Summary of Contents for Symbol 3366

  • Page 2 Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.
  • Page 3: About This Guide

    Q u i c k R e f e r e n c e Introduction Symbol Technologies’ 3366 Cradle provides communication and charging capabilities for Series 3300 terminals. The 3366 communicates through an RS-232 interface to a computer, printer or modem. About This Guide This guide provides operation and installation information.
  • Page 4: Wall Mounting

    Wall Mounting 1. Hold the cradle against the wall and mark the two screw hole positions (one in the first cradle slot and one in the fourth cra- dle slot). Make sure the wall is flat. 2. Attach the cradle with appropriate fasteners. For example, use anchors for plasterboard (drywall).
  • Page 5 Q u i c k R e f e r e n c e Connecting Cable for Data Communicatons (to a host computer, printer or modem) 1. Plug serial cable (RS-232) into the communication port locat- ed on the left end of cradle below the power connector. 2.
  • Page 6 Inserting Terminal in Cradle Caution: Do not remove the terminal while the cradle's red COMM light is blinking. 1. Seat the terminal into the bottom of the cradle. 2. Press the top of the terminal toward the back of the cradle un- til the terminal is firmly seated.
  • Page 7: Sending Data

    Q u i c k R e f e r e n c e Connecting to Other Cradles Up to 25 cradles can be connected in series using an RS-232 inter- cradle cable (p/n 60427-00-00). Caution: Each cradle must have its own power supply; any other method of power hookup is unsafe.
  • Page 8: Indicator Lights

    Caution: Do not remove the terminal while the cradle's red COMM light is blinking. Recharging the Terminal's Battery Caution: Do not charge if battery temperature is below 0° C (32° F). If below 0° C, wait 2 hours for battery to warm •...
  • Page 9: Troubleshooting

    Q u i c k R e f e r e n c e Troubleshooting Symptom Possible Cause Action Green and red indicators Cradle is not re- Make sure power cable do not momentarily light ceiving power. is securely connected when the cradle is and wall outlet is sup- plugged in.
  • Page 10: Warranty

    It shall not apply to any product (i) which has been repaired or altered unless done or approved by Symbol, (ii) which has not been maintained in accordance with any operating or handling instructions supplied by Symbol, (iii) which has been...
  • Page 11 Customer will pay for the replacement product in case it does not return the replaced product to Symbol within 3 days of receipt of the replacement product. The process for return and customer’s charges will be in accordance with Symbol’s Exchange Policy in effect at the time of the exchange.
  • Page 12: Ergonomic Recommendations

    Ergonomic Recommendations Caution: In order to avoid or minimize the potential risk of ergonomic injury follow the recommendations below. Consult with your local Health & Safety Manager to ensure that you are meeting with your company’s safety programs to prevent employee injury.
  • Page 13: Radio Frequency Interference Requirements - Canada

    Q u i c k R e f e r e n c e Radio Frequency Interference Requirements - Canada This device complies with RSS 210 of Industry & Science Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 14 Telephone Devices (Modems) - United States If this product contains an internal modem it is compliant with Part 68 of the Federal Communications Commission Rules and Regulations and there will be a label on the product showing the FCC ID Number and the REN, Ringer Equivalence Number. The REN is used to determine the quantity of devices which maybe connected to the telephone line.
  • Page 15 Load Numbers of all devices not exceed 100. The Load Number is located on a label on the product. Contact your local Symbol Technologies, Inc., representative for service and support; Symbol Technologies, Inc., Canadian Sales and Service...
  • Page 16 72-40937-01 Revision A — January 2000 Symbol Technologies, Inc. One Symbol Plaza Holtsville, NY 11742-1300...
