VIEW INPUT

1502C MTDR User Manual
This push button allows you to view what is coming in the CABLE connector, or
to eliminate it from the display.
1. Set the 1502C front-panel controls to:
CABLE
NOISE FILTER
VERT SCALE
DIST/DIV
2. Press VIEW INPUT. The indicator block on the LCD should read OFF and
the waveform should disappear from the display.
ac
O
F
F
O
F
F
O
F
F
O
F
F
Figure 2–22: Display with VIEW INPUT Turned Off
3. Press VIEW INPUT again. The indicator block will reappear and the
waveform should be displayed again.
ac
O
N
O
F
F
O
F
F
O
F
F
Figure 2–23: Display with VIEW INPUT Turned On
Attach 3-ft cable
1 avg
500 mr
1 ft/div (0.25 m)
0.000 ft
0.000 ft
Operator Tutorial
2–17
