PROMET EExd Process Moisture Analyzer Sampling Systems
____________________________________________________________
2 Channel Version wiring connections are as follows:
Terminal No.
1
Channel 1 Process Alarm Relay NC
2
Channel 1 Process Alarm Relay COM
3
Channel 1 Process Alarm Relay NO
4
Channel 1 Analyzer Status Alarm Relay NC
5
Channel 1 Analyzer Status Alarm Relay COM
6
Channel 1 Analyzer Status Alarm Relay NO
7
Channel 2 Process Alarm Relay NC
8
Channel 2 Process Alarm Relay COM
9
Channel 2 Process Alarm Relay NO
10
Channel 2 Analyzer Status Alarm Relay NC
11
Channel 2 Analyzer Status Alarm Relay COM
12
Channel 2 Analyzer Status Alarm Relay NO
13
MODBUS digital Comms B
14
MODBUS digital Comms A
15
MODBUS digital Comms Earth
16
Channel 1 Moisture measurement current +mA
17
Channel 1 Moisture measurement current -mA
18
Channel 1 Pressure measurement current +mA
19
Channel 1 Pressure measurement current -mA
20
Channel 2 Moisture measurement current +mA
21
Channel 2 Moisture measurement current -mA
22
Channel 2 Pressure measurement current +mA
23
Channel 2 Pressure measurement current -mA
E
Screen
____________________________________________________________
Installation, Operation & Maintenance Manual and User Guide
Output
www.michell.com
13
