Digital Watchdog MEGApix IVA DWC-MB84Wi4T User Manual page 16

Setup - Video and Audio Setup
Video Configuration
1
2
3
4
5
Live Video Channel Setup - The video can be configured to various settings with a combination of codec and
1
resolution. The camera performance should be considered when setting multiple channels, as the performance
of the camera will be affected.
H.265 (HEVC) codec with a higher bitrate may cause unstable live streaming or reload the webpage.
Codec - Choose the video codec. Depending on the selected codec, the subcategories may be changed
2
accordingly.
Description - Input the additional description of the selected channel. Max. 30 alphanumeric characters may
3
be used, including spaces.
Resolution - Select video resolution.
4
Available Frame Rate may differ even if the same codecs are in use.
<Resolution of Video Format>
2560x1440
QFHD
(4M)
3840x2160 2560x1440 1920x1080 1280x720
Frame Rate - Select the maximum Frame Rate.
5
Available Frame Rate can be different although the same codecs were set up.
1080p/i 720p/i SVGA
800x600
768x432
4CIF
(0.3M)
704x576
768x432
704x480
15
640x360
VGA
(0.2M)
352x288
640x480 640x360
352x240
CIF
