- Page 1 Network Configuration Guide ™ Powered Loudspeaker Management Rev. 1.0.5 Item no. NCG-PLM Series systems ™...
-
Page 2: Table Of Contents
1 CONTENTs 1 CONTENTS ...2 2 INTRODUCTION ...3 Overview ...3 2.2 Ethernet Fundamentals...3 2.2 PC Configuration ...3 3 PLM SERIES aND DaNTE ™ Networking Overview ...5 3.2 Dante Audio Network ...5 3.3 Rear Panel Connections...5 4 aVOIDINg SINgLE POINT OF FaILURE (SPF) ISSUES ...6 SPF Overview ...6 4.2 Automatic Priority Input Switching ...6 4.2.1 Signal type redundancy ...7... -
Page 3: Introduction 2
2.1 Overview Thank you for choosing the Lab.gruppen PLM Series of Powered Loudspeaker Management systems for your sound reinforcement needs. We are confident that you will be pleased with the performance, unique features, configuration flexibility, reliability, and long- term durability offered by PLM Series products. This document covers only information related to network configuration. - Page 4 2 INTRODUCTION From the Start menu, open the Control Panel. Under Network and Internet, choose View Network Status and Tasks. Underneath Network, to the right of Connection / Local Area Connection, choose View Status. In the dialog box, click on Properties, and click Continue in the warning dialog.
-
Page 5: Plm Series And Dante Networking Features 3
(straight) or crossover Ethernet cable to be used. cabling is strongly recommended due to its increased bandwidth capacity. CH 2 Ser. N:o SPEAKER OUTPUTS INPUT LINK CH 3 CH 4 ANALOG WITH CLASS 2 WIRING Figure 3.3: Dual Ethernet ports are located on the PLM rear... -
Page 6: Avoiding Single Point Of Failure (Spf) Issues
4 avOIDINg SINgLe POINT OF FaILURe (SPF) ISSUeS 4.1 SPF Overview Critical network configurations (such as those trans- porting audio signals) should avoid “Single Point of Failure” (SPF) scenarios to the greatest extent possible. SPF failures can occur when a network has been designed in such a way that failure of a single part of the network can cause the entire network to fail or cease operation. -
Page 7: Signal Type Redundancy
4.1.1 Signal type redundancy Use of this topology allows a PLM to receive audio and control signals from a source device using differ- ent output types, i.e. a device which can output both analog and AES signals simultaneously. These signals are then designated as priorities in the auto input section. -
Page 8: Network Connections And Topologies
5 NeTwORk CONNeCTIONS aND TOPOLOgIeS 5.1 PLM Series Network Cabling The common cable categories used for high band- width network connectivity are Cat-5e and Cat-6; these are preferred choices for PLM Series network use. However, Cat-5 may be used in limited applica- tions, as explained below. -
Page 9: Star Or Hub-And-Spoke Networks
5.2.2 Star or Hub-and-Spoke networks An alternative approach is to implement a network with Star topology, also referred to as ‘hub-and- spoke’ or ‘radial’ topology, using a number of Ethernet switches. (See figure 5.2.2.) In such a network, a group of PLMs (typically those inside the same rack) are connected directly to a switch also housed in the rack. -
Page 10: Other Combination Networks
5 NeTwORk CONNeCTIONS aND TOPOLOgIeS Rack 1000 1000 1000 1000 Rack 1000 5.2.5 Dual daisy-chained switches This is a hybrid that combines the ease of wiring of the daisy chain topology with the 100% avoid- ance of SPF issues in the dual redundant star/spoke configuration (figure 5.2.5). -
Page 11: Plm / Dante Network Size Limitations
1000 Stage Right Rack 1000 1000 distances. The recommended LinkSys switch can be upgraded with SFP modules to support fiber connec- tions (See section 7, References and Definitions, for more information on SFP.) System type Source Backbone Sink Latency setting 1 0.8 ms Latency setting 1 1.3 ms... -
Page 12: Wireless Network Topologies
5 NeTwORk CONNeCTIONS aND TOPOLOgIeS devices (or sinks) for a given latency setting. Table 5.4 shows the limits for a Dante system with PLM Series devices as the sinks. The recommended system is shown in grey in Table 5.4. It has a DLP or PLM as the source (100 Mbps) and PLM Series devices as sinks. -
Page 13: Network Hardware Recommendations 6
Code Point (DSCP) protocol, and it must implement strict priority control over at least the top two priority levels. (3Com is an example of a provider that typi- cally prioritizes only the top level.) See References and Definitions in section 7 for more on DSCP. -
Page 14: Recommended Network Cabling: Belden 1305A
• Accepts standards-based PoE (IEEE 802.3af) or external DC power • Manufacturer website: www.linksys.com or www.3com.com 6.1.3 Recommended network cabling: Belden 1305a Although Belden 1305A is a stranded-type cable providing high resilience against failure from repetitive bending or stressing, it ex- hibits a loss of 26.4 dB instead of the 24... -
Page 15: References And Definitions 7
The following definitions will help the user better understand some specific terms used in this guide, and in other PLM Series technical documentation. Lab.gruppen has made every effort to make sure that the information here is correct and accurate. Term Description auto-sensing The Ethernet ports on the PLM automatically determine the base speed of the network connection (10Base-T or 100Base-T) and configure... -
Page 16: Additional Information
8 ADDITIONAl INFORmATION Contact: Lab.gruppen AB Faktorvägen 1 SE-434 37 Kungsbacka SWEDEN Phone: +46 300 56 28 00 Fax: +46 300 56 28 99 plmsupport@labgruppen.com info@labgruppen.com www.labgruppen.com Intercooler and Class TD are national and/or international registered trademarks of Lab.gruppen AB. PLM, Powered Loudspeaker Management, R.SMPS, LoadLibrary, LoadSmart, SpeakerSafe and ISVPL are trademarks of Lab.gruppen AB. - Page 17 L a b . g r u p p e n a b • S w e d e n i n t e r n a t i o n a L c o n t a c t • i n f o @ L a b g r u p p e n . c o m u S c o n t a c t •...
