CW9162 Installation Guide
CW9162 Installation Guide
The Cisco Catalyst Wireless 9162 is a tri-band enterprise-class WiFi 6E cloud-managed access point supporting the 2.4
GHz, 5 GHz, and the newly opened unlicensed 6 GHz frequency bands. Designed for the ultra-high capacity and
highest density, these AP meet the needs of the most demanding and mission-critical environments. The access point
includes a fourth radio dedicated to optimizing the RF environment and securing the airwaves. The AP also has an
additional Bluetooth Low Energy (BLE) capable radio used for location and other IoT applications. In addition, the
CW9162 has a USB port.
About this Guide
This guide provides instructions on how to install and configure your CW9162 access points. This guide also provides
mounting instructions and limited troubleshooting procedures. For more wireless installation guides, refer to the
installation guides section
Product Overview
Physical Specifications
Interfaces
• 1x 100/1000/2.5G BASE-T Ethernet (RJ45)
• 1x DC power connector (5.5 mm x 2.5 mm, center positive)
Power
on our documentation website.
CW9162
wireless
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CW9162 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cisco MERAKI CW9162

  • Page 1 CW9162 has a USB port. About this Guide This guide provides instructions on how to install and configure your CW9162 access points. This guide also provides mounting instructions and limited troubleshooting procedures. For more wireless installation guides, refer to the...
  • Page 2 Physical Security • Kensington lock hardpoint * Screws that can be attached to the security hasp of the universal mounting bracket • Concealed mount plate with anti-tamper cable bay Product View and Physical Features Your CW9162 has the following features:...
  • Page 3 A - LED indicator B - USB Slot - with protective cover C - Kensington lock hard point D - Rubber Feet/universal mounting bracket slide in points E - Cable access bay The Meraki AP comes with the default Cisco universal mounting bracket (AIR-AP-BRACKET-2) that has the following features:...
  • Page 4: Security Features

    2. Kensington lock – The access point contains a hard point that allows it to be secured to any nearby permanent structure using a standard Kensington lock. Ethernet Ports The CW9162 features one RJ45 port capable of operating at 100/1000/2.5G BASE-T Ethernet (RJ45). ETH0, PoE...
  • Page 5: Power Source Options

    6GHz Scan CW9162 AP can be powered by PoE power in different modes as mentioned above when using a PoE capable switch. They can also be powered by a single 802.3at capable PoE injector MA-INJ-6 Meraki multiGigabit 802.3at Power over Ethernet Injector.
  • Page 6: Package Contents

    Surveys with MR Access Points for more details. The CW9162 access point may be operated in the “Run Dark” mode for additional security and to reduce the visibility of the access point. In this mode, the LED will not be illuminated. This mode may be enabled through the Meraki Dashboard.
  • Page 7 T-Rail mount attachment (AIR-AP-T-RAIL-R) and screws (5 Nos - 6-32 x 1/4 included)
  • Page 8: Safety And Warnings

    Safety and Warnings These operations are to be taken with respect to all local laws. Please take the following into consideration for safe operation: • Power off the unit before you begin. Read the installation instructions before connecting the system to the power source.
  • Page 9: Pre-Install Preparation

    Pre-install Preparation You should complete the following steps before going on-site to perform an installation. Configure your Dashboard Network The following is a brief overview only of the steps required to add an access point to your network. For detailed instructions about creating, configuring, and managing Meraki wireless networks, refer to the online documentation (documentation.meraki.com).
  • Page 10: Static Assignment

    Static Assignment • Static IPs are assigned using the local web server on each AP. The following procedure describes how to set the static • Using a client machine (e.g., a laptop), connect to the AP wirelessly (by associating to any SSID broadcast by the AP) or over a wired connection.
  • Page 11: Installation Instructions

    RJ45 connectors long enough for your particular mounting location Note: CW9162 can be powered by a PoE Switch, PoE Injector or an AC adaptor. Powering up the AP with an AC adapter while connecting to a PoE source is not recommended. Proper functionality of the AP is not guaranteed and this can potentially cause damage to the AP hardware.
  • Page 12 Attaching the Universal Mounting Bracket The access point universal mounting bracket (AIR-AP-BRACKET-2 - included) can be used to install your access point in a wide range of scenarios including a wall or solid ceiling, below a drop ceiling, or on various electrical junction boxes. Wall or Solid Ceiling Mount Using Universal Mounting Bracket Using included wall anchors and screws, attach the universal mounting bracket to your mounting wall or ceiling.
  • Page 13 4. Align the corresponding holes (A, B, or C) on the mounting bracket over the mounting holes on the ceiling grid clip. 5. Hold the mounting bracket and insert a 6-32 x 1/4 in. screw into each of the four corresponding holes (A, B, or C) and tighten.
  • Page 14 Wall Mount the AP using Universal Mounting Bracket To mount the AP on the wall first, identify the location of the wall 1. Use the mounting bracket as a template to mark the locations of the mounting holes on the bracket 2.
  • Page 15 The AP is not ready to be mounted on the wall Electrical Junction Box Mount Using Universal Mounting Bracket The access point can be mounted to a 4” square cable junction box, a 3.5 or 4” round cable junction box, or various U.S. and European outlet boxes (mounting screws are not included).
  • Page 16: Physical Security

    bracket. If mounting to a wall or ceiling, the Ethernet cable will feed from behind the AP. The "Power Source Options" section of this document lists the different powering options and their unique characteristics. Mount the AP Attach the AP to the Universal Mounting Bracket (Picture for Wall mount section and Picture for ceiling mount section ) The AP has four rubber feet that when gently slid in attach to the universal mounting bracket To attach the AP to the universal mounting bracket properly, align the access point feet over the keyhole mounting slots...
  • Page 17: Kensington Lock

    6GHz Configuration The 6 GHz frequency band for the CW9162 can be enabled from the RF Profile page in the dashboard Wireless > CONFIGURE > Radio Settings>RF Profiles 6 GHz band is enabled using the drop-down menu, 6 GHz capability can be enabled for all SSIDs...
  • Page 18: Basic Troubleshooting

    6 GHz channel selection in the RF profile for CW9162 Auto RF configuration will be restricted to a set of PSC capable channels. The list of the PSC channels is indicated above in green. Auto RF will choose a channel that is a PSC-supported channel for 20, 40, 80, and 160 MHz frequencies.
  • Page 19 If your access point still does not connect, the following instructions may be useful, depending on your issue. Check Radio Functionality by Making the AP a Repeater 1. If your AP is acting as a gateway, disconnect the Ethernet cable from the LAN (while keeping the AP powered on). This will switch your AP into repeater mode.
  • Page 20: Warranty

    Meraki CW9162 devices have been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 21 Support and Additional Information If issues are encountered with device installation or additional help is required, contact Meraki Support by logging in to dashboard.meraki.com and opening a case by visiting the Get Help section. • The equipment is intended for industrial or other commercial activities. •...
