LG 49WL900G Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Owner's Manual
LED LCD MONITOR
(LED Monitor*)
* LG LED Monitor applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and retain it for future reference.
49WL900G
49WL900G-BE
49WL900G-BY
Copyright © 2019 LG Electronics Inc. All Rights Reserved.
www.lg.com

Advertisement

loading

Related Manuals for LG 49WL900G

Summary of Contents for LG 49WL900G

  • Page 1 Owner’s Manual LED LCD MONITOR (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 49WL900G 49WL900G-BE 49WL900G-BY www.lg.com Copyright © 2019 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. LICENSE ............2 The terms HDMI and HDMI High-Definition Multimedia Interface, OPEN SOURCE SOFTWARE NOTICE and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

  • Page 3: Open Source Software Notice

    The power cord provided may differ depending upon the region. for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing Supported Drivers and Software such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.
  • Page 4 Product and Button Description Moving and Lifting the Monitor When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or damaged and to ensure safe transportation, regardless of its shape or size. • Place the monitor in the original box or packing material before attempting to move it. •...
  • Page 5 Be careful not to apply too much force while mounting the wall mount plate as it may cause damage to the • A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not screen.
  • Page 6 • Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. • To prevent injury, this apparatus must be securely attached to the wall in accordance with the installation instructions.

  • Page 7: Using The Monitor

    CAUTION DisplayPort) cable or gender that supports DisplayPort1.4. (sold separately) • If you use generic cables not certified by LG, the screen may not display or there may be image noises. USB-C connection • Do not press the screen for a prolonged time. This may cause image distortion.
  • Page 8 Connecting AV Devices Connecting Peripherals HDMI Connection USB Device connection HDMI transmits digital video and audio signals from your AV device to the monitor. The USB port on the product functions as a USB hub. NOTE NOTE • Using a DVI to HDMI / DP (DisplayPort) to HDMI cable may cause compatibility issues. •...
  • Page 9 Headphones Connection CAUTION Cautions When Using a USB Device Connect peripherals to the monitor via the headphones port. • A USB device with an automatic recognition program installed, or that uses its own driver, may not be NOTE recognized. • Peripheral devices are sold separately.

  • Page 10: User Settings

    USER SETTINGS NOTE • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. Activating the Main Menu 1 Press the joystick button located at the back of the monitor. 2 Move the joystick up/down and left/right to set the options. 3 Press the joystick button once more to exit the main menu.
  • Page 11 Main Menu Features Main Menu Description A: [Power Off] Turns off the monitor. B: [Input] Sets input mode. C: [Settings] Configures the screen settings. D: [Picture Mode] Sets the picture mode. E: [Exit] Exits the main menu. Menu Settings 1 To view the OSD menu, press the joystick button at the back of the monitor and then enter the [Settings]. 2 Move the joystick up/down and left/right to set the options.
  • Page 12 [Quick Settings] [PBP / PIP] • [Input List]: Displays the screens of main input and sub input [Settings] [Quick Settings] • [Brightness]: Adjusts the brightness of the screen. Sub Screen PBP / PIP Connection • [Auto Brightness]: Optimizes the brightness automatically for surrounding illuminance. HDMI 1 HDMI 2 USB-C...
  • Page 13 [Picture] [Settings] [Picture] [Picture Adjust] • [Brightness]: Adjusts the brightness of the screen. [Settings] [Picture] [Picture Mode] • [Auto Brightness]: Optimizes the brightness automatically for surrounding illuminance. NOTE • [Contrast]: Adjusts the contrast of the screen. - The [Picture Mode] that can be set depends on the Input signal. •...
  • Page 14 [Settings] [Picture] [Color Adjust] [Settings] [Picture] [Picture Reset] • [Gamma]: • [Do you want to reset your picture settings?]: - [Mode 1], [Mode 2], [Mode 3]: The higher the gamma value, the darker the image becomes. Likewise, the - [Yes]: Returns to the default settings. lower the gamma value, the lighter the image becomes.
  • Page 15 • [HDMI ULTRA HD Deep Color]: Provides sharper images when connected to a device supporting ULTRA HD [Settings] [General] [Reset to Initial Settings] Deep Color. • [Do you want to reset your settings?] - To use [HDMI ULTRA HD Deep Color], turn this function on. - [Yes]: Returns to the default settings.

  • Page 16: Troubleshooting

    TROUBLESHOOTING Nothing is displayed on the screen. • Is the monitor's power cord plugged in? - Check if the power cord is correctly plugged into the power outlet. - Check the AC power plug by plugging in a different device such as a lamp. •...
  • Page 17 • Have you installed the display driver? - Be sure to install the display driver from our web site: http://www.lg.com. - Make sure to check if the graphics card supports Plug and Play function. No sound from the headphone port.

  • Page 18: Product Specification

    PRODUCT SPECIFICATION Power Sources: • Power Rating: AC 100 - 240 V, 50/60 Hz, 2.5 A • Power Consumption: Specifications are subject to change without notice. - Operating Mode: 80 W (Typical)* - Off Mode: ≤ 0.3 W Color Depth: 8-bit / 10-bit color is supported. Resolution: * The Operating Mode of Power Consumption is measured with LGE test standard.
  • Page 19 Factory Support Mode (Preset Mode, PC) DisplayPort/USB-C Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 1280 x 800 49.702 59.81...
  • Page 20 HDMI Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 1280 x 800 49.702 59.81 1280 x 1024 63.981 60.02 1280 x 1440...
  • Page 21 Remarks SINGLE 2PBP-A 2PBP-A 3PBP 2PBP-A 3PBP 2PBP-B1 2PBP-B2 HDMI Timing (Video) Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) 480P 31.5 720P 1080P 67.5 2160p...
  • Page 22 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. Responsible Party LG Electronics USA, Inc. Address 111 Sylvan Avenue, North Building,...
