Lab.gruppen iP Series IP 1350 Specifications page 2

SPECIFICATIONS iP 1350
MAX OUTPUT POWER 1)
8 per channel
4 per channel
2 per channel
8 bridged
4 bridged
Max output voltage
8 ohms load
Peak voltage, no load
Distortion etc.
THD 20Hz-20kHz
and 1W to full power
THD @ 1kHZ and –1dB
under clip
DIM 30 at –3dB under clip
Hum and Noise
Channel separation @10kHz
Output impedance
Slew Rate
Inputs
Gain, selectable [dB]
Impedance
Common mode rejection
Front Panel
Gain controls
Protect indicator
Clip Indicator
Signal present indicator
On Indicator
Rear Panel
Input connectors
Input /Link connector
Output connectors
Switches
Clip limiter A and B
Link-switch
Power
Operation voltage
Minimum start voltage
Full output power at 4ohms
Peak inrush current (Soft start limited) 20 A
Current Draw @ 4ohms&230V
Quiescent power (no load)
1/8 of full power (-9dB)
1/3 of full power (-5dB)
At full power (0 dB) @1 kHz 1% THD
Net Dimensions mm (inch)
Shipping Dimensions mm (inch)
Net Weight
Shipping Weight
Approvals
1) Specifications measured with 230 VAC
2) Component tolerance dependent
3) Continuous power, one channel driven or peak power both channels driven
(Thermal protection may occur at high continuous power)
LAB. GRUPPEN reserve the right to alter functions or specifications without prior notice.
Lab.gruppen AB, Gullregnsvägen 16, S-434 44 Kungsbacka, Sweden.
Tel. +46 300 168 23. Fax +46 300 142 46. e-mail: info@labgruppen.se www.labgruppen.se
EIA at 1 kHz and 1% THD
300 W
500 W
2)
700 W
1000 W
2)
1400 W
49 Vrms
77 V
0,03 %
0,005 %
0,005 %
<-110 dB
70 dB
30 m
45 V/ s
20, 23, 26, 29,
32, 35, 38, 41
20 kohm
50 dB
(2) channel A, B
(2) yellow LEDs
(2) red LEDs
(2) green LEDs
(2) green LEDs
(2) Neutrik Combo XLR type, 3 pin & 1/4" jack
(2) 3-pin Phoenix terminal block
(2) Neutrik 4-pole Speakon connectors
On-Off (switchable)
Ch.A-B
230 V version
130 V-265 V AC
190 V
230 V AC
0.6 Arms
3.5 Arms
5.5 Arms
9.5 Arms
483 (19") W x 88 (3,5") H x 325 (12.8") D
560 (22") W x 180 (7.1") H x 500 (19.7") D
15 kg (33 lbs)
16.6 kg (36.5 lbs)
CE
Emission EN 55 103-1, E3
Immunity EN 55 103-2, E3, with S/N below 1% at normal operation level
Safety EN 60 065, class I
THX iP1350T
4) Normal operation level 1/8 of full power or –9dB below clip level.
FTC 20-20kHz @0.1%THD
280 W
460 W
2)
660 W
920 W
2)
1320 W
31 positions detent
80 C at heatsink or >12kHz at full power or shorted output
Fast peak – slow release
-40 dB below full output
DC rail voltage for channel A and B
115 V version
65 V – 135 V AC
95 V AC
115 V AC
10 A
1.2 Arms
7 Arms
11 Arms
19 Arms
4)
2002-03 V1
