ASSEMBLY INSTRUCTION
Check there is no network voltage before installing the equipment.
• Unplug the appliance (1) before installing/substituting the bulb.
• Put bulbs (2) to the lamp holders.
• Insert the glass (3) until it leans on the box(4).
• Tighten the three screws (5) within the frame: proceed to make a fixed and stable
glass. Do not exceed When tightening to prevent breakage or cracking of the
glass.
• If you are unable to tighten the three screws (5) due to an excessive thickness of
the glass, move the screws in the holes (6).
• Connect the plug (1) to the electrical power supply.
If the external flexible cable or cord of this luminarie is damaged, it shall be
exclusively replaced by the manufacturer or his service agent or a similar qualified
person in order to avoid a hazard.
English
BOT LT 35
ISTRUZIONI PER IL MONTAGGIO
Assicurarsi che non sia presente tensione di rete prima di procedere all'installazione
dell'apparecchio.
• Scollegare la spina (1) dalla presa elettrica prima di montare/sostituire la lam-
padina.
• Avvitare le lampadine (2) nei portalampade.
• Infilare il vetro (3) fino ad appoggiarlo alla scatola (4).
• Avvitare le tre viti (5) all'interno della montatura : procedere fino a rendere fisso
e stabile il vetro. Non eccedere nell'avvitamento onde evitare rotture o criccature
del vetro.
• Se non si riuscisse ad avvitare le tre viti (5) a causa di un eccessivo spessore del
vetro, spostare le viti nei fori (6).
• Collegare la spina (1) alla presa di rete.
• Se il cavo flessibile esterno di questo articolo risultasse danneggiato, deve essere
sostituito esclusivamente dal produttore, dal suo agente di servizio o da personale,
qualificato così da impedire incidenti.
rev. 1
Italiano
