StonePoint LL-100-25D Quick Start Manual

Led low voltage linkable
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

25 ft. 3 Light, Dusk to Dawn Kit
MODEL No: LL-100-25D
1x
12W Plug-in
Dusk to Dawn
Transformer
Operating voltage: 110-240v
40 ft. 4 Light, Dusk to Dawn Kit
MODEL No: K4LVPPP-40
1x
12W Plug-in Dusk to Dawn
Transformer w/ 4 or 8 Hour
Time On Settings
Operating voltage: 110-240v
3x
100 Lumen Plastic
Landscape Lights w/ 3 ft. cords
Operating Voltage: 12-24V
(24V Max.)
2x
Weatherproof
Caps
1x
25 ft. 18/2 SPT-2W
Main Cord
4x
35 Lumen Plastic Pathway
Lights w/ 3 ft. cords
Operating Voltage: 12-24V
(24V Max.)
2x
Weatherproof
Caps
1x
40 ft. 18/2 SPT-2W
Main Cord
LED Low Voltage Linkable
Landscape Light Kits
w/Dusk to Dawn Transformers
30 ft. 3 Light, Dusk to Dawn Kit
MODEL No: K3LVSM-30
1x
24W Plug-in Dusk
To Dawn Transformer
w/ 4 or 8 Hour
Time On Settings
Operating voltage:
110-240v
40 ft. 4 Light, Dusk to Dawn Kit
MODEL No: K4LVPM-40-75
1x
24W Plug-in Dusk To
DawTransformer
w/ 4 or 8 Hour
Time On Settings
Operating voltage:
110-240v
1
3x
200 Lumen Metal
Landscape Lights w/ 3 ft. cords
Operating Voltage: 12-24V
(24V Max.)
2x
Weatherproof
Caps
1x
30 ft. 18/2 SPT-2W
Main Cord
4x
75 Lumen Metal Pathway
Lights w/ 3 ft. cords
Operating Voltage: 12-24V
(24V Max.)
2x
Weatherproof
Caps
1x
40 ft. 18/2 SPT-2W
Main Cord
Revision Date: 10-28-2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LL-100-25D and is the answer not in the manual?

Questions and answers

Related Manuals for StonePoint LL-100-25D

Summary of Contents for StonePoint LL-100-25D

  • Page 1 Landscape Light Kits w/Dusk to Dawn Transformers 25 ft. 3 Light, Dusk to Dawn Kit 30 ft. 3 Light, Dusk to Dawn Kit MODEL No: LL-100-25D MODEL No: K3LVSM-30 100 Lumen Plastic 200 Lumen Metal Landscape Lights w/ 3 ft. cords Landscape Lights w/ 3 ft.

  • Page 2: Safety And Precautions

    PRODUCT TERMS SPOT LIGHT PATHWAY LIGHT DUSK TO DAWN Mounting Tabs TRANSFORMERS Shroud 4-8-D2D Switch Light Head Light Head Plug Dusk-to-Dawn Diffuser Sensor Friction Lock Tube Ground Plug Stake Cord Collar Ring Cord Quick Connector Quick Connector Ground Stake Wood Screw Collar Ring DUSK TO DAWN DUSK TO DAWN...
  • Page 3 SPOT LIGHT ASSEMBLY & OPERATION 1. Remove the thumbscrew from the stake (Fig. 1). Line up the flat side of the ground stake with the friction lock (Fig. 2) against the friction lock on the back of the light head (Fig. 3). Fasten both pieces together with the thumb screw (Fig. 4). Fig.

  • Page 4: Installation

    INSTALLATION 1. The dusk to dawn timer 2. Each connection is made up of a connector (Fig. 3) and a should be plugged into a quick connector (Fig. 4). The quick connectors and GFCI protected outlet after the connectors are only designed to connect one way. installation is complete.
  • Page 5 MODEL No: LL-100-25D 25 ft. 3 Plastic Spot Light Kit with a Dusk to Dawn Transformer 25 FT MATERIAL: Plastic CORD LENGTH: 25 ft. NUMBER OF HEADS: 3 LUMENS PER HEAD: 100 (300 total lumens) WATTS PER HEAD: 1.5 (4.5 total watts) TRANSFORMER: 12 Watts MAX., Dusk to Dawn...

  • Page 6: Cleaning Instructions

    CLEANING INSTRUCTIONS Using a soft cloth, clean the fixture using a mild, non-abrasive glass cleaner. DO NOT use solvents. DO NOT use cleaners containing abrasive agents. NEVER spray liquid cleaner directly onto the light or LED. TROUBLESHOOTING GUIDE Problem Probable Cause Solution Light comes on during the 1.
