- Page 1 Table of Contents DBU INTERF ACE OPTION MODULE (MULTIPORT) Part Number 1200089L2#HS USER MANUAL 61200.089L2-1A November 1995 61200.089L2-1 DBU Interface Option Module User Manual...
- Page 2 Table of Contents 901 Explorer Boulevard P.O. Box 070020 Huntsville, AL 35807 Phone: (205) 971-8000 Fax: (205) 971-8699 © 1995 ADTRAN, Inc. All rights reserved. Printed in the USA. DBU Interface Option Module User Manual 61200.089L2-1...
- Page 3 Table of Contents FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 Table of Contents DBU Interface Option Module User Manual 61200.089L2-1...
-
Page 5: Table Of Contents
Dial Backup Option Module Specifications ............3 Physical Description ....................4 Chapter 2. Installation ..................5 Unpack & Inspect ....................5 ADTRAN Shipments ....................5 Customer Provides ....................5 Installing the Option Module ................6 Placement of the Option Module ..............6 Power Connection .................... - Page 6 Table of Contents 7)PORT UTILITY, Submenu of 3)UTIL ............19 Operation ......................19 2)RUN SELF TEST, Submenu of 4)TEST ............20 3)PORT TEST, Submenu of 4)TEST ..............21 Operation ......................21 Appendix A. Dial Backup System Messages ..........2 3 List of Figures Figure 1-1.
-
Page 7: Chapter 1. Introduction
The Dial Backup (DBU) Interface Option Module is one of the option modules available for use with the ADTRAN TSU 100/600. The DBU interface option module installs in the option slot of the TSU 100/600 and provides a DTE interface capable of interfacing to various dial backup devices. -
Page 8: Features Of The Dbu Interface Option Module
Chapter 1. Introduction FEATURES OF THE DBU INTERFACE OPTION MODULE The main features of the DBU Interface Option Module include the following: • Operates using 1 to 24 DS0s • Includes an elastic store for absorption of rate variations • Accepts a plug-on port •... -
Page 9: Compatibility
Chapter 1. Introduction COMPATIBILITY The DBU Interface Option Module has been tested with the following external DCE devices: • ADTRAN DSU • ISU 2x64 (ADTRAN) • ISU 128 (ADTRAN) • ISU 512 (ADTRAN) DIAL BACKUP OPTION MODULE SPECIFICATIONS DTE Interface CCITT V.35 Synchronous... -
Page 10: Physical Description
Chapter 1. Introduction PHYSICAL DESCRIPTION The DBU is a module which plugs into the option slot in the rear of the TSU 100/600; see Figure 1-1. The rear panel of the option module includes a plastic plug over a cutout for a plug-on option card. This allows a plug-on board to be added to the option module, creating an additional port. -
Page 11: Chapter 2. Installation
Carefully inspect the DBU module for any shipping damage. If damage is suspected, file a claim immediately with the carrier and then contact ADTRAN customer service. If possible, keep the original shipping container for use in shipping the DBU module back for repair or for verification of damage during shipment. -
Page 12: Installing The Option Module
Chapter 2. Installation INSTALLING THE OPTION MODULE Placement of the Option Module Figure 2-1 is representative of the action required for proper placement of the option module. Perform the following steps to install the option module: 1. Remove the cover plate from the TSU 100/600 rear panel. -
Page 13: Warranty And Customer Service
Chapter 2. Installation WARRANTY AND CUSTOMER SERVICE ADTRAN will replace or repair this product within five years from the date of shipment if it does not meet its published specifications or fails while in service. For detailed warranty, repair, and return information refer to the ADTRAN Equipment Warranty, Repair, and Return Policy Procedure at the end of this manual. -
Page 14: Wiring
Chapter 2. Installation WIRING The DBU option module has a V.35 Winchester-style connection as defined in Table 2-A. Table 2-A V.35 Winchester Pin Connection CCITT DESCRIPTION Protective ground (PG) Signal ground (SG) Request to send (RTS) to DCE Clear to send (CTS) from DCE Data set ready (DSR) to DTE from DCE Received line signal detector (DCD) from DCE Data terminal ready (DTR) to DCE... -
Page 15: Power-Up Initialization
Chapter 2. Installation POWER-UP INITIALIZATION No initialization input is required. Upon power-up, any previously configured setting for the DBU is automati- cally restored. When the configuration is successfully restored, the LED labeled OK in the MODULE group on the front panel turns On. - Page 16 Chapter 2. Installation DBU Interface Option Module User Manual 61200.089L2-1...
-
Page 17: Chapter 3. Operation
Chapter 3. Operation Chapter 3 Operation OVERVIEW The DBU is controlled as part of the TSU 100/600 using the same methods as described in the TSU 100/600 user manual. Front Panel Indicators/Buttons Refer to the description of the TSU 100/600 front panel indicators and buttons in the TSU 100/600 user manual. -
Page 18: Figure 3-1. Tsu 100 Main Menu Tree
Chapter 3. Operation % AS 1) NI PERF RPTS 2) NI ERRORS (ALARM LIST) 3) ACTIVE ALARMS 1) STATUS END OF LIST (HISTORY LIST) 4) VIEW HISTORY END OF HISTORY DTE DATA/ 0.1 Nx56/64 DTE STATUS 5) PORT STATUS (OPTION PORTS) PORT RATE 6) REMOTE PORT 1) FORMAT... -
Page 19: Dbu Menus Are All Submenus
Chapter 3. Operation DBU MENUS ARE ALL SUBMENUS The DBU menus are accessed from, and operated the same as, menus for the TSU 100. As shown in the menu items in bold italics in Figure 3-1, the DBU items are submenu choices of the four Main menus. -
Page 20: Port Status, Submenu Of 1)Status
Chapter 3. Operation 5)PORT STATUS, SUBMENU OF 1)STATUS The Status menu branch provides the ability to view the status of the TSU 100 operation. It displays the status of the monitored signal line on the DBU option board and the backup rate for which the DBU card is configured. Operation To display Figure 3-3 on the TSU 100, start with the cursor on Main menu item 1)STATUS and do the... -
Page 21: Figure 3-4 Sync Status Window
Chapter 3. Operation DCE DATA/CK: Shows the status (active or not active) of the following lines: Transmit data to the DCE Receive data from the DCE Data carrier detect from DCE Lock status of the phase locked loop DCE Status: Shows the status (active or not active) of the following lines: Request to send to DCE Clear to send from DCE... -
Page 22: Port Config, Submenu Of 2)Config
Chapter 3. Operation 7)PORT CONFIG, SUBMENU OF 2)CONFIG The 7)PORT CONFIG submenu is used for configura- tion of the DIALBU option module. Operation To display Figure 3-5 on the TSU 100, starting with the cursor on Main menu item 2)CONFIG, do the following: 1. - Page 23 Chapter 3. Operation 4. The DBU can activate backup in two basic modes: Single End Failure or Both End Failure: Single End Failure (Mode: ORIG/ANS.ANY) - In this mode, a network failure detected at either end of the circuit causes a backup to be activated. The DBU at the failed end initiates a call to the opposite end which goes into backup mode upon receiving a call.
- Page 24 Chapter 3. Operation 6. NUMBER DS0: (1-24) - The number of DS0s that are backed up is entered by using the numeric keypad on the front of the TSU 100/600. Verify that the two above settings do not exceed available bandwidth.
-
Page 25: Factory Restore, Submenu Of 3)Util
The 7)PORT UTILITY submenu is used primarily to access the display of the current software information for each port installed in the unit. This information is required when requesting assistance from ADTRAN Technical Support or when updates are needed. Operation To display Figure 3-6 on the TSU 100, do the following: 1. -
Page 26: Run Self Test, Submenu Of 4)Test
Chapter 3. Operation To display the port name and the firmware version installed as shown in Figure 3-7, do the following: 1. Use the Scroll keys to move through the available ports, or enter the port number with the number key. -
Page 27: Port Test, Submenu Of 4)Test
Chapter 3. Operation 3)PORT TEST, SUBMENU OF 4)TEST This menu item is used to activate testing of specific data ports. It also controls the activation of loopbacks and the initiation of data test patterns. Test results are shown on the TSU 100 display. The execution of port tests disrupts normal data flow in the port being tested. - Page 28 Chapter 3. Operation 4) DCE DATA/CK - Allows status of DCD and LCK to be monitored while the INTERFACE TST is on. If the dial up network is correctly configured, there should be an asterisk over DCD and LCK. 5) CHECK DCE RATE - Measures the clock rate provided by the external DCE to the Dial Backup option card.
-
Page 29: Appendix A. Dial Backup System Messages
Appendix A. Dial Backup System Messages Appendix A Dial Backup System Messages The Dial Backup system messages are the following: • RATE MISMATCH - The dial backup configured rate does not match the rate provided by the DCE. • PLL Alarm - The Phase Locked Loop (PLL) is unable to lock on the clock provided by the DCE interface. - Page 30 Appendix A. Dial Backup System Messages DBU Interface Option Module User Manual 61200.089L2-1...
- Page 31 Technical Support (800) 726-8663 Repair and Return If ADTRAN Technical Support determines that a repair is needed, Technical Support will coordinate with the Return Material Authori- zation (RMA) department to issue an RMA number. For informa- tion regarding equipment currently in house or possible fees...
- Page 32 DCD - Normal DBU MODE: ORG/ANS ANY DSR - Off Idle + Test Set number of DS0s to backup If Code revision is incorrect, contact ADTRAN Customer (1-24) Service at (800) 726-8663. CTS - Follow RTS Set rate per DS0 (56K or 64K) 3.
- Page 33 (V.54 loopback Repair and Return cannot be sent over the backup link.) If ADTRAN Technical Support determines that a repair b. Turn on 511 pattern generation in the Nx56/64 in is needed, Technical Support will coordinate with the the local end unit and verify sync.
- Page 34 Same as the TSU 100, and the DBU must be installed in slot 2. TSU 600L2 Same as the TSU 100, and the DBU must be installed in slot 2. For further assistance, please contact ADTRAN Technical Support at 1-800- 726-8663. 61200.089L2-17A...
