- Page 1 Owner’s Manual LED LCD MONITOR (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 49WQ95C 49WQ95X 49BQ95C www.lg.com Copyright © 2022 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
TabLE of CoNTENTS LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. LICENSE ............2 The terms HDMI and HDMI High-Definition Multimedia Interface, OPEN SOURCE SOFTWARE NOTICE and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. -
Page 3: Open Source Software Notice
• Illustrations in this document represent typical procedures, so they may look different from the actual LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing product. such distribution (such as the cost of media, shipping, and handling) upon email request to •... - Page 4 • The power cord provided may differ depending upon the region. Supported Drivers and Software You can download and install the latest version from the LGE website (www.lg.com). NoTE • Drivers and Software: Monitor Driver / onScreen Control / Dual Controller •...
- Page 5 Moving and Lifting the Monitor CaUTIoN • Avoid touching the monitor screen as much as possible. When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or - This may result in damage to the screen or some of the pixels used to create images. damaged and to ensure safe transportation, regardless of its shape or size.
- Page 6 Installing on a Table adjusting the Stand Height 1 Place the monitor mounted on the stand base in an upright position. • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm (3.9 inches) away from the wall to ensure sufficient ventilation.
- Page 7 adjusting the angle Using the Kensington Lock 1 Place the monitor mounted on the stand base in an upright position. The connector for the Kensington security system is located at the back of the monitor. 2 Adjust the angle of the screen. For more information on installation and usage, refer to the Kensington lock owner’...
- Page 8 Be careful not to apply too much force while mounting the wall mount plate as it may cause damage to the • A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not screen.
- Page 9 • Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. • To prevent injury, this apparatus must be securely attached to the wall in accordance with the installation instructions.
-
Page 10: Using The Monitor
CaUTIoN HDMI Connection • If you use generic cables not certified by LG, the screen may not display or there may be image noises. Transmits digital video and audio signals from your PC to the monitor. • Do not press the screen for a prolonged time. This may cause image distortion. - Page 11 Connecting aV Devices DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. HDMI Connection NoTE HDMI transmits digital video and audio signals from your AV device to the monitor. • There may be no video or audio output depending on the DP (DisplayPort) version of the PC. •...
- Page 12 Connecting Peripherals CaUTIoN Cautions When Using a USB Device USb Device connection • A USB device with an automatic recognition program installed, or that uses its own driver, may not be recognized. The USB port on the product functions as a USB hub. •...
- Page 13 Headphones Connection Connect peripherals to the monitor via the headphones port. NoTE • Peripheral devices are sold separately. • Depending on the audio settings of the PC and external device, headphones and speaker functions may be limited. • If you use angled earphones, it may cause a problem with connecting another external device to the monitor. Therefore, it is recommended to use straight earphones.
-
Page 14: User Settings
USER SETTINGS NoTE • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. • When [Beep Guide] is activated, pressing the joystick button will take you to [Settings] right away. activating the Main Menu 1 Press the joystick button located at the back of the monitor. - Page 15 Main Menu features Main Menu Description A: [Power Off] Turns off the monitor. B: [Input] Sets input mode. C: [Settings] Configures the screen settings. D: [Picture Mode] Sets the picture mode. E: [Exit] Exits the main menu. Menu Settings 1 To view the OSD menu, press the joystick button at the back of the monitor and then enter the [Settings]. 2 Move the joystick up/down and left/right to set the options.
- Page 16 [Quick Settings] [PbP / PIP] • [Input List]: Displays the screens of main input and sub input [Settings] [Quick Settings] • [Brightness]: Adjusts the brightness of the screen. Sub Screen PBP / PIP Connection • [Auto Brightness]: Optimizes the brightness automatically for surrounding illuminance. HDMI 1 HDMI 2 USB-C...
- Page 17 [Picture] [Picture Mode] on HDR signal • [Custom]: Allows the user to adjust each element. [Settings] [Picture] [Picture Mode] • [Vivid]: Optimized the screen for HDR vivid colors. NoTE • [Cinema]: Optimized the screen for HDR video. - The [Picture Mode] that can be set depends on the Input signal. •...
- Page 18 [Settings] [Picture] [Picture adjust] [Settings] [Picture] [Game adjust] • [Brightness]: Adjusts the brightness of the screen. • [Response Time]: Sets a response time for displayed pictures based on the movement of the picture on the screen. For a normal environment, it is recommended that you use [Fast]. When there is a lot of motion, it is •...
- Page 19 [Settings] [Picture] [Color adjust] [Settings] [Picture] [Picture Reset] • [Gamma]: • [Do you want to reset your picture settings?]: - [Mode 1], [Mode 2], [Mode 3]: The higher the gamma value, the darker the image becomes. Likewise, the - [Yes]: Returns to the default settings. lower the gamma value, the lighter the image becomes.
- Page 20 • [Input Compatibility Version]: Set Input Compatibility Version to the same version as the connected external device. - In case of DisplayPort and USB-C set to 1.4 or over to use the HDR function. - In case of HDMI input, set to 2.1[AV] or over to use the HDR function. •...
-
Page 21: Troubleshooting
TRoUbLESHooTING Nothing is displayed on the screen. • Is the monitor's power cord plugged in? - Check if the power cord is correctly plugged into the power outlet. • Is the [No Signal] message being displayed? - This is displayed when the signal cable between the PC and the monitor is missing or disconnected. Check the cable and reconnect it. •... - Page 22 • Have you installed the display driver? - Be sure to install the display driver from our web site: http://www.lg.com. - Make sure to check if the graphics card supports Plug and Play function. No sound from the headphone port.
-
Page 23: Product Specification
PRoDUCT SPECIfICaTIoN Power Sources: • Power Rating: AC 100 - 240 V, 50/60 Hz, 2.5 A • Power Consumption: Specifications are subject to change without notice. - Operating Mode: 103 W (Typical)* The symbol means alternating current, and the symbol means direct current. - Sleep Mode: ≤... - Page 24 factory Support Mode (Preset Mode, PC) DisplayPort / USb-C Resolution Horizontal frequency (kHz) Vertical frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1280 x 1024 79.976 75.025 1920 x 1080 66.587 59.934 5120 x 1440...
- Page 25 HDMI Resolution Horizontal frequency (kHz) Vertical frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1280 x 720 91.49 119.91 1280 x 1024 79.976 75.025 1920 x 1080 66.587 59.934 5120 x 1440 222.16 143.98...
- Page 26 Remarks PBP(16:9) PBP(16:9) SINGLE PBP(21:9) PBP(11:9) PBP(11:9) PBP(21:9) HDMI Timing (Video) Preset Mode Horizontal frequency (kHz) Vertical frequency (Hz) 480p 31.5 720p 1080p 67.5 2160p...
- Page 27 beep Guide Menu Location Menu Location Menu Location Quick Settings Quick Settings - USB Selection - HDMI1 1 7 1 Input (PBP/PIP Off) - Aspect Ratio - Cinema 1 2 2 4 Quick Settings - Brightness Quick Settings - USB Selection - HDMI1 - USB-B 1 7 1 1 Input (PBP/PIP Off) - Aspect Ratio - Cinema 2 2 2 5...
- Page 28 Menu Location Menu Location Menu Location Input (PBP/PIP On) - Input List - Main Input List 2 1 1 Input (PBP/PIP On) - Aspect Ratio - Sub Aspect Picture - Picture Mode - Reader 3 1 4 2 2 2 2 Ratio - Original Input (PBP/PIP On) - Input List - Main Input List Picture - Picture Mode - Cinema...
- Page 29 Menu Location Menu Location Menu Location Picture - Picture Adjust - Black Level - Low 3 2 6 2 Picture - Game Adjust - Crosshair - Red Dot 3 3 4 3 Picture - Color Adjust - Six Color - Red Hue 3 4 6 1 1 Slider Picture - Picture Adjust - Local Dimming 3 2 7...
- Page 30 Menu Location Menu Location Menu Location Picture - Color Adjust - Six Color - Yellow Saturation 3 4 6 12 General - USB Selection General - Input Compatibility Version 3 4 6 12 1 General - USB Selection - HDMI1 4 2 1 General - Input Compatibility Version - 1.4(DSC) / Picture - Color Adjust - Six Color - Yellow Saturation...
- Page 31 Supplier's Declaration of Conformity Trade Name Responsible Party LG Electronics USA, Inc. (for 49BQ95C) Address 111 Sylvan Avenue, North Building, Englewood Cliffs, NJ 07632 E-mail lg.environmental@lge.com ® This Product qualifies for ENERGY STAR The model and serial number of the product are located on the back and on one side of the product.
