LG PZCWRC2 Installation Manual

INSTALLATION MANUAL

AIR

CONDITIONER

Please read this installation manual completely before installing the product.

Installation work must be performed in accordance with the national wiring

standards by authorized personnel only.

Please retain this installation manual for future reference after reading it

thoroughly.

Cable Assembly For 2-REMO

PZCWRC2

3828A20494Y

Rev.01_102518

www.lg.com

Table of Contents

Need help?

Do you have a question about the PZCWRC2 and is the answer not in the manual?

Page 1 Installation work must be performed in accordance with the national wiring standards by authorized personnel only. Please retain this installation manual for future reference after reading it thoroughly. Cable Assembly For 2-REMO PZCWRC2 www.lg.com 3828A20494Y Copyright © 2012 - 2018 LG Electronics Inc. All Rights Reserved. Rev.01_102518...
Page 2 TABLE OF CONTENTS 3 PART DESCRIPTION 4 INSTALLATION GUIDE Wiring diagram to use 2-REMO Function 2 Cable Assembly...
Page 3 Part Description Part Description This Accessory is used for 2-REMO function Cable assembly for 2-REMO: 1 EA Other Parts Owner's/Installstion Manual (1 EA) Installation Box (1 EA) Installation Manual 3...
Page 4 Installation Guide Installation Guide Wiring diagram to use 2-REMO Function Wired controller Wired controller MASTER SLAVE 1. When installing 2 wired remote controllers to one or more air conditioners, please connect as above picture. [Note] 1) Some Wired Remote Controller can not use '2-REMO' function. It depends on the Controller's type.
Page 5 Installation Guide Cable Assembly for 2-REMO Check whether the connector Indoor is connected correcly. Indoor terminal block RED(12V) YL(SIGNAL) BK(GND) Extension Cable Check whether the connector is connected correcly. Wired controller Wired controller Installation Manual 5...
Page 6 6 Cable Assembly...
Page 7 Installation Manual 7...
