Pacific VPC-HD10 Operational Manual

Color hd（720p）board camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PACIFIC CORPORATION
Tokyo H.Q.
          2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN
TEL: +81-3-3760-8881 FAX : +81-3-3760-8882
Color HD（720p）Board Camera
VPC-HD10
Product Specification
& Operational Manual
2010 Pacific Corporation.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VPC-HD10 and is the answer not in the manual?

Questions and answers

Related Manuals for Pacific VPC-HD10

Summary of Contents for Pacific VPC-HD10

  • Page 1 PACIFIC CORPORATION Tokyo H.Q.           2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: +81-3-3760-8881 FAX : +81-3-3760-8882 Color HD（720p）Board Camera VPC-HD10 Product Specification & Operational Manual 2010 Pacific Corporation.

  • Page 2: Table Of Contents

    8.2. PC Operation via RS232C···························································································································· 9 8.3. Switch Operation with OSD Menu··············································································································· 9 Factory Settings (Underlined and Bold letters show the factory settings) ························································ 15 Dimensions ····················································································································································· 16 Cases for Indemnity (Limited Warranty) ········································································································· 17 CMOS Pixel Defect········································································································································· 17 Product Support··············································································································································· 17 ©2010 Pacific Corporation.

  • Page 3: Scope Of Application

              2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: +81-3-3760-8881 FAX : +81-3-3760-8882 Scope of Application This is to describe VPC-HD10, analog color HD (720P) board camera assembly. All specifications contained herein are subject to change without prior notice. Reproduction in whole or in part is prohibited.

  • Page 4: Product Outline

    TEL: +81-3-3760-8881 FAX : +81-3-3760-8882 Product Outline VPC-HD10 is a HD (720P) output, color board camera assembly utilizing 1/3 type CMOS image sensor. With our own image processing technologies, electrical zoom, long time exposure function, OSD functions, and others are incorporated into the camera.

  • Page 5: Specifications

    ATW1 : 2200〜9000K, ATW2 : 3200〜6500K White Balance (18) Preset:3200K, 4800K, 6500K, Manual: 2200〜9000K Adjustment Range Electrical Zoom ×1〜×4 PAN, TILT (19) Responses are adjustable. AUTO IRIS Signals (20) Usable with electrical shutter (with priority to electrical shutter). 2010 Pacific Corporation.

  • Page 6: Camera Input/Output Signals

    Humidity: 20 〜 80%RH with no condensation Storage environment Temperature : -25 〜 +60℃ Humidity: 20 〜 80%RH with no condensation. (30) 5.2. Camera Input/Output Signals Video Signals White clip level: 760mV ±10% SYNC level: 300mV ±10% (3values sync signals) 2010 Pacific Corporation.

  • Page 7: Part Names And Functions

    ④ Dedicated board camera lens Lenses are optional. ⑤ Camera Mounting Holes With bundled attachment screws, mount the camera. ⑥ Extended Connectors (Not implemented. Can be implemented on request.) ⑦ DC  IRIS Connectors (Not implemented. Can be implemented on request.) 2010 Pacific Corporation.

  • Page 8: External Connector Pin Assignment

    DC+12VIN Y/G_OUT VD OUT GREEN HD15PIN HD OUT BLUE IRIS_SIG N.C. N.C. Pr/R_OUT to MONITOR Pb/B_OUT GND(RED) (VGA Terminal) GND(GREEN) GND(BLUE) 51021-1000 N.C. N.C. N.C. N.C. N.C. HSYNC VSYNC N.C. +12V to VIDEO IRIS LENS IRIS OUT 2010 Pacific Corporation.

  • Page 9: Osd Switch Connectors ※Optional Connectors

    Switch connecting terminal (DOWN) SW_BACK BACK ENTER SW_UP SW_ENTER SW_DOWN SHR-10V-S-R DOWN Remote Control Cable Connectors 7.3. Connectors of camera side Connectors of remote control cable side 53398-0271 (molex) 51021-0200 (molex) Signals Remote Control GND REMOTE Remote Control Signals (Input/Output) 2010 Pacific Corporation.

  • Page 10: Camera Operating Instructions

    To select items in the menu. When operating volume type menu, this button makes the value to ＋direction. [DOWN] KEY: To select items in the menu. When operating volume type menu, this button makes the value to −direction. 2010 Pacific Corporation.
  • Page 11 SETTING speed. EXIT SAVE> Save the data set with OSD, and terminate the menu. CANSEL> Restore the data set with OSD, and terminate the menu. DEFAULT> Restore the data to the initial settings, and terminate the menu. 2010 Pacific Corporation.
  • Page 12 Lower speed than LOW SHUTT.LIM. can’t be set. 1/15,1/25, 1/30,1/50, 1/60,1/100, 1/120,1/250,1/ 500,1/1K, 1/2K,1/4K, 1/10K MANUAL SHUTTER Items SELECT Next menu Explanation SHUTTER 8s,4s,2s,1s, Set the shutter speed manually. SPEED 1/2,1/4,1/8, 1/15,1/25, 1/30,1/50, 1/60,1/100, 1/120,1/250,1/ 500,1/1K, 1/2K,1/4K, 1/10K 2010 Pacific Corporation.
  • Page 13 Please refer to the usage method of Auto Iris lens. BLC SETTING Items SELECT Next menu Explanation OFF back light. (Full Photometry) SETTING ON(3×3) ON back light. (Center 3×3) ON(USER) →BLC ON back light. > WINDOW With the next menu, window settings can be done. 2010 Pacific Corporation.
  • Page 14 10 seconds. When PAN, TILT, and EZOOM are changed, it is indicated and disappears automatically after approx. 5 seconds. REMOTE SETTING Items SELECT Next menu Explanation BIT RATE 19200bps Set the speed of serial communication. 9600bps 4800bps 2400bps 2010 Pacific Corporation.
  • Page 15 After adjusting, restore GAIN and SHUTTER settings to be used. When adjusting brightness, please do not use lens-side volume. Adjust the brightness with AE LEVEL after the explained adjustment is completed. If lens-side volume is forced to use to adjust brightness, AGC and AES would not work properly in conjunction with the other. 2010 Pacific Corporation.

  • Page 16: Factory Settings (Underlined And Bold Letters Show The Factory Settings)

    OPTION PICTURE> SHARPNESS STD. GAMMA CHROMA BLEMISH COMP. USER> USER COMP. DISP. START LEVEL MAX. QTY FACT. EZOOM> EZOOM x1.000 TILT DISPLAY> TITLE CHAR> VPC-HD10 MODE REMOTE> BIT RATE 19200bps 9600bps 4800bps 2400bps EXIT SAVE> CANSEL> DEFAULT> 2010 Pacific Corporation.

  • Page 17: Dimensions

    Dimensions                                       ±0.3 ±0.15 (19.2) 2 (mounting surface 2.55 to imaging surface) 4-R1 10.5 4-f 2.2 hole 999-540-00-00 (Unit:mm) 2010 Pacific Corporation.

  • Page 18: Cases For Indemnity (Limited Warranty)

    CMOS pixel defects might be noted with time of usage of the products. The cause of the CMOS pixel defects is the characteristic phenomenon of CMOS itself and Pacific Corporation are exempted from taking any responsibilities for them. Pixel defects (White Spot) compensation we perform is not to guarantee its effects to whole white spot.
