iLIVE ISB210 - Portable Touch Light Wireless Speaker Manual

Features

Supports Bluetooth
Party Plus Mode
Wireless range: 33 ft.
Built-in microphone for hands free speakerphone
Voice prompts announce speaker functions
Micro-USB port for battery recharge
DC battery power: built-in rechargeable battery
Battery life: approx. 9 hrs at 50% volume (light off)

Includes

USB charging cable
3.5mm audio cable
User's guide

Overview & Controls

Remove the sticker on the bottom of the speaker.
Remove Sticker

Battery Power

Charge fully before use. The charge time is approximately 3 hours.

When the unit is charging, the Charging Indicator Light will display a solid red light. When charging is complete, the indicator will turn green.

Using a Micro-USB to USB cable (included), connect the DC power input on the speaker to the USB port of a powered on computer or USB power adaptor (not included) to charge the speaker.
Charging

Pairing Bluetooth & Playing Audio

Note: This model features automatic Bluetooth pairing.

Power on the speaker, the Bluetooth Indicator Light will flash white, this means the speaker is ready to pair.
Using the controls on your Bluetooth device, select ISB210 in the Bluetooth settings to pair. A voice will announce "Bluetooth is connected," and the light will turn solid white when the speaker is successfully paired to your device. If need be, refer to the user's manual for your specific device for more information.
Use the controls on the connected Bluetooth device to select and begin playing audio. Use the controls on the device or the speaker to play, pause, or answer an incoming call.

Note: The speaker will always try to reconnect to the last device used. To reconnect to a different device, press and hold the Play/Pause/Pair button until "Bluetooth is connecting," is heard. Access the Bluetooth settings menu on the device you wish to use and select ISB210.

Party Plus

If you have two ISB210 Wireless Speakers, you can pair them together for stereo sound.

Power on both speakers one by one.
Make sure that both speakers are not connected to any Bluetooth device.
Press the POWER button once on one of the speakers and wait until you hear a beep indicating the 2 speakers are paired. Note: this is now the dominant speaker.
Pair your device to ISB210 and audio can now be heard on both speakers.
To disconnect from Party Plus Mode, Press the POWER button on one of the speakers.
To reconnect again, quickly press the POWER button twice on the non-dominant speaker.

Aux In

Requires a 3.5mm cable (included).

Connect the included 3.5mm cable to the Aux in port on the speaker. You will hear "Auxiliary" and the Indicator Light will flash slowly when the unit is ready.
Plug the other end into audio output/headphone jack on a media player.
Use the controls on the connected device to select and play audio.

LED Lantern

To use the lantern light, use 2 fingers to gently tap the lantern sensor or tap the top of the lantern.
Tap once for high setting, twice for medium, three times for low and four times to turn the light off.

ADDITIONAL WARNINGS

To prevent fire or shock hazards, do not expose this unit to rain or moisture.
Where the mains plug or appliance coupler is used as the disconnect device, such disconnect device shall remain readily operable.
Lithium batteries, like all rechargeable batteries, are recyclable and should be recycled or disposed of according to state and local guidelines. They should never be disposed of in normal household waste and they should never be incinerated, as they might explode. Contact your local government for disposal or recycling practices in your area.

This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov. This product meets and complies with all Federal regulations.
