SubDude Audio PINWOOFER Instructions Manual

Hide thumbs Also See for PINWOOFER:

Advertisement

Quick Links

Copyright © 2019-2023 SubDude Audio LLC, Idaho, USA. All
Rights Reserved. Reproduction, transmission or
redistribution of this document or its contents without
written permission is prohibited.
Take your time, follow the instructions, relax, and enjoy yourself!
WARNINGS: Perform installation with your pinball machine turned off and unplugged from AC power.

Advertisement

loading
Need help?

Need help?

Do you have a question about the PINWOOFER and is the answer not in the manual?

Questions and answers

Summary of Contents for SubDude Audio PINWOOFER

  • Page 1 Copyright © 2019-2023 SubDude Audio LLC, Idaho, USA. All Rights Reserved. Reproduction, transmission or redistribution of this document or its contents without written permission is prohibited. Take your time, follow the instructions, relax, and enjoy yourself! WARNINGS: Perform installation with your pinball machine turned off and unplugged from AC power.
  • Page 2 PinWoofer KO and GT BBU Amplifier Instructions...
  • Page 3: Kit Components

    Kit Components Shown to the right are the kit • components: 1. PinWoofer BBU Board 2. 3ft 3.5mm Male to Male TRS Cable 3. 3ft Power Cable 4. 12ft 3.5mm TRS Male Stereo to RCA Male Stereo Subwoofer Cable 5. Adhesive Double Sticky Mounting Pad.
  • Page 4 BBU Overview The PinWoofer BBU (Bass Boost Unit) is • used with a PinWoofer Amplifier. It enables fine control of Bass Volume and • Bass Frequency Cutoff and provides a line out to your external subwoofer. The first time you use the BBU, please •...
  • Page 5 Amplifier Identification This document covers BBU installation on • one of two possible amplifier models. Identify your amplifier as shown to the • right. Section 1: PinWoofer KO • Section 2: PinWoofer GT •...
  • Page 6 Section 1 KO Amplifier •...
  • Page 7 Starting PinWoofer KO Amplifier Connections Shown to the right are: • 1. Harness Power Cable Connection. 2. Harness Audio Cable Connection.
  • Page 8 KO BBU Connections Disconnect the Harness Power Cable from the PinWoofer Amplifier and plug it into the 5.5mm BBU Power Jack. Connect the New Power Cable Stub to the 2-pin header on the BBU observing the polarity shown. Plug the other end of the New Power Cable Stub into the 5.5mm amplifier power jack.
  • Page 9 Section 2 GT Amplifier •...
  • Page 10 Starting PinWoofer GT Amplifier Connections Shown to the right are: • 1. Harness Power Cable Connection. 2. Amplifier Output Mini-Jack.
  • Page 11 GT BBU Connections 1. Disconnect the Harness Power Cable from the PinWoofer Amplifier and plug it into the 5.5mm BBU Power Jack. 2. Connect the New Power Cable Stub to the 2-pin header on the BBU observing the polarity shown. (The image shows a 12in cable to minimize clutter.)
  • Page 12: Subwoofer Connection

    Subwoofer Connection Route the 12ft SUB_OUT cable out the • back of the cabinet (through a ventilation hole) and plug into your subwoofer. • It is recommended that you run the external subwoofer volume at or near maximum. It is also recommended that you run the bass cutoff frequency (LOW PASS / Hz) at maximum.
  • Page 13 KO Use Model Example Shown is one example of how you might • place your BBU into your machine using the KO Amplifier. Keep in mind that there is power to your • BBU so care should be taken to secure it to an interior surface using the supplied double sticky tape, similar to what is shown.
  • Page 14 GT Use Model Example Shown is one example of how you might • place your BBU into your machine using the GT Amplifier. Keep in mind that there is power to your • BBU so care should be taken to secure it to an interior surface using the supplied double sticky tape, similar to what is shown.
  • Page 15 Your PinWoofer BBU is now ready for use.
