- Page 1 TTP 101 Kiosk Printer Evaluation Kit Getting Started Part No.: SWC-870A...
- Page 2 SWECOIN PROMAKON AB disclaims any liability re- sulting from the use of this information and reserves the right to make changes without n otice. First edition, October 1996 Printed in Sweden SWECOIN TTP 101 Kiosk Printer Evaluation Kit – Getting Started 9610...
-
Page 3: Table Of Contents
4.1 Connect printer to control board ..............5 4.2 Connect a paper feed switch (optional) ............5 4.3 Connect power cables................6 4.4 Running the TTP 101 without a metal cover ..........7 4.4.1 Light shielding ................7 4.4.2 ESD precautions ................7 4.5 Install paper roll .................. -
Page 4: Introduction
If a host computer is at hand, all the printer commands described in the TTP 101 Installation Manual can be used to operate the printer. The TTP 101 can also be set in an on-line hex dump mode to log the data transfer between the host and the printer. -
Page 5: Unpacking
UNPACKING The TTP 101 Kiosk Printer Evaluation Kit contains the following items: 83-0101-00 TTP 101 Kiosk Printer (with control board SWC-842 and 50-pole ribbon cable 90-0774-000) 38-9828-052 Power supply unit, 90—260V, 47—63 Hz, 1.25 A 38-8000-02 TTP Editor, one 3.5" diskette... -
Page 6: Product Presentation
PRODUCT PRESENTATION Figure 1. Printer exterior Figure 2. Power supply unit SWECOIN TTP 101 Kiosk Printer Evaluation Kit – Getting Started 9610... -
Page 7: Printer Preparation
PRINTER PREPARATION Connect printer to control board Connect the TTP 101 to the SWC 728-000 control board using the enclosed 50-pole ribbon cable. See Figure 4. Connect a paper feed switch (optional) You may connect a paper-feed switch (not enclosed) to control board connector J6. This switch is required in order to produce test printouts and to log the data transferred between the printer and the host computer. -
Page 8: Connect Power Cables
Connect the power supply unit to a live wall outlet. IMPORTANT! — If you are going to run the printer on-line, connect the TTP 101 power supply unit and the host computer to the same wall outlet or, at least, to the same mains fuse box. -
Page 9: Running The Ttp 101 Without A Metal Cover
Figure 5. Shielding the presenter sensor 4.4.2 ESD precautions Running the TTP 101 without a metal cover exposes the printer to electrostatic discharges from any person that touches the printer. To ensure proper printer operation, connect the printer chassis to protective ground. -
Page 10: Install Paper Roll
This is important since the outer end of the paper is usually fixed to the roll with some type of glue or self-adhesive substance that might otherwise cause paper jam or even printhead damage. Figure 7. Tear off 0.5 m from the new paper roll SWECOIN TTP 101 Kiosk Printer Evaluation Kit – Getting Started 9610... - Page 11 Insert the paper through the opening at the back of the printer and push the paper until it becomes visible in the presenter module. Lower the paper release lever. Figure 9. Insert the new paper 9610 SWECOIN TTP 101 Kiosk Printer Evaluation Kit – Getting Started...
-
Page 12: Test The Printer
NOTE! — If the serial interface is used, the communication parameters in the host computer should be set to: 9600 baud 8 data bits 1 stop bit No parity These parameters are fixed in the printer. SWECOIN TTP 101 Kiosk Printer Evaluation Kit – Getting Started 9610... -
Page 13: Operating The Printer On-Line
NOTE ! — Some of the commands in the TTP Editor are not applicable to the TTP 101. 9610 SWECOIN TTP 101 Kiosk Printer Evaluation Kit – Getting Started... -
Page 14: Fault Finding
FAULT FINDING Refer to the enclosed Operating Instructions. PAPER JAM REMOVAL Refer to the enclosed Operating Instructions. SWECOIN TTP 101 Kiosk Printer Evaluation Kit – Getting Started 9610...
