Explorer/Patroller PLUS Power Kit USER GUIDES
Place the stabilizer wing
under the plus power kit
This compartment is also
for PowerFlight battery
This compartment is for front wing
Install the two wheels
Make sure the rubber cover
contacts with the board
Fasten the board onto the box.
11
All rights reserved by Waydoo
Simply pull the handle, and you can carry the
whole Waydoo product.
How to use
Select a suitable riding location. It is necessary to
select a location with sufficient water depth,
not less than 1.2 meters (4 feet) that is free of
obstacles on or below the surface. Choose a
location away from swimmers and other water
users. Ensure local laws allow the motorized craft
to be used in the area. wearing a life jacket and
helmet is recommended while operating this
product. When you are about to lose balance, try
to fall on the same side of the board that tends to
flip to, to avoid being hit by the board.
Riding the Efoil
Please follow the below steps:
1. Getting familiar with the board. It is
recommended that users climb up the board
from the backside. Be careful not to kick the
wings, propeller or the mast.
(Recommendation: Have a person designat-
ed as a "spotter" when using this product
to keep an eye on the rider.)
2. Long press "-" to unlock the Controller plus.
3. On-board practice: Set the suitable gear.
It is recommended that beginners familiar-
ize themselves with a gear lower than 5.
Slowly pull the trigger, and the propeller will
start.
15-20
kph
4. Slow gliding practice: Adjust the speed
through the gear. When the flight speed
reaches about 15kph, slightly tilt the front of
the board. You can take off.
5. After taking off, adjust the height and direction
of the flight by shifting your weight.
Explorer/Patroller PLUS Power Kit USER GUIDES
Note: To obtain a better wireless signal
connection, the front of the board should be
exposed to the water as much as possible
during the flight. Beginners need a certain
amount of training to slowly master the skills
and reach the flight action of Steps 4 and 5. It
is recommended that beginners spend more
time practicing.
Maintenance
Regularly check the waterproof components
(such as the Controller Plus, the PowerFlight
Battery, and the mast head) for damage and the
status of each module of the power system and
control system.
1. After using the product, turn off the Controller
Plus and PowerFlight Battery.
2. To clean the Plus Power Kit, please flush the mast
body with a fresh water pipe for about 1 min to
ensure that there is no seawater residue on the body
to prevent corrosion. Rinse the mast head to ensure
that the mast head is clean and free of debris; rinse
with fresh water and clean the DC port of the mast
with an alcohol swab to ensure that the DC port is dry
and free of debris. Clean the motor shroud, propeller,
and propeller protective cover with fresh water. Make
sure to remove any salt, sand or other debris.
3. Rinse the board body with a fresh water pipe for
about 1 minute, and clean the battery compartment
and mast mounting hub and other parts to ensure
that there is no salt, sand or other debris remaining.
Then wipe it dry with a dry towel and let it stand in a
dry environment to remove the remaining water.
4. Clean the battery, use fresh water to rinse the
appearance of the battery. Use a cotton swab dipped
in a little alcohol to clean the battery DC port and
buttons. Wipe the battery with a dry towel and let
stand in a dry environment to remove the remaining
water.
5. Clean the Controller Plus. Pay special attention to
the location of the trigger. If you find that there is a
jam when pulling the trigger, check whether there is
any gravel in the trigger. If so, rinse the gravel out
with clean water.
6. After cleaning, wait for the moisture of all parts to
dry before putting the parts back into the package.
7. When storing this product, avoid direct sunlight.
Ultraviolet rays and high temperatures will cause
permanent damage to the product.
8. To ensure safety, make sure to turn off the remote
control and battery, and when transporting this
product, do not install the battery on the board.
All rights reserved by Waydoo
EN
12
