-selct input router for all inputs with user definable priorities
Technical Data
and Mesa Parametic EQ
™
™
Speakon
(1 x NLT8, 2 x NLT4) power
®
®
frequency measurement and
™
™
®
,
™
devices
