  • Page 1 NI-6589 2022-07-06...

  • Page 2: Table Of Contents

    NI-6589 Contents NI 6589 Getting Started Guide........... 3 Electromagnetic Compatibility Guidelines.

  • Page 3: Ni 6589 Getting Started Guide

    Furthermore, any modifications to the product not expressly approved by National Instruments could void your authority to operate it under your local regulatory rules. Caution To ensure the specified EMC performance, operate this product only with shielded cables and accessories. © National Instruments...

  • Page 4: Flexrio Documentation

    NI-6589 Caution To ensure the specified EMC performance, you must attach EMI gaskets (NI part number 746228-01) to both sides of your NI 6589 before using. Caution To ensure the specified EMC performance, you must install PXI EMC Filler Panels (NI part number 778700-01) in all open chassis slots.

  • Page 5: Verifying The System Requirements

    To use the FlexRIO Support instrument driver, your system must meet certain requirements. For more information about minimum system requirements, recommended system, and supported application development environments (ADEs), refer to the FlexRIO Support Readme, which is available on the FlexRIO Support software DVD or online at ni.com/updates. © National Instruments...

  • Page 6: Unpacking

    NI-6589 Unpacking Caution To prevent ESD from damaging the devices, ground yourself using a grounding strap or by holding a grounded object, such as your computer chassis. 1. Touch the antistatic package to a metal part of the computer chassis.

  • Page 7: Installing The Ni 6589

    MAX is automatically installed with FlexRIO Support. 1. Launch MAX by navigating to Start » All Programs » National Instruments » NI MAX or by clicking the NI MAX desktop icon.

  • Page 8: Cables

    NI-6589 Cables Caution You must operate the NI 6589 with shielded cables and shielded accessories to ensure compliance with the EMC requirements defined in the NI 6589 Specifications. Do not use unshielded cables or accessories unless they are installed in a shielded enclosure with properly designed and shielded input/output ports and are connected to the NI 6589 using a shielded cable.

  • Page 9: Accessories

    A flying lead cable, the NI SHB12X-H3X24, is also available for differential signals. This cable offers connectivity similar to that found on a typical logic analyzer, so you can use it in logic analyzer-type applications. This cable is shown in the following figure. © National Instruments...
  • Page 10 NI-6589 Figure 2. NI SHB12X-H3X24 Flying Lead Cable 1. Leads (1 × 3 Header Receptacle) 2. DDC Connector 3. Removeable Sleeving Custom Accessories If you are creating a custom accessory to use with a DUT with a VHDCI DDC connector, you can purchase the mating connector for the VHDCI cable from NI. For...

  • Page 11: Front Panel And Connector Pinouts

    To avoid permanent damage to the NI 6589, disconnect all signals connected to the NI 6589 before powering down the module, and connect signals only after the adapter module has been powered on by the FlexRIO FPGA module or Controller for FlexRIO. © National Instruments...
  • Page 12 NI-6589 Caution Connections that exceed any of the maximum ratings of any connector on the NI 6589 can damage the device and the chassis. NI is not liable for any damage resulting from such connections. Note If you design a custom cabling solution with the Infiniband connector (779157-01) and the SHB12X-B12X LVDS shielded cable (192344-01), the NI 6589 pinout is reversed at the end connector.

  • Page 13: Block Diagrams

    Differential data lines provide a low-noise, low- power, low-amplitude differential method for high-speed digital data transfer. Figure 4. Clock Input Signal Global Clock to CLOCK IN NI FlexRIO FPGA Module (UserGclkLvttl) © National Instruments...
  • Page 14 NI-6589 Figure 5. LVDS Data and PFI Lines Direction Control from NI FlexRIO FPGA Module (GPIO Direction) Data from NI FlexRIO FPGA Module 110 Ω DIO <0..15>+ and (GPIO Output) PFI <1..4>+ Switch Data to DIO <0..15> NI FlexRIO FPGA Module 110 Ω...

  • Page 15: Component-Level Intellectual Property (Clip)

    FPGA. Adapter module socketed CLIP allows your IP to communicate directly with both the FPGA VI and the external adapter module connector interface. The FlexRIO adapter module ships with socketed CLIP items that add module I/O to the LabVIEW project. Related reference Block Diagrams ■ © National Instruments...

  • Page 16: Ni 6589 Clip

    NI-6589 NI 6589 CLIP Refer to the following table for the available NI 6589 CLIP items, and each CLIP item's function and available signals. Note All NI 6589 CLIP items allow individual clock output inversion. CLIP Name Signals Description NI 6589...
  • Page 17 PFI 1+ GPIO_39_CC GPIO_36 GPIO_14 PFI 1- GPIO_39_n_CC GPIO_36_n PFI 2+ GPIO_40_CC GPIO_41 GPIO_14_n PFI 2- GPIO_40_n_CC GPIO_41_n PFI 3+ GPIO_45 GPIO_46 GPIO_15 PFI 3- GPIO_45 _n GPIO_46_n PFI 4+ GPIO_47 GPIO_48 GPIO_15_n PFI 4- GPIO_47_n GPIO_48_n © National Instruments...
  • Page 18 NI-6589 NI 6589 FlexRIO FPGA Module Signal Name GPIO Input GPIO Output GPIO Direction DIO 0+ GPIO_62 GPIO_32 GPIO_4_n DIO 0- GPIO_62_n GPIO_32_n DIO 1+ GPIO_63 GPIO_28 GPIO_11 DIO 1- GPIO_63_n GPIO_28_n DIO 2+ GPIO_64 GPIO_23 GPIO_9_n DIO 2- GPIO_64_n...

  • Page 19: Clocking

    Global clock are all sourced by the crosspoint switch. The Acquisition Bank I/O clock can be sourced from the crosspoint switch or accessed directly through the Strobe Bypass path. Note Only the Acq_IO_Clock_Source signal can use the STROBE Bypass path. If Acq_IO_Clock_Source is set to Strobe Bypass, then © National Instruments...

  • Page 20: Where To Go Next

    NI-6589 Gen_IO_Clock_Source, PFI_IO_Clock_Source, and IO_Module_Clock_1_Source cannot be set to Strobe From Crosspoint Switch. Figure 9. Crosspoint Switch Strobe Bypass Control from NI FlexRIO FPGA Module (GPIO_8_n) Acquisition Bank I/O Clock to NI FlexRIO FPGA Module STROBE GPIO_56_CC GPIO_56_n_CC Generation Bank I/O Clock...

  • Page 21: Worldwide Support And Services

    A Declaration of Conformity (DoC) is our claim of compliance with the Council of the European Communities using the manufacturer’s declaration of conformity. This system affords the user protection for electromagnetic compatibility (EMC) and product safety. You can obtain the DoC for your product by visiting ni.com/ © National Instruments...
  • Page 22 1 866 ASK MYNI (275 6964). For telephone support outside the United States, visit the Worldwide Offices section of ni.com/niglobal to access the branch office websites, which provide up-to-date contact information, support phone numbers, email addresses, and current events. ni.com © 2022 National Instruments Corporation.
