Model # GCS09020D
USE AND CARE GUIDE
EGG SWING WITH BASKET WEAVE
Questions, problems, missing parts? Before returning to the store
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this swing. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY GCS09020D
Summary of Contents for HAMPTON BAY GCS09020D
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this swing. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Hardware Included ..............Product Caution ..............2 Package Contents ..............Safety Warnings ..............2 Assembly ................ 5 Warranty ................ 2 Care and Cleaning ............ -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity... -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Base Lower hanging pole Upper hanging pole Basket Cushion... -
Page 5: Assembly
Assembly ATTACHING THE CONNECTOR RING TO THE BASKET Open the connector ring (DD) in the counterclockwise direction. Hang the basket (D) to the connector ring (DD) and close the connector ring (DD) in the clockwise direction. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance... - Page 6 Assembly (continued) ATTACHING THE LOWER HANGING POLE TO THE BASE Insert the lower hanging pole (B) through the safety strap on the basket (D) and attach to the base (A). Tighten the lower hanging pole (B) with the base using one M8x60 bolt, washer, nut (BB). Connect the decorative ring (CC) to the lower hanging pole (B).
- Page 7 Assembly (continued) ATTACHING THE UPPER HANGING POLE TO THE LOWER HANGING POLE Attach the upper hanging pole (C) to the lower hanging pole (B) using M8x55 bolts, washers, nuts (AA). Tighten all bolts by using the hex wrench (EE) and the wrench (FF). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON...
- Page 8 Assembly (continued) ATTACHING THE BASKET TO THE UPPER HANGING POLE. Open the connector ring (DD) in the clockwise direction. Hang the basket (D) to the upper hanging pole (C) by hooking the connector ring (DD) to the upper hanging pole (C). Close the connector ring (DD) in the counterclockwise direction.
-
Page 9: Care And Cleaning
Assembly (continued) PUT THE CUSHION ON THE EGG SWING. Put the cushion (E) on the egg swing (D). Care and Cleaning For best results, clean the swing with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. - Page 10 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
